LonganNanoTest

<h1>Tests</h1> <table> <tr><th>Led</th><td>Onboard RGB Led</td></tr> <tr><th>Freq</th><td>Output wave signal on pin A8/CK_OUT0 (select wave form in main())</td></tr> <tr><th>Usart</th><td>USART0 (115200,8N1), Pins TX0, RX0</td></tr> <tr><th>Lcd</th><td>Onboard LCD 160x80, SPI master</td></tr> <tr><th>Dma</th><td>DMA mem to CRC register</td></tr> <tr><th>UsartIrq</th><td>USART0 (115200,8N1), Echo serial input to serial output and LCD with 10 character per second, using 1k buffer</td></tr> <tr><th>PA8</th><td>Read GPIO PA8 which is connected to BOOT0 button</td></tr> <tr><th>EspLink</th><td>Connect Rx0/Tx0/Gnd/Rst to an ESP8266 running <a href="https://github.com/jeelabs/esp-link/releases/tag/v3.2.47.alpha">esp-link v3.2.47</a></td></tr> <tr><th>EspLinkWeb</th><td>Connect Rx0/Tx0/Gnd/Rst to an ESP8266 running <a href="https://github.com/jeelabs/esp-link/releases/tag/v3.2.47.alpha">esp-link v3.2.47</a> and update a User Defined Web Page (copy from html folder)</td></tr> <tr><th>EspLinkSocket</th><td>Connect Rx0/Tx0/Gnd/Rst to an ESP8266 running <a href="https://github.com/jeelabs/esp-link/releases/tag/v3.2.47.alpha">esp-link v3.2.47</a> and start TCP server (telnet or netcat to esp-link port 5555 or 6666)</td></tr> <tr><th>I2c</th><td>Connect a 3.3V 1602 LCD via PCF8574 (I2C-to-parallel) to port I2C0 (pins B6,B7) in master mode</td></tr> <tr><th>SpiDma</th><td>Evaluate SPI with and without DMA with and without IRQ</td></tr> <tr><th>GpioIrq</th><td>Display BOOT0 button status on LED via Irq Handler</td></tr> <tr><th>LcdFonts</th><td>Show test string in various fonts on LCD</td></tr> <tr><th><a href="Can">Can</a></th><td>Connect two Longan Nanos via CAN bus</td></tr> <tr><th><a href="SdCard">SdCard</a></th><td>Read/Write SD card</td></tr> <tr><th><a href="Flash">Flash</a></th><td>Using 64MBit SPI Flash memory</td></tr> </table> <h1>Case</h1> <p>3D Printer files for a case are in the folder <a href="_CaseStl">_CaseStl</a>.</p> <h1>License</h1> <p>My code uses the <a href="LICENSE">MIT License</a>. The repository contains code from other sources, for their license conditions check the files in the lib/ folders.</p> <h1>Resources</h1> <img src="https://github.com/kprasadvnsi/longan_nano_pinout/releases/download/v1.1.0/longan_nano_pinout_v1.1.0_w1419_h1000_small.png" alt="pin map" width="100%"/> <h2>Boards</h2> <p> <table> <tr><th>Board</th><th>MCU</th><th>Flash</th><th>SRAM</th></tr> <tr><td>Longan Nano</td><td>GD32VF103CBT6</td><td>128kB</td><td>32kB</td></tr> <tr><td>Longan Nano Lite</td><td>GD32VF103C8T6</td><td>64kB</td><td>20kB</td></tr> </table> </p> <h2>Documentation, Examples, etc</h2> <table> <tr><td>Sipeed Longan Nano <a href="http://dl.sipeed.com/LONGAN/Nano/">Specs Tools</a> <a href="https://longan.sipeed.com/en/">Wiki</a> <a href="https://en.bbs.sipeed.com/c/14-category/">BBS</a></td></tr> <tr><td><a href="http://www.gd32mcu.com/download/down/document_id/222/path_type/1">GD32VF103 User Manual 1.2</a></td></tr> <tr><td><a href="http://www.gd32mcu.com/download/down/document_id/221/path_type/1">GD32VF103 Datasheet 1.3</a></td></tr> <tr><td><a href="http://www.gd32mcu.com/download/down/document_id/228/path_type/1">GD32VF103 Firmware Library User Guide 1.0</a></td></tr> <tr><td><a href="http://www.gd32mcu.com/download/down/document_id/227/path_type/1">GD32VF103 Demo Suites 1.1.0 (.rar)</a></td></tr> <tr><td><a href="http://www.gd32mcu.com/download/down/document_id/266/path_type/1">GD32VF103 Firmware Library 1.1.1 (.rar)</a></td></tr> <tr><td><a href="https://content.riscv.org/wp-content/uploads/2019/06/riscv-spec.pdf">The RISC-V Instruction Set Manual Volume I: Unprivileged ISA</a></td></tr> </table> <h2>platformio.ini</h2> <pre> [env:sipeed-longan-nano-lite] platform = gd32v board = sipeed-longan-nano-lite framework = gd32vf103-sdk upload_protocol = dfu &nbsp; [env:sipeed-longan-nano] platform = gd32v board = sipeed-longan-nano framework = gd32vf103-sdk upload_protocol = dfu</pre>

Longan Nano Lite needs version >= 1.1.1 of the GD32V platform.

<h2>DFU Upload (Linux)</h2> <ol> <li>connect USB</li> <li>press buttons RESET, BOOT0</li> <li>release button RESET</li> <li>release button BOOT0</li> <li>start upload in PlatformIO</li> </ol> <h2>PIN Connections</h2> <table> <tr><th colspan="3">A</th><th colspan="3">B</th><th colspan="3">C</th><th colspan="3">D</th> <tr><th>Pin</th><th>5VT</th><th>OnBoard Function</th><th>Pin</th><th>5VT</th><th>OnBoard Function</th><th>Pin</th><th>5VT</th><th>OnBoard Function</th><th>Pin</th><th>5VT</th><th>OnBoard Function</th></tr> <tr><td>A0</td><td>-</td><td></td> <td>B0</td><td>-</td><td>LCD RS</td> <td></td><td></td><td></td> <td>[D0/OSCIN]</td><td>-</td><td>8MHz Clk</td></tr> <tr><td>A1</td><td>-</td><td>Green LED active low</td><td>B1</td><td>-</td><td>LCD RST</td> <td></td><td></td><td></td> <td>[D1/OSCOUT]</td><td>-</td><td>8MHz Clk</td></tr> <tr><td>A2</td><td>-</td><td>Blue LED active low</td> <td>[B2]</td><td>*</td><td>LCD CS</td></tr> <tr><td>A3</td><td>-</td><td></td> <td>B3</td><td>*</td><td></td></tr> <tr><td>A4</td><td>-</td><td></td> <td>B4</td><td>*</td><td></td></tr> <tr><td>A5/SCK0</td><td>-</td><td>LCD SPI Clk</td> <td>B5</td><td>-</td><td></td></tr> <tr><td>A6</td><td>-</td><td></td> <td>B6</td><td>*</td><td></td></tr> <tr><td>A7/MOSI0</td><td>-</td><td>LCD SPI MOSI</td> <td>B7</td><td>*</td><td></td></tr> <tr><td>A8</td><td>*</td><td>10k PullDown?, connected to BOOT0 button active high</td><td>B8</td><td>*</td><td></td></tr> <tr><td>A9</td><td>*</td><td></td> <td>B9</td><td>*</td><td></td></tr> <tr><td>A10</td><td>*</td><td></td> <td>B10</td><td>*</td><td></td></tr> <tr><td>A11/USBFS_DM</td><td>*</td><td>USB D-</td> <td>B11</td><td>*</td><td></td></tr> <tr><td>A12/USBFS_DP</td><td>*</td><td>USB D+</td> <td>B12/NSS1</td><td>*</td><td>TF CARD SPI CS</td> <td>C13</td><td>-</td><td>Red LED active low</td></tr> <tr><td>A13</td><td>*</td><td></td> <td>B13/SCK1</td><td>*</td><td>TF CARD SPI Clk</td> <td>C14/OSC32IN</td><td>-</td><td>32kHz Clk</td></tr> <tr><td>A14</td><td>*</td><td></td> <td>B14/MISO1</td><td>*</td><td>TF CARD SPI MISO, 10k PullUp</td><td>C15/OSC32OUT</td><td>-</td><td>32kHz Clk</td></tr> <tr><td>A15</td><td>*</td><td></td> <td>B15/MOSI1</td><td>*</td><td>TF CARD SPI MOSI, 10k PullUp</td></tr> <tr><td colspan="99">[x] not available as header pin; 5VT (5 Volt Tolerant Input): * yes, - no</td></tr> </table> <h2>Troubles with Longan Nano and GD32V Platform</h2> <h3>Compile</h3> <ul> <li><pre>.../.platformio/packages/framework-gd32vf103-sdk/GD32VF103_standard_peripheral/gd32vf103.h:179:41: error: redeclaration of C++ built-in type 'bool' [-fpermissive] 179 | typedef enum {FALSE = 0, TRUE = !FALSE} bool;</pre> <p>Put this line in comments, then C++ will compile the SDK files.</p> </li> <li><pre>Adding dfu suffix to firmware.bin sh: 1: dfu-suffix: not found</pre> <p>dfu-utils only gets installed when uploading with dfu. Build with target 'upload' once, then the program will be found.</p> </li> </ul> <h3>Upload</h3> <ul> <li>DFU on Linux: <ul> <li>GD32V 1.1.1: Longan Nano Lite working fine. Longan Nano only after download & compile of <a href="https://sourceforge.net/p/dfu-util/dfu-util/ci/master/tree/">latest dfu-util</a>.</li> <li>GD32V 1.2.0: Error messages after upload, but seems to work. Sometimes a reset is needed after upload and sometimes not.</li> </ul> </li> <li>JLink on Linux (tried with 1.1.1): Gives error message after upload, but after power cycling the Longan Nano the program is working (reset is not enough).</li> <li>DFU on Windows (tried with 1.1.1): didn't get it working. Use <a href="https://longan.sipeed.com/en/get_started/blink.html#usb-dfu-download_1">GigaDevice Dfu Tool</a> instead.</li> <li>JLink on Windows: didn't try yet.</li> </ul>
