gretl - Graph evaluation toolkit

gretl is a tool for basic graph statistics using GFA format input. Our statistics are based on nodes, edges and paths/walks. Walks can also be used, but will be represented as paths internally. Many commands do not work without paths/walk information.
In addition, we added some commands, using graph-based statistics, but represent it on a path (sample scale). We also offer commands for more complex analysis - an overview can be seen below.

---

Requirements on GFA file:

• GFA format v1.0, v1.1 or v1.2.
• Numerical node ID

Comment:

• Sorted node IDs (in 1D SGD) are not required, but all "jump" related statistics, the block and nwindow subcommand will be based on the order of the nodes in the GFA file. Check this paper for more information.
  • Run odgi sort -Y to sort the graph in pan-genomic order.
• We recommend dense node ID, starting at 1 and end at the number of nodes +1. Memory efficient on multiple levels.

Prepare your graph (optional)

This is normally not needed if your graph is constructed by PGGB, Minigraph-Cactus or vg construct

# Convert string-based node IDs to numerical IDs
./target/release/gretl id2int -g /path/to/old_grapg.gfa -o /path/to/new_graph.gfa

# Sort the graph in pan-genomic order
odgi sort -Y -i /path/to/new_graph.gfa -o /path/to/new_graph_sorted.og
# Convert the ODGI file back to GFA
odgi view -i /path/to/new_graph_sorted.og -g > /path/to/new_graph_sorted.gfa

---

Plotting your results / Follow-along documentation

We have added python scripts to visualize the output of the different commands of this tool. The scripts are stored in the scripts directory. Almost all commands of gretl are covered, some even multiple times. For better understanding we added a follow-along markdown with examples, which highlights research questions and ideas can be answered.

---

Explanation

Since some of the commands run relative complex computation, we have added a detailed description of each subcommand in the doc directory, which can be found here. It covers how internal each command is structured, what is calculated and how this calculation is performed (very roughly).

---

Installation:

Github

git clone https://github.com/MoinSebi/gretl
cd gretl
cargo build --release

Running gretl:
A list of all subcommands is at the bottom

./target/release/gretl [subcommand] [options]

From Bioconda channel

Gretl is available on Bioconda. You need to install conda/mamba first. We recommend creating a new environment for gretl to avoid conflicts with other packages conda create -n gretl_env && conda activate gretl_env.

mamba install -c conda-forge -c bioconda gretl

---

Testing

We provide a small test suite to test the basic functionality of the tool.

cargo test

---

Performance

We tried to optimize the code as much as possible. Most steps are dependent on the number of nodes and the length of the paths. Runtime should be linear in most cases. All commands can be multithreaded, which can be controlled by the -t option.

---

Usage

---

Stats

Calculate statistics of a graph in GFA format. A list of all stats can be found here. Please consider using the --pansn option to group the paths by sample. Read more information about PanSN-spec here.

In general the stats command has two possible options:

1. Path-based statistics: Calculate statistics for each path in the graph (-p flag needed)
2. Graph-based statistics: Calculate statistics for the whole graph, including hybrid statistics based on path statistics (default). These hybrid statistics are the average and standard deviation of all path statistics. A full list of all statistics be found in paper directory in this repository.

Example

/// Graph-based + hybrid statistics
./gretl stats -g /path/to/graph.gfa -o /path/to/output.txt

/// Path-based statistics
./gretl stats -g /path/to/graph.gfa -o /path/to/output.path.txt -p

Result

• TSV or YAML file with statistics

---

id2int

Convert any string-based node identifier to numeric values. Afterward, use odgi sort -Y to sort the graph in pan-genomic order, which will create more meaningful statistics in gretl stats and is required in ````block´´´ subcommand (see above). Nevertheless, numerical node IDs are required by any gretl command. The new node identifiers will start at 1 and end at the number of nodes +1. More information can be found here.

Available options:

• -d, --dict <dict> Write a dictionary with the new and old IDs to a plain text file.

Example usage

./gretl id2int -g /path/to/graph.gfa -o /path/to/output.gfa -d /path/to/dict.txt

Result:

• GFA file with numerical node IDs

Important: This function will convert all node IDs in the graph. Additional data in tags will not be converted.

---

Node-list

Individual node statistics based on graph-related features. Statistics provided:

• Length
• Node Degree
• Depth
• Core

Comment
The information of the reported table can be used as a individual lookup or to create own window-like statistics (over nodes).

Example usage

./gretl node-list -g /path/to/graph.gfa -o /path/to/output.txt

Result

• TSV file output

| Node_id | Length | Core | Depth | ND | |---------|--------|------|-------|----| | 1 | 21176 | 1 | 1 | 0 | | 2 | 15530 | 1 | 1 | 0 | | 3 | 15530 | 1 | 1 | 0 | | 4 | 24351 | 1 | 1 | 0 | | 5 | 24367 | 1 | 1 | 0 | | 6 | 100 | 2 | 2 | 2 | | 7 | 1 | 1 | 1 | 1 | | 8 | 1 | 1 | 1 | 1 |

---

Core

Count the amount of sequence and the number of nodes found in each similarity level. The method calculates the similarity for each node and summarize for each possible level the number of nodes and the amount sequence.

Example usage

./gretl core -g /path/to/graph.gfa -o /path/to/output.txt

---

Path similarity (PS)

Calculate for each path the number of nodes and the amount of sequence at each similarity level.

Example usage

./gretl ps -g /path/to/graph.gfa -o /path/to/output.txt

Example output Core sequence/nodes are those which are traversed by all other samples as well (here: 5). Since nodes can be traversed multiple times, the amount of sequence and the number of nodes can be different in each path.
Type: N = Number of nodes, S = Amount of sequence [bp]

| Accession | Type | 0 | 1 | 2 | 3 | 4 | 5 | |------------|------|---|--------|------|-------|-------|--------| | ABQ_6.ChrX | N | 0 | 336 | 891 | 1785 | 6630 | 7655 | | BIH_4.ChrX | N | 0 | 278 | 764 | 1753 | 6592 | 7655 | | ABF_6.ChrX | N | 0 | 2181 | 1093 | 1206 | 5216 | 7655 | | BPN_2.ChrX | N | 0 | 1250 | 690 | 916 | 5170 | 7672 | | BCK_8.ChrX | N | 0 | 3275 | 948 | 1062 | 3734 | 7655 | | ABQ_6.ChrX | S | 0 | 47050 | 3792 | 12833 | 73540 | 597805 | | BIH_4.ChrX | S | 0 | 26389 | 2445 | 12195 | 73030 | 597805 | | ABF_6.ChrX | S | 0 | 33120 | 5969 | 12142 | 71593 | 597805 | | BPN_2.ChrX | S | 0 | 104353 | 5352 | 1650 | 9894 | 598957 | | BCK_8.ChrX | S | 0 | 53334 | 4054 | 2600 | 67558 | 597805 |

Bootstrap

We bootstrap different samples of the graph. We iterate from one sample to the maximum number of samples, each time bootstrapping n different combinations. At each iteration, we calculate the number of nodes and the amount of sequence in each similarity level. If you want to exclude speicifc nodes, you can use the --nodes option. The most important parameter is the number of bootstraps, which is defined by the --number option.

Available options:

• --nodes <nodes>Run bootstrap only on these nodes
• --number <number> Number of bootstrap for each number of genomes

Example usage

./gretl bootstrap -g /path/to/graph.gfa -o /path/to/output.txt -n 20

Example output

• Size: Number of samples bootstrapped
• Run: Which iteration of this bootstrap-level
• Type: N = Number of nodes, S = Amount of sequence
• 1-5: Number of nodes or amount of sequence in each similarity level (depends on the type)

| Size | Run | Type | 1 | 2 | 3 | 4 | 5 | |------|-----|------|-------|-------|-------|------|------| | 2 | 0 | N | 12238 | 10890 | 0 | 0 | 0 | | 2 | 1 | N | 7650 | 13368 | 0 | 0 | 0 | | 2 | 2 | N | 10165 | 11903 | 0 | 0 | 0 | | 3 | 0 | N | 7773 | 7263 | 9587 | 0 | 0 | | 3 | 1 | N | 8621 | 7833 | 8466 | 0 | 0 | | 3 | 2 | N | 4370 | 4041 | 13077 | 0 | 0 | | 4 | 0 | N | 6756 | 2420 | 6487 | 9325 | 0 | | 4 | 1 | N | 6227 | 2303 | 6249 | 9275 | 0 | | 4 | 2 | N | 7870 | 3085 | 7085 | 7858 | 0 | | 5 | 0 | N | 7315 | 2191 | 2240 | 6833 | 7655 |

---

Window (sliding, path)

Calculate statistics on a node level (graph- or path-based) and summarize them for each path in a sliding window approach. In detail: Iterate over the nodes of a path (window-like), summarize the stats of all nodes in the window and report a single value for each window.

Example Usage

./gretl window -g /path/to/graph.gfa -o /path/to/output.txt -s 1000 --step 100

Example output Table: Path in col1, similarity values on all the other values (each column is 1000 bp, going 100 bp steps)

| ABQ_6.ChrX | 5 | 5 | 5 | 5 | 5 | 5 | |-
