SubPlotter

SubPlotter is a Python script to visualize data from given files. It supports two types of files, which can represent different types of signals:

1. .sub files, which represent Sub-GHz signals. In these files, the data consists of alternating positive and negative numbers, representing time intervals (in some unit) of 'on' and 'off' states, respectively.

2. .ir files, which represent IR signals. In these files, the data is a series of positive numbers, and 'on' and 'off' states alternate with every number.

The script organizes the data and then uses Plotly to create a graph. It produces a step graph where 'on' states are represented by 1 and 'off' states by 0. The x-axis represents the cumulative time.

Installation

1. Clone the repository
2. Navigate to the project directory in your terminal
3. Install the necessary packages by running pip install -r requirements.txt

Usage

Run the script with the filename as an argument.

python PlotSub.py filename.sub

python PlotIr.py filename.ir
