MeshInfo

A real-time web application for visualizing and monitoring Meshtastic mesh networks.

Overview

MeshInfo connects to one or more MQTT brokers receiving Meshtastic traffic and provides a modern web UI for exploring your mesh. It decodes protobuf and JSON messages in real time, stores everything in PostgreSQL, and serves it through a FastAPI backend and React frontend.

See a live instance at Central Valley Mesh.

Features

• Interactive Map -- Node positions on OpenStreetMap or Mapbox with hardware icons
• Chat -- View and search mesh text messages across channels, with CSV/JSON export
• Node Explorer -- Browse all nodes with filtering by status, hardware, role, and more
• Network Graph -- Visualize mesh topology with adjacency heatmaps and arc diagrams
• Neighbor View -- Inspect neighbor relationships and signal quality (SNR)
• Telemetry -- Device metrics, environment sensors, and power data per node
• Traceroutes -- Hop-by-hop path visualization between nodes
• MQTT Log -- Live stream of raw mesh traffic for debugging
• Discord Integration -- Bridge mesh messages and position updates to Discord channels
• Node Enrichment -- Augment node data from the MeshInfo network discovery service
• Reverse Geocoding -- Resolve node coordinates to human-readable locations
• Multi-topic MQTT -- Subscribe to multiple MQTT topics with tag-based filtering in the UI
• Channel-aware Chat -- Firmware 2.5+ channel hash support with configurable channel views

Architecture

MQTT Broker(s)  -->  MeshInfo Backend (Python / FastAPI / uvicorn)
                          |
                     PostgreSQL 16
                          |
                     MeshInfo Frontend (React 19 / TypeScript / Vite)
                          |
                     Caddy (reverse proxy, automatic HTTPS)

All components run as Docker containers orchestrated by Docker Compose.

Supported Message Types

• neighborinfo -- neighbor lists and SNR data
• nodeinfo -- hardware, firmware, and role information
• position -- GPS coordinates and altitude
• telemetry -- device, environment, and power metrics
• text -- chat messages
• traceroute -- hop-by-hop route data

Quick Start

Prerequisites

• Docker and Docker Compose
• An MQTT broker receiving Meshtastic traffic (or use a public one like mqtt.meshtastic.org)

1. Clone and configure

git clone https://github.com/MeshAddicts/meshinfo.git
cd meshinfo

# Backend config
cp config.toml.sample config.toml
# Edit config.toml -- set your MQTT broker, topics, mesh name, and node ID

# Frontend config
cp frontend/.env.sample frontend/.env
# Edit frontend/.env if you want to use Mapbox instead of OpenStreetMap

# MQTT broker config
cp mosquitto/config/mosquitto.conf.sample mosquitto/config/mosquitto.conf
# Edit mosquitto.conf -- add bridge connections to MQTT brokers for your region

# Reverse proxy
cp Caddyfile.sample Caddyfile
# Edit Caddyfile -- set your domain (FQDN) and email for automatic TLS

2. Start

docker compose up -d

MeshInfo will be available at https://your-domain (or http://localhost if using a local setup).

3. Update

git pull && docker compose pull && docker compose down && docker compose up -d

Configuration

The main configuration file is config.toml. Key sections:

| Section | Purpose | |---------|---------| | [broker] | MQTT connection, topics, channel hashes, decoders | | [server] | Node ID, base URL, timezone, enrichment, graph settings | | [storage.postgres] | PostgreSQL connection and pool settings | | [mesh] | Network name, region, coordinates, external tool links | | [integrations.*] | Discord bridge, reverse geocoding |

See config.toml.sample for all options with inline documentation.

For PostgreSQL-specific details, see POSTGRES.md.

Caddy / Reverse Proxy

The included Caddyfile.sample routes /api/* and /v1/* to the backend and everything else to the frontend. Caddy automatically provisions Let's Encrypt certificates when you use a public FQDN on ports 80/443.

If you use a different reverse proxy, point /api/* and /v1/* at the backend container (port 9000) and / at the frontend container (port 80).

Map Providers

MeshInfo supports two map providers, configured in frontend/.env:

• OpenStreetMap (default) -- no account needed
• Mapbox -- requires a Mapbox access token

Running Without Docker

Backend

Requires Python 3.12.4+ and a running PostgreSQL instance.

pip install -r requirements.txt
# Edit config.toml with storage.postgres.host = "localhost"
python main.py

Frontend

Requires Node.js 20.19+ and Yarn.

cd frontend
cp .env.sample .env
yarn install
yarn dev

Development

See CONTRIBUTING.md for development setup, project structure, and contribution guidelines.

Building Local Docker Images

# Build everything with docker-compose in dev mode
docker compose -f docker-compose-dev.yml up --build --force-recreate

# Or build images individually
scripts/docker-build.sh 0.0.1-dev

Releasing

Tag the release and push. GitHub Actions builds and publishes images to ghcr.io/meshaddicts/meshinfo and ghcr.io/meshaddicts/meshinfo-spa for both amd64 and arm64.

git tag v0.0.0 && git push && git push --tags

API

MeshInfo exposes a REST API used by the frontend. See API.md for endpoint documentation.

Community

Questions, feedback, or want to contribute? Join us on the Central Valley Mesh Discord.

If you run a public MeshInfo instance, we'd love to hear about it -- drop a note in Discord.

Related Projects

• Airframes / GitHub -- ADS-B, ACARS, VDL, HFDL, SATCOM, and AIS tracking

License

GNU General Public License v3.0
