BannerViewPager

前言

在开发中经常会遇到循环轮播图，之前的实现方式是在Activity中使用定时器控制轮播。后面想了想，看能不能把ViewPager2和定时器封装成自定义控件方便移植。然后就有了这个自定义控件。

效果

如何使用

gradle依赖

Project 的 settings.gradle 添加仓库

dependencyResolutionManagement {
    repositories {
        // ...
        maven { url 'https://jitpack.io' }
    }
}

Module 的 build.gradle 添加依赖框架

dependencies {
    implementation 'com.github.MattLjp:bannerViewPager:1.0.3'
}

基础用法

1. 在xml中添加控件

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <com.example.myapplication.banner.BannerViewPager
        android:id="@+id/viewpager2"
        android:layout_width="match_parent"
        android:layout_height="400dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent" />
</androidx.constraintlayout.widget.ConstraintLayout>

2. 继承BaseBannerAdapter实现适配器

class BannerAdapter : BaseBannerAdapter<Int, BannerAdapter.ViewHolder>() {

    override fun getLayoutId(viewType: Int) = R.layout.item_banner

    override fun onBind(holder: ViewHolder, data: Int, position: Int, pageSize: Int) {

        holder.imageView.setImageResource(data)
    }


    override fun createViewHolder(parent: ViewGroup, itemView: View, viewType: Int): ViewHolder {
        return ViewHolder(itemView)
    }

    class ViewHolder(itemView: View) : RecyclerView.ViewHolder(itemView) {
        var imageView: ImageView = itemView.findViewById(R.id.iv_banner)
    }
}

item_banner.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:gravity="center"
    android:orientation="vertical">

    <ImageView
        android:id="@+id/iv_banner"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:scaleType="fitXY" />
</LinearLayout>

3. 在Activity中配置和使用

class MainActivity : AppCompatActivity() {

    private lateinit var binding: ActivityMainBinding
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        binding = ActivityMainBinding.inflate(LayoutInflater.from(this))
        setContentView(binding.root)

        val adapter = BannerAdapter()
        binding.bannerViewpager
            .setAutoPlay(true)  //设置自动轮播
            .setCanLoop(true) //设置是否循环
            .setInterval(3000) //设置轮播间隔时间
            .seScrollDuration(1000) //设置滚动时长
            .setPageMargin(dpToPx(15)) //设置页边距
//            .setRevealWidth(dpToPx(35)) //一屏多页模式下两边页面显露出来的宽度
//            .addPageTransformer(ScaleTransformer()) //切换效果
            .setIndicatorSliderColor(
                R.drawable.dot_def,
                R.drawable.dot_selected
            )
            .setCanShowIndicator(true)
            .setAdapter(adapter)
            .create(
                listOf(
                    R.mipmap.b,
                    R.mipmap.c,
                    R.mipmap.d,
                    R.mipmap.e,
                    R.mipmap.f
                )
            )
    }

    private fun dpToPx(dip: Int): Int {
        return (0.5f + dip * Resources.getSystem().displayMetrics.density).toInt()
    }
}

在创建完成后，可以通过refreshData()方法，更新列表

切换效果可以继承ViewPager2.PageTransformer自己实现，当前预设了几种效果

ScaleTransformer

AlphaPageTransformer

DepthPageTransformer

RotateDownPageTransformer

RotateUpPageTransformer

RotateYTransformer

ZoomOutPageTransformer
