PyMieSim

PyMieSim is an open-source Python package for fast and flexible Mie scattering simulations. It supports spherical, cylindrical and core--shell particles and provides helper classes for custom sources and detectors. The project targets both quick single-scatterer studies and large parametric experiments.

Features

Solvers for spheres, cylinders and core--shell geometries.
Built-in models for plane wave and Gaussian sources.
Multiple detector types including photodiodes and coherent modes.
Simple data analysis with pandas DataFrame outputs.

Installation

PyMieSim is available on PyPI and Anaconda. Install it with:

.. code-block:: bash

pip install PyMieSim conda install PyMieSim --channels MartinPdeS

See the online documentation <https://martinpdes.github.io/PyMieSim/>_ for detailed usage and additional examples.

Quick example

Below is a short example computing the scattering efficiency of a sphere.

.. code-block:: python

from PyMieSim.experiment.scatterer_set import SphereSet
from PyMieSim.experiment.source_set import GaussianSet
from PyMieSim.experiment.polarization_set import PolarizationSet
from PyMieSim.experiment import Setup
from PyMieSim.units import ureg
import numpy as np

polarization = PolarizationSet(
    angles=[0] * ureg.degree
)

source = GaussianSet(
    wavelength=np.linspace(400, 2000, 500) * ureg.nanometer,
    polarization=polarization,
    optical_power=1e-3 * ureg.watt,
    numerical_aperture=0.2 * ureg.AU,
)

scatterer = SphereSet(
    diameter=[200, 300] * ureg.nanometer,
    material=[4 + 1j] * ureg.RIU,
    medium=[1] * ureg.RIU,
)

experiment = Setup(
    scatterer_set=scatterer,
    source_set=source
)
df = experiment.get("Qsca", "Qext")
df.plot(x="source:wavelength")

.. image:: https://github.com/MartinPdeS/PyMieSim/raw/master/docs/images/resonances.png :width: 1000 :align: center :alt: Scattering efficiency of a 200 nm sphere with refractive index 4.0.

Code structure

Here is the architecture for a standard workflow using PyMieSim:

.. image:: https://github.com/MartinPdeS/PyMieSim/raw/master/docs/images/code_structure.png :width: 1000 :align: center :alt: Code structure of a standard workflow using PyMieSim.

Building from source

For development or manual compilation, clone the repository and run:

.. code-block:: bash

git submodule update --init mkdir build && cd build cmake ../ -G"Unix Makefiles" sudo make install cd .. python -m pip install .

Testing

Run the unit tests with:

.. code-block:: bash

pip install PyMieSim[testing] pytest

Citing PyMieSim

If you use PyMieSim in academic work, please cite:

.. code-block:: none

@article{PoinsinetdeSivry-Houle:23, author = {Martin Poinsinet de Sivry-Houle and Nicolas Godbout and Caroline Boudoux}, journal = {Opt. Continuum}, title = {PyMieSim: an open-source library for fast and flexible far-field Mie scattering simulations}, volume = {2}, number = {3}, pages = {520--534}, year = {2023}, doi = {10.1364/OPTCON.473102}, }

Contact

For questions or contributions, contact martin.poinsinet.de.sivry@gmail.com <mailto:martin.poinsinet.de.sivry@gmail.com>_.
