Xeeny

Framework For Building And Consuming Cross Platform Services In .Net Standard.

Cross Platform, Duplex, Scalable, Configurable, and Extendable

Table Of Content

• What Is Xeeny
• Nuget
• Features
• Terminology
• Get Started
  • Server Side
  • Client Side
• Duplex and Callback
  • Duplex Server
  • Duplex Client
• Instance Lifetime
  • Service Instance Lifetime
  • Callback Instance Lifetime
  • Initializing Created Instances
• Operations
• Managing The Connection
  • Access Connection From The Service
  • Access Connection From The Client
  • Connection Options
  • Connection Timeout
  • Connection Buffers
  • Keep Alive Management
• Serialization
• Security
• Logging
• Transports
• Performance
• Extend Xeeny
  • Custom Transport
  • Custom Protocol
• Samples

What is Xeeny

Xeeny is framework for building and consuming services on devices and servers that support .net standard.

With Xeeny you can host and consume services anywhere .net standard is able to work (e.g Xamarin android, Windows Server, ...). It is Cross Platform, Duplex, Multiple Transports, Asynchronous, Typed Proxies, Configurable, and Extendable

Nuget

Install-Package Xeeny

For extensions:
Install-Package Xeeny.Http
Install-Package Xeeny.Extentions.Loggers
Install-Package Xeeny.Serialization.JsonSerializer
Install-Package Xeeny.Serialization.ProtobufSerializer

Features

Current Features:

• Building and consuming services in .Net Standard
• Multiple Transports, You can mix transports
• Duplex connections
• Typed proxies
• Asynchronous, Scalable, and Lightweight
• Extendable, you can have your custom transport (e.g Behind bluetooth), custom protocol, and custom serialization

Comming:

• Integrating AspNetCore (Logger is done, next is DI, Kestrel, and Middleware)
• Streaming
• UDP transport
• P2P Framework

Terminology

• Contract: A shared interface between the Service and Client
• Service Contract: The interface that is referenced by the client to call remotely, and actually implemented on the server
• Callback Contract: The interface that is referenced by the service to call remotely, and actually implemented on the client
• Operation: Any method in a Contract is called Operation

Get Started

• Define service contract (an interface) shared between your client and server

public interface IService
{
    Task<string> Echo(string message);
}

Server Side

• Create the service that implements the contract, services without interfaces won't expose methods to clients

public class Service : IService
{
    public Task<string> Echo(string message)
    {
        return Task.FromResult(message);
    }
}

• Create ServiceHost using ServiceHostBuilder<TService> where <TService> is the service implementation
• Add Servers to the host using AddXXXServer methods
• Open the host

var tcpAddress = "tcp://myhost:9999/myservice";
var httpAddress = "http://myhost/myservice";
var host = new ServiceHostBuilder<Service>(InstanceMode.PerCall)
		.AddTcpServer(tcpAddress)
		.AddWebSocketServer(httpAddress);

await host.Open();

Client Side

• Create client connection connection using ConnctionBuilder<T>

var tcpAddress = "tcp://myhost/myservice";
var client = await new ConnectionBuilder<IService>()
			.WithTcpTransport(tcpAddress)
			.CreateConnection();

• Once the connection is created it is connected and now you can call the service remotely

var msg = await client.Echo("Hellow World!");

Duplex and Callback

• First define a callback contract (an interface) shared between your service and client to handle the callback

public interface ICallback
{
    Task OnCallback(string serverMessage);
}

• Callback contract methods must return void or Task as the server always invoke them as OneWay operations

Duplex Service

• In your service, optain the typed callback channel using OperationContext.Current.GetCallback<T>

public Service : IService
{
    public Task<string> Join(string name)
    {
        CallBackAfter(TimeSpan.FromSeconds(3));
        return Task.FromResult("You joined");
    }

    async void CallBackAfter(TimeSpan delay)
    {
        var client = OperationContext.Current.GetCallback<ICallback>();
        await Task.Delay((int)delay.TotalMilliseconds);
        await client.OnCallBack("This is a server callback");
    }
}

• Call WithCallback<T> on the builder

var host = new ServiceHostBuilder<Service>(InstanceMode.Single)
                .WithCallback<ICallback>()
                .AddTcpServer(address)
                .CreateHost();
await host.Open();

• For Duplex connections you will usually have your services PerConnection or Singleton *

Duplex Client

• Implement your callback contract in the client side

public class Callback : ICallback
{
    public void OnServerUpdates(string msg)
    {
        Console.WriteLine($"Received callback msg: {msg}");
    }
}

• Use DuplexConnectionBuilder to create the duplex client, note that it is generic class, the first generic argument is the service contract, while the other one is the callback implementation not the contract interface, so the builder knows what type to instantiate when the callback request is received.

var address = "tcp://myhost/myservice";
var client = await new DuplexConnectionBuilder<IService, Callback>(InstanceMode.Single)
                        .WithTcpTransport(address)
                        .CreateConnection();
await client.Join("My Name");

Instance Lifetime

Service Instance Lifetime

Xeeny defines three modes for creating service instances

• PerCall: A PerCall mode instructs the framework to create one instance of the service object for every client request, That is anytime any client invokes a method on the service a new instance is going to handle that request. Once the method is execute the instance is going to be collect by GC like any other out of scope objects.
• PerConnection: A PerConnection mode istructs the framework to create one instance of the service object for each client. That is every time a proxy is connected there is one instance for that client is created, This instance will last as long as the connection between the client and server is open. Once the connection is closed (Or dropped by the network) the instance is removed and becomes available for GC to collect.
• Single: A Singleton instance mode means that there is one instance of the service handles all requests from all clients, This is the typical chat room example. The instance will be removed when the host is closed.

You define the service instance mode using the InstanceMode enum when creating the ServiceHost

var host = new ServiceHostBuilder<Service>(InstanceMode.PerCall)
		...
		.CreateHost();
await host.Open();

Callback Instance Lifetime

When you create duplex connection you pass the callback type and InstanceMode to the DuplexConnectionBuilder. The InstanceMode acts the same way it does for the service when creating ServiceHost

• PerCall: Every callback from the service will be handled in new instance, the instance is subject to collection by GC once the callback method is done.
• PerConnection: All callbacks from the service to a connection created by that builder will have one instance to handle them, all callbacks to another connection created by that builder will have another callback instance, these instances are subject to collection by GC when the connection is closed or dropped by the network
• Single: All callbacks from the service to any connection created by that builder will be handeled by one instance.

Initializing Created Instances

• ServiceHostBuilder constructor has one overload that takes instance of the service type, This allows you to create the instance and pass it to the builder, the result is InstanceMode.Single using the object you passed
• Similar to ServiceHostBuilder, the DuplextConnectionBuilder takes an instance of the callback type allowing you to create the singleton yourself
• Instances that are PerCall and PerConnection are created by the framework, you still can initialize them after being constructed and before executing any method by listening to the events: ServiceHost<TService>.ServiceInstanceCreated event and DuplextConnectionBuilder<TContract, TCallback>.CallbackInstanceCreated
• Once AspNetCore Dependency System (IServiceCollection and IServiceResolver) are used you will be able to have easy DI.

host.ServiceInstanceCreated += service =>
{
    service.MyProperty  = "Something";
}
...
var builder = new DuplexConnectionBuilder<IService, Callback>(InstanceMode.PerConnection)
                    .WithTcpTransport(tcpAddress);

builder.CallbackInstanceCreated += callback =>
{
    callback...
}
var client = builder.CreateConnection();

Operations

• Two Way Operations: Methods by default are two way, even methods that return void or Task are two way methods. A two way method means that the method waits the service to finish executing the operation before it returns.
• One Way Operations: One way operations return when the server receives the m
