Android Infra Red

Open source project for transmitting signals via IR-blasters on Android devices

Created in Android Studio

Supports Samsung, HTC, some LG devices with IR

Contains:

• SampleApplication
• InfraRed library

Email: one.button.developer@gmail.com

Menu

• Basis
  • Basic theory
  • Sequence types
  • Converting the patterns
• How to use
  • 0. Include the InfraRed library to your project
  • 1. Add the following permissions to your AndroidManifest.xml
  • 2. Initialize logging
  • 3. Initialize the InfraRed class
  • 4. Initialize the transmitter
  • 5. Initialize the raw patterns
  • 6. Adapt the patterns for the device that is used to transmit the patterns
  • 7. Implement the start and stop methods
  • 8. Transmit the adapted patterns via IR
  • In addition
• What's in the box?
  • Android project - Sample application
  • Android library - Infrared
    • Logging package
    • Pattern package
    • Detection package
    • Transmit package
    • Infrared class

Basis

Basic theory

In order to remotely control a device via IR, you require a transmitter (mobile phone with IR blaster) and a control signal sequence that you want to send. This sequence is the key to the function that the device is supposed to perform (e.g. the function of a TV to turns itself on). The built-in IR receiver of the controlled device analyzes all incoming signals. When they match a pattern of a particular function, the devices calls that function.

The control signal sequence consists of two parameters: The frequency (in Hertz) and the pattern, which is a time sequence of ON/OFF signals on the specified carrier frequency. Such patterns can be found on the Internet.

Sequence types

The pattern is pictured by a sequence of numbers either of the hexadecimal (HEX) or the decimal (DEC) numeral system.

Here's an example:

Frequency:
  33000 Hertz (33KHz)
Patterns:
  0) 0x01f4 0x1c84 0x01f4 0x00c8 or (01f4 1c84 01f4 00c8)
  1) 500 7300 500 200
  2) 17 241 17 7

The main difference between the patterns in this example is their notation. Each number in the pattern describes the duration of a single ON/OFF signal, only that patterns 0 and 1 describe it in microseconds, while patterns 2 describes it in cycles.

One cycle always consists of an an ON and an OFF signal (the image below shows cycles with a frequency of 40000 Hz).

Converting the patterns

The length of a single period T in microseconds equals 1 000 000 (1 second in microseconds) divided by the frequency f (in Hertz)

T = 1 000 000 ms / f

For example

T = 1 000 000 ms/ 33000 Hz ≈ 30.3 ms

To covert a microsecond pattern to a cycle pattern, divide each value by T

To convert a cycle pattern to a microsecond pattern, simply multiply each value by T

How to use

0. Include the InfraRed library to your project

• Download the AndroidInfraRed project
• Run the project on a device or an emulator
• Find the infrared-release.aar file in the project folder (infrared/build/outputs/aar/infrared-release.aar)
• Import this file into your own project in Android Studio (File > New > New Module... > Import .JAR/.AAR package)

Tip! Your can download the infrared-release.aar file from releases

Known issue! One of the project files contains broken characters. Just rename it again.

1. Add the following permissions to your AndroidManifest.xml

	<uses-permission android:name="android.permission.TRANSMIT_IR" android:required="false"/>
	<uses-feature android:name="android.hardware.consumerir" android:required="false"/>

2. Initialize logging

You can choose between printing your logs to an EditText view (LogToEditText), the LogCat console (LogToConsole) and not logging at all (LogToAir)

	// print log messages to EditText
	EditText console = (EditText) this.findViewById(R.id.console);
	log = new LogToEditText(console, TAG);

	// print Log messages with Log.d(), Log.w(), Log.e() (LogCat)
	// LogToConsole log = new LogToConsole(TAG);

	// Turn off logs
	// LogToAir log = new LogToAir(TAG);

LogToEditText is the default option

3. Initialize the InfraRed class

Create a new InfraRed object with the parameters Context and Logger

	infraRed = new InfraRed(this, log);

4. Initialize the transmitter

	TransmitterType transmitterType = infraRed.detect();

	// initialize transmitter by type
	infraRed.createTransmitter(transmitterType);

The "detect()" method returns the TransmitterType. Possible values:

• Actual - The signals will be transmitted by the ConsumerIrManager
• Obsolete - The signals will be transmitted by a Samsung IR service
• HTC - The signals will be transmitted by the HTC IR SDK
• LG, LG_WithOutDevice - The signals will be transmitted by the QRemote SDK
• Undefined - the "empty" implementation will be used to transmitt the signals

5. Initialize the raw patterns

	// initialize raw patterns
	List<PatternConverter> rawPatterns = new ArrayList<>();
	// Canon
	// rawPatterns.add(new PatternConverter(PatternType.Intervals, 33000, 500, 7300, 500, 200));
	// Nikon D7100 v.1
	rawPatterns.add(new PatternConverter(PatternType.Cycles, 38400, 1, 105, 5, 1, 75, 1095, 20, 60, 20, 140, 15, 2500, 80, 1));
	// Nikon D7100 v.2
	rawPatterns.add(new PatternConverter(PatternType.Cycles, 38400, 77, 1069, 16, 61, 16, 137, 16, 2427, 77, 1069, 16, 61, 16, 137, 16));
	// Nikon D7100 v.3
	rawPatterns.add(new PatternConverter(PatternType.Intervals, 38000, 2000, 27800, 400, 1600, 400, 3600, 400, 200));
	// Nikon D7100 v.3 fromString
	rawPatterns.add(PatternConverterUtils.fromString(PatternType.Intervals, 38000, "2000, 27800, 400, 1600, 400, 3600, 400, 200"));
	// Nikon D7100 v.3 fromHexString
	rawPatterns.add(PatternConverterUtils.fromHexString(PatternType.Intervals, 38000, "0x7d0 0x6c98 0x190 0x640 0x190 0xe10 0x190 0xc8"));
	// Nikon D7100 v.3 fromHexString without 0x
	rawPatterns.add(PatternConverterUtils.fromHexString(PatternType.Intervals, 38000, "7d0 6c98 190 640 190 e10 190 c8"));

The PatternConverter can be used to easily define and convert IR patterns between the different patterns types (Cycles and Intervals in ms)

6. Adapt the patterns for the device that is used to transmit the patterns

	PatternAdapter patternAdapter = new PatternAdapter(log);

	// initialize TransmitInfoArray
	TransmitInfo[] transmitInfoArray = new TransmitInfo[rawPatterns.size()];
	for (int i = 0; i < transmitInfoArray.length; i++) {
	    transmitInfoArray[i] = patternAdapter.createTransmitInfo(rawPatterns.get(i));
	}
	this.patterns = transmitInfoArray;

PatternAdapter automatically detects the device's manufacturer (LG/HTC/Samsung) and uses that information to determine how the raw patterns have to be converted in order to be compatible with the transmitter of the used device.

7. Implement the start and stop methods

    @Override
    protected void onResume() {
        super.onResume();
        infraRed.start();
    }

    @Override
    protected void onDestroy() {
        super.onDestroy();

        infraRed.stop();

        if (log != null) {
            log.destroy();
        }
    }

Always call the start() method before transmit IR signals and call the stop() method when you are done.

It is a good idea to call them in the onCreate/onDestroy or onResume/onPause methods.

8. Transmit the adapted patterns via IR

    private int currentPattern = 0;

    @Override
    public void onClick(View v) {
        TransmitInfo transmitInfo = patterns[currentPattern++];
        if (currentPattern >= patterns.length) curr
