Advanced Network Security Scanner

⚠️ ALPHA VERSION WARNING ⚠️

Version: 0.3.3-alpha

A modern, high-performance network penetration testing platform built with Tauri, React, and Rust

</div>

What's New in v0.3.3-alpha

This release focuses on scan reliability, correctness, and stability for real-world LAN environments.

Critical bug fixes:

Target argument passing fixed — nmap and masscan previously received space-separated IPs as a single shell argument, causing nmap to attempt DNS resolution and fail. Targets are now passed as separate arguments, resolving DNS hangs and incorrect host handling.
Infinite recursive scan loop eliminated — The discovery manager was autonomously re-scanning every newly discovered host, producing cascading obs:host events that triggered further scans. All autonomous scanning is now disabled; all scanning is strictly user-initiated.
CVE database SQL error fixed — The references column name (a reserved SQLite keyword) caused CREATE TABLE and INSERT failures. Renamed to cve_references throughout.
Masscan empty XML handled gracefully — When masscan finds no open ports it writes a near-empty XML file. Previously this logged a parse error. Now LEGION2 checks file size before parsing: files under 100 bytes produce a quiet "no open ports found" message with no error.

Massmap architecture improvements:

3-phase scanning pipeline — Phase 1 (nmap -sn ARP discovery) → Phase 2 (masscan targeted ports) → Phase 3 (nmap service detection with -sT, no raw socket required). Quick scan now works correctly without root or cap_net_raw.
Quick scan uses -sT (TCP connect) instead of SYN scan — produces real open/closed/filtered results per host without requiring raw socket privileges.
Quick scan NSE scripts — banner, http-title, ssh-hostkey for fast device type identification.
Masscan port list refined — Quick scan uses a targeted 28-port list covering the most common services; comprehensive scan uses full 1-65535 range.
Phase handoff corrected — Phase 3 nmap correctly narrows targets to hosts discovered by Phase 1, not masscan port counts.

Dead code removed:

scanner_engine.rs deleted (unused protocol enum file).

Project Status

LEGION2 v0.3.3-alpha delivers a stable, working scan pipeline on Debian-based Linux systems without requiring root for the common use case. The Tauri/React/Rust architecture eliminates the GUI freezing issues that led to the original LEGION being archived.

Implemented and stable:

3-phase Massmap pipeline: ARP discovery → masscan port sweep → nmap service detection
Real-time scan output via Tauri event system
SQLite persistence for hosts, services, and vulnerabilities
NSE script support with CVE extraction
Network topology visualization
NetSniffer passive packet capture (requires cap_net_raw)
SpiderIoTA IoT device discovery (SSDP, mDNS, WSDD, SNMP, CoAP, MQTT)
Enrichment pipeline: MAC-vendor OUI lookup, TTL-based OS hints, CVE correlation

Architecture Overview

LEGION2 is built on a modern technology stack:

Frontend: React 18 with TypeScript + Zustand for state management
Backend: Rust with Tauri 2 for high-performance, memory-safe operations
Database: SQLite with async operations for reliable data persistence
Scanning Engine: nmap + masscan integration with real-time output streaming
Communication: Event-driven architecture — Tauri events bridge Rust backend to React frontend

Pipeline:

Source (nmap / masscan / netsniffer / iot_probe)
  ↓ ObsStream
Transform Pipeline (MAC enrichment → OS fingerprint → service parse → CVE lookup)
  ↓ Enriched Observations
Broadcast Channel
  ├── UiSink    → Tauri events → React frontend
  ├── DbSink    → SQLite (hosts, services, vulns)
  └── VulnSink  → Vulnerability analysis engine

Screenshots

<div align="center"> <img src="images/legion2/Legion2-v0.3.3-dashboard.png" alt="LEGION2 Scanner Dashboard" width="1300"/> <p><em>Scanner Dashboard with Real-time Live Output</em></p> </div> <div align="center"> <img src="images/legion2/Legion2-v0.3.3-hosts.png" alt="LEGION2 Hosts View" width="1300"/> <p><em>Hosts & Results Analysis Interface</em></p> </div> <div align="center"> <img src="images/legion2/Legion2-v0.3.3-topology.png" alt="LEGION2 Network Topology" width="1300"/> <p><em>Network Topology Visualization</em></p> </div>

Features

Core Scanning Capabilities:

3-phase Massmap: ARP discovery + masscan port sweep + nmap service detection
Quick scan: network topology and device classification in under 90s for a /24
Comprehensive scan: all 65535 ports + OS fingerprinting + vulnerability scripts
Stealth scan: fragmented SYN packets, randomized host order, slow timing
Real-time scan output with terminal-like live display
Automatic host discovery and service enumeration
NSE script support: pass scripts and script-args from the UI

Enhanced User Experience:

Dual-pane interface: Scanner Dashboard and Hosts & Results
Network topology visualization tab
Real-time progress tracking with scan metrics
Live output terminal showing raw scanner output
Responsive design optimized for security workflows

Technical:

Non-blocking async operations — no GUI freezes
Memory-safe Rust backend
Event-driven real-time updates
SQLite persistence across sessions
Interface auto-detection for local network scanning

Installation

Supported Platforms

LEGION2 runs on Debian-based Linux distributions:

| Distribution | Minimum Version | Status | |---|---|---| | Kali Linux | 2022.1+ | ✅ Primary target | | Ubuntu | 22.04 LTS+ | ✅ Supported | | ParrotOS | 5.0+ | ✅ Supported | | Debian | 12 (Bookworm)+ | ✅ Supported | | Linux Mint | 21+ | ✅ Supported |

Option 1 — Build from Source (Recommended)

1. System dependencies

Kali Linux / ParrotOS / Debian 12+ / Ubuntu 22.04+:

sudo apt update
sudo apt install -y \
  build-essential pkg-config curl git \
  libssl-dev \
  libwebkit2gtk-4.1-dev \
  libgtk-3-dev \
  libayatana-appindicator3-dev \
  librsvg2-dev \
  libpcap-dev \
  nmap masscan

Ubuntu 20.04 (uses older webkit):

sudo apt update
sudo apt install -y \
  build-essential pkg-config curl git \
  libssl-dev \
  libwebkit2gtk-4.0-dev \
  libgtk-3-dev \
  libappindicator3-dev \
  librsvg2-dev \
  libpcap-dev \
  nmap masscan

2. Rust toolchain

curl --proto '=https' --tlsv1.2 -sSf https://sh.rustup.rs | sh
source ~/.cargo/env
# Verify
rustc --version   # should be 1.70+

3. Node.js 18+

curl -fsSL https://deb.nodesource.com/setup_20.x | sudo -E bash -
sudo apt install -y nodejs
node --version   # should be 18+

4. Clone and build

git clone https://github.com/NubleX/LEGION2.git
cd LEGION2

# Install frontend dependencies
npm install

# Development mode (hot reload)
npm run tauri dev

# Production release binary
npm run tauri build
# Binary: src-tauri/target/release/legion2

Option 2 — Pre-built Binary (coming soon)

Packaged .deb and AppImage releases will be available on the GitHub Releases page once LEGION2 reaches beta stability.

Runtime Permissions

Certain features require raw socket access. Grant capabilities once after each build, or run as root:

# NetSniffer (passive packet capture) and masscan SYN scan
sudo setcap cap_net_raw,cap_net_admin=eip $(which masscan)
sudo setcap cap_net_raw+ep src-tauri/target/release/legion2

# Alternative: run as root
sudo src-tauri/target/release/legion2

Note: Quick scan (-sT TCP connect mode) does not require cap_net_raw. You can run full quick scans without root. Comprehensive scan uses SYN packets and requires the capability above.

Usage

Launch: Run the binary from src-tauri/target/release/legion2 or use npm run tauri dev for development.
Configure scan: Enter target IP, CIDR range (e.g. 192.168.1.0/24), or space-separated IPs. Select scan type.
Scan types:
- Quick — Network topology + device classification. ARP discovery → masscan top ports → nmap -sT -sV. Under 90s for /24. No root required.
- Comprehensive — Full port scan + OS detection + vulnerability scripts. Requires cap_net_raw.
- Stealth — Slow fragmented SYN scan with randomized host order. Requires cap_net_raw.
Monitor: Watch real-time output in the Live Output panel.
Results: Switch to Hosts & Results tab to view discovered hosts, open ports, service versions, and vulnerabilities.
Topology: Use the Network Topology tab to visualize discovered network structure.

Contributing

LEGION2 welcomes contributions from the security and development community. Priority areas:

Additional scanning tool integrations (Nikto, SSLyze, Gobuster)
Enhanced reporting and export (PDF, JSON, CSV)
UI improvements and accessibility
Test coverage improvements
Documentation

Please review contribution guidelines before submitting pull requests. All contributions must maintain the security focus and professional standards expected of penetration testing tools
