Spatial-Spectral Sensing System

An open-source, validated sensing system for comprehensive spatial-spectral daylight monitoring in buildings, enabling scalable human-centric light assessment.

Associated Publication: "Enabling scalable, human-centric daylight assessment: A validated open-source sensing system for spatial-spectral monitoring in buildings" by Kristiansen et al. (2026) in Building and Environment.

Overview

The Spatial-Spectral Sensing System is a complete, validated platform for multi-node deployment in indoor environments. It combines multispectral sensing with high-resolution imaging capabilities to provide comprehensive light characterization across ultraviolet (UV), visible (VIS), and near-infrared (NIR) wavelengths.

Conceptual overview

Conceptual overview of the multimodal sensing system's capabilities. (a) The system is motivated by the human ocular pathways and the eye's complex spectral sensitivity. (b) The instrument is a single device that captures two synchronized data streams: a high-resolution spatial signal from an RGB imager and a low-resolution (single point) with multispectral signal from a 21-channel sensor. (c) In a measurement, the imager captures the spatial distribution of light, while the spectral sensor integrates light from its entire field of view. (d) This produces a complementary final output: a photometrically accurate high dynamic range (HDR) luminance map and a calibrated absolute spectral irradiance graph for the same scene.

Key Features

21-channel multispectral sensor with full UV-VIS-NIR coverage (260–940 nm)
- 18 channels: VIS/NIR spectral sensor (AS7265x: 410–940 nm)
- 3 channels: UV sensor (AS7331: UVA, UVB, UVC: 280–400 nm)
5MP RGB camera (OV5640) for HDR luminance mapping
High-dynamic-range illuminance sensor (TSL2591) for auto-exposure control
Environmental monitoring (SHT41: temperature & humidity) for thermal compensation
Validated accuracy against reference instrumentation
Open-source hardware and software with complete calibration pipeline

Technical Stack

C/C++ - ESP32-S3 firmware (Arduino framework)
Python - Calibration pipeline and data analysis
PowerShell - Running python scripts

Getting Started

Hardware Assembly

Fabricate Components
- 3D print enclosure parts from 01_Hardware/3d_Models
- Order PCB assembly from 01_Hardware/PCB specifications
Assemble System - Follow the detailed Hardware Assembly Guide
Test Hardware - Use utilities in 02_Firmware/Utilities to verify sensor communication

Firmware Setup

Install Arduino IDE with ESP32 board support
Configure Code Dependencies:
- WiFi credentials in secrets.h (copy from secrets.example.h).
- Calibration factors in calibration.cpp (copy from calibration.example.cpp).
- Sensor libraries in 02_Firmware/Main/src/sensors
Upload Main firmware to ESP32-S3
Verify data logging via serial monitor

Calibration Workflow

The complete calibration pipeline is in 03_Python_Suite. Install Python dependencies with:

pip install -r 03_Python_Suite/requirements.txt

Characterization (generate models for sensor behavior)
- Integration Time Model - Auto-exposure optimization
- Thermal Analysis - Temperature compensation
- Cosine Correction - Angular response validation
- Camera Characterization - HDR imaging calibration
Absolute Calibration (derive calibration factors)
- Lux Calibration - Illuminance sensor
- Spectral Calibration - Multispectral sensors
- Camera Calibration - Luminance mapping
Validation (verify system performance)
- Spectral Validation - Against reference spectroradiometer
- Narrowband Validation - Wavelength accuracy
- Camera Validation - Luminance accuracy

Each subfolder contains a detailed README with step-by-step instructions.

Data Collection

Once calibrated, the system automatically:

Measures spectral irradiance and illuminance at configurable intervals
Captures HDR image sequences
Logs environmental data (temperature, humidity)
Uploads data via WiFi/MQTT/FTP to your server

Project Structure

Each main folder has a dedicated readme.md file.

SpatialSpectralMonitoring/
├── 01_Hardware/                    # Physical design & fabrication
│   ├── 3d_Models/                 # 3D printable enclosure files (.3dm, .step, .stl)
│   └── PCB/                       # Circuit board schematics & dimensions
│
├── 02_Firmware/                   # ESP32-S3 microcontroller code
│   ├── Main/                      # Production firmware
│   └── Utilities/                 # Hardware testing utilities (Arduino sketches)
│
├── 03_Python_Suite/               # Scientific analysis & calibration
│   ├── 00_Utilities/              # Data management helpers
│   ├── 01_Characterization/
│   │   ├── 01_Integration_Time_Model/  # Auto-exposure model generation
│   │   ├── 02_Thermal_Analysis/        # Temperature compensation model
│   │   ├── 03_Cosine_Correction/       # Angular response correction
│   │   └── 04_Camera_Characterization/ # HDR imaging & vignetting correction
│   ├── 02_Absolute_Calibration/
│   │   ├── 01_Lux_Calibration/         # Illuminance calibration
│   │   ├── 02_Spectral_Calibration/    # Spectral irradiance calibration
│   │   └── 03_Camera_Calibration/      # Camera luminance calibration
│   └── 03_Validation/
│       ├── 01_Spectral_Validation/     # Spectral validation analysis
│       ├── 02_Narrowband_Validation/   # Narrowband validation analysis
│       └── 03_Camera_Validation/       # Camera illuminance & luminance validation
│
└── 04_Documentation/              # Project documentation & images

Citation

If you use this system in your research, please cite our work. Citation information is available in the CITATION file or use the "Cite this repository" button on GitHub.

License

This project is licensed under the GNU General Public License v3.0 (GPL-3.0). See LICENSE.

You are free to use, modify, and distribute this project, including for commercial purposes, provided that you:

Preserve copyright notices and license information
License any derivative works under GPL-3.0
Make source code and design files available when distributing
Provide clear attribution to the original authors

Citation is required for all uses (see CITATION).

Acknowledgments

This project was developed at the Norwegian University of Life Sciences (NMBU) and is part of an PhD financed by NMBU.
