Malkom

Malkom is an extensible and simple similarity graph generator for malware analysis aimed at helping analysts visualize and cluster sets of PE and ELF malware samples.

Malkom extracts all the metrics from the input samples. Then it uses the selected metric to compute the similarity between each pair of samples and generate a Graphviz graph showing the relationship between the samples. Edges are placed between samples that have the selected --metric above a certain --threshold value.

Note that most use cases and supported metrics in Malkom generate very dense graphs, so a set of 1.000 samples could really generate up to 500.000 edges. Malkom is designed solely for experimentation & analysis purposes; depending on your setup and sample set, Malkom is likely to use a lot of RAM.

Supported Metrics

• tlsh. TrendMicro's TLSH (PE)
• telfhash. TrendMicro's Telfhash (ELF)
• ssdeep. SSDeep (PE/ELF)
• imphash. Mandiant's Imphash (PE)
• elfsymbols. Symbol-Set Jaccard (ELF)
• peimports. Imports-Set Jaccard (PE)
• peexports. Exports-Set Jaccard (PE)
• overhash. Overhash is simply the SHA256 of the overlay, if present in the binary. (PE/ELF)

Some of these metrics (imphash and overhash) induce exact similarity values (100% or 0%) instead of percentages. Therefore, if using these metrics, any positive threshold will have the same effect. This doesn't mean that they can't be used for comparative analyses, and that's why they were included in the tool.

Setup

Malkom uses the dot command from Graphviz to render the graph, so you need Graphviz installed in your distro in order to export a visual representation of the graph. It may also be needed to install libfuzzy-dev in order to obtain required headers for ssdeep:

$ apt install graphviz libfuzzy-dev

Python dependencies are managed by pipenv. To make a new environment with all the dependencies run:

$ pipenv install

Usage

Whenever you want to run malkom in a new shell, you must activate the environment:

$ pipenv shell

And then run the following to compute the metrics and plot the graph in PDF:

$ ./malkom.py <OUTPUT_NAME> --plot --ext pdf --indir <SAMPLES_FOLDER> --metric <CHOSEN_EDGE_METRIC> --threshold <EDGE_THRESHOLD>

Where:

• <OUTPUT_NAME> is an arbitrary friendly name for your experiment that will be used to prefix the results in the output directory.
• <SAMPLES_FOLDER> is a directory with malware samples.
• <CHOSEN_EDGE_METRIC> is the selected metric to evaluate against the threshold to build graph edges.
• <EDGE_THRESHOLD> is the threshold to use to build graph edges. If the similarity between the metric values of each two samples is above the threshold then an edge will be inserted into the graph.

You might prefer to also use --write-mkm in the first run in order to cache the computed metrics for the samples set in the cache directory. Then you can use --mkm for subsequent plots to specify the pre-computed MKM file instead of using --indir.

Example:

$ ./malkom.py myexperiment --indir mysamplesdir --write-mkm
$ ./malkom.py myexperiment --mkm cache/myexperiment.mkm --plot --metric tlsh --threshold 90 --plot --ext pdf

If you provide --indir, --mkm and --write-mkm, the MKM file provided with --mkm will be incremented with the metrics computed from the --indir directory and saved into results/<OUTPUT_NAME>.mkm. This behavior can be used to build large MKM files containing useful metadata for multiple sets of samples, without having to keep the samples themselves in the disk. Example:

$ ./malkom.py myexperiment --indir newsamples --mkm cache/myexperiment.mkm --write-mkm

Optional Flags

• --outdir. Output directory (default: results).
• --plot. Plot graph from Graphviz dot file (default: False).
• --colors. Colorize nodes based in the provided JSON file mapping SHA256s to RGB colors (default: colors.json).
• --write-colors. Write color mappings in results directory based in the components found with the specified metric and threshold (default: False).
• --mkm. MKM file to use as input instead of extracting metrics from a directory of samples (default: None).
• --write-mkm. Save metrics information in MKM file (default: False).
• --write-gexf. Write graph in GEXF (Graph Exchange XML Format) in results directory (default: False).
• --stats. Compute statistics on the constructed graph (default: False).
• --isolates. Show isolated nodes - those without similarity to any other nodes (default: False).
• --layout-engine. Layout engine to use for graph plot (default: sfdp).
• --archs. Allowed architectures (default: None).
• --ext. Extension for Graphviz plot (default: png).
• --metadata. JSON file mapping SHA256s to metadata dictionary to import into the MKM. These metadata can be used for clustering or labelling (default: metadata.json). Read the Use cases section for more information on this option.
• --clusters. Cluster nodes by the "cluster" key from their metadata into Graphviz subgraphs (default: False).
• --groups. Show members of each connected component (default: False).
• --verbose. Enable verbose mode (default: False).

Use cases

Coloring the graph with ground-truth for malware families

You can specify custom fill/text colors for each SHA256 in the colors.json file to help visualize, for example, different families of malware. Besides that, if you don't care much about the specific colors used but you have a CSV with malware families for each SHA256 in your sample set, you can use the csv2colors.py utility to automatically generate a reasonable colors.json file from your families. Example:

malware-families.csv

SHA256,Family
f97d74ac49a75219ac40e8612a0ec0a829ed9daac2d913221115562c219c99b7,Enemybot
fd07ef316187f311bec7d2ff9eb793cc3886463ebae9445c9f89903b66727832,Enemybot
283bbfca166becfbaa701a28b973dbe4903732a69bc50a22d0879ddddfe7bf25,Mirai
fbaafdd070c20de4b0da48a37b950f968ffca16c354b9416b40e0727b854fd8d,Mirai
47832322d8314b87d1187e0aee9289649b86edc60e7de9ebc36ff5b6ddb92ee0,Mirai
...

$ python3 csv2colors.py malware-families.csv > colors.json

$ python3 malkom.py myexperiment --mkm cache/myexperiment.mkm --colors colors.json --metric telfhash --threshold 90 --plot

Comparing connected components with colors

When using --write-colors, Malkom will generate a color for each connected component in the final graph and save the colors into the results/<output_name>.colors.json file. The colors JSON can then be specified with the --colors flag to use the same node colors in subsequent plots.

For example, if you already have an MKM file with your precomputed metrics, you can compare ssdeep and tlsh results with this sequence:

$ ./malkom.py myexperiment --mkm cache/myexperiment.mkm --write-colors --metric ssdeep --threshold 90
$ ./malkom.py myexperiment --mkm cache/myexperiment.mkm --colors results/myexperiment.colors.json --metric tlsh --threshold 90 --plot

You can also plot the same metric with different thresholds for colors and edges, which can be useful to determine variants of malware families:

$ ./malkom.py myexperiment --mkm cache/myexperiment.mkm --write-colors --metric tlsh --threshold 90
$ ./malkom.py myexperiment --mkm cache/myexperiment.mkm --colors results/myexperiment.colors.json --metric tlsh --threshold 80 --plot

Using metadata to enrich the graph with custom labels and clusters

If you have strings that you want to use to cluster the resulting graph, such as ground truths for the malware family of each sample, you can specify them in the cluster key of each SHA256 in the metadata dictionary. Then you can plot the graph with --clusters --layout-engine fdp --plot to get a graph where the nodes with the same cluster key are grouped together.

If you want to label the nodes with custom labels instead of the prefix of their hashes, you can also specify the labels in the label keys of the metadata dictionary.

Example:

{
    "SHA256_OF_SAMPLE_1": {
        "cluster": "Bashlite",
        "label": "MySample1"
    },
    "SHA256_OF_SAMPLE_2": {
        "cluster": "EnemyBot",
        "label": "MySample2"
    },
    ...
}

$ python3 ./malkom.py myexperiment --mkm cache/myexperiment.mkm --colors colors.json --metric telfhash --threshold 90 --clusters --layout-engine fdp --plot

Computing graph statistics

If you provide the --stats flag, Malkom will compute the following statistics and store them in results/<output_name>.stats.json:

• Total nodes per component (n_nodes_per_component)
• Average nodes per component (avg_nodes_per_component)
• Average similarity per component (avg_weights_per_component)
• Variance of similarity per component (var_weights_per_component)
• Average clustering coefficient (avg_clust)
• Number of isolate nodes (n_isolates)
• Number of maximal cliques (n_maximal_cliques)

Analyzing the graph with 3rd-party tools

By default, Malkom will generate the .dot file for the graph in results/<output_name>.dot. You can omit the --plot flag if you don't want to plot the graph with Malkom, and then load the .dot in graph analysis tools such as Gephi or Cytoscape. Exporting the graph in GEXF format into results/<output_name>.gexf is also supported by specifying the --write-gexf flag.

Using MKM files for external analy
