MFC
Exascale multiphase flow solver — 2025 Gordon Bell Prize Finalist | 200T grid points on 43K+ GPUs
Install / Use
/learn @MFlowCode/MFCREADME
<div align="center"> <video src="https://github.com/user-attachments/assets/4ad20dc2-0920-4ba0-9c95-0949768f8332" width="700" controls autoplay loop muted playsinline></video> </div>2025 Gordon Bell Prize Finalist - MFC simulates compressible multi-phase flows at exascale, using Fypp metaprogramming in ~40K lines of Fortran. It conducted the largest known public CFD simulation at 200 trillion grid points and 1 quadrillion degrees of freedom, scaling ideally to >43K AMD APUs on El Capitan and >33K AMD GPUs on Frontier.
Why MFC?
- Exascale GPU performance - Ideal weak scaling to 43K+ GPUs. Near compute-roofline behavior. Compile-time case optimization for up to 10x speedup.
- Compact codebase - ~40K lines of Fortran with Fypp metaprogramming. Small enough to read and modify; powerful enough for Gordon Bell.
- Native multi-phase - 4, 5, and 6-equation models, phase change, surface tension, bubble dynamics, and Euler-Lagrange particle tracking, all built in.
- Portable - NVIDIA and AMD GPUs, CPUs, laptops to exascale. Docker, Codespaces, Homebrew, and 16+ HPC system templates.
- Tested - 500+ regression tests per PR with line-level coverage across GNU, Intel, Cray, and NVIDIA compilers.
- Truly open - MIT license, active Slack, and responsive development team.
If MFC is useful to your work, please ⭐ star the repo and cite it!
Try MFC
| Path | Command |
| --- | --- |
| Codespaces (fastest) 💨 | Open a Codespace - pre-built, zero install |
| Docker 🐳 | docker run -it --rm --entrypoint bash sbryngelson/mfc:latest-cpu |
| Homebrew (macOS) 🍺 | brew install mflowcode/mfc/mfc |
| From source 💻 | git clone https://github.com/MFlowCode/MFC && cd MFC && ./mfc.sh build -j $(nproc) |
Your first simulation:
./mfc.sh run examples/3D_shockdroplet/case.py -n $(nproc)
Visualize the output in examples/3D_shockdroplet/silo_hdf5/ with ParaView, VisIt, or your favorite tool.
For detailed build instructions (Linux, macOS, Windows/WSL, HPC clusters), see the Getting Started guide.
MFC is developed by the Computational Physics Group at Georgia Tech and collaborators. Get in touch with <a href="mailto:shb@gatech.edu">Spencer</a> if you have questions! We have an active Slack channel and development team. MFC has high- and low-level documentation, visualizations, and more on its website.
Examples
MFC ships with 137+ example cases.
Here is a high-Mach flow over an airfoil (see examples/2D_ibm_airfoil/):
And a high-amplitude acoustic wave reflecting and emerging through a circular orifice:
<p align="center"> <img src="docs/res/orifice.png" alt="Acoustic wave through orifice" width="700"/><br/> </p>Toolchain
| Command | Description |
|---------|-------------|
| ./mfc.sh build | Build MFC and its dependencies |
| ./mfc.sh run case.py | Run a simulation case (interactive or batch: SLURM/PBS/LSF) |
| ./mfc.sh test | Run the test suite |
| ./mfc.sh validate case.py | Check a case file for errors before running |
| ./mfc.sh new my_case | Create a new case from a template |
| ./mfc.sh clean | Remove build artifacts |
| ./mfc.sh interactive | Launch interactive menu-driven interface |
Run ./mfc.sh <command> --help for detailed options, or see the full documentation. Tab completion for bash and zsh is auto-installed after you have run ./mfc.sh generate (or any non-new command) at least once. Play with the examples in examples/ (showcased here).
Is this really exascale?
MFC weak scales to the full machines on El Capitan (MI300A), Frontier (MI250X), and Alps (GH200) with near-ideal efficiency. MFC is a SPEChpc benchmark candidate, part of the JSC JUPITER Early Access Program, and used OLCF Frontier and LLNL El Capitan early access systems.
<p align="center"> <picture> <source media="(prefers-color-scheme: dark)" srcset="docs/res/weakScaling/weakscaling-dark.png"/> <source media="(prefers-color-scheme: light)" srcset="docs/res/weakScaling/weakscaling.png"/> <img src="docs/res/weakScaling/weakscaling.png" alt="Weak scaling on El Capitan, Frontier, and Alps" width="400"/> </picture> </p>What else can this thing do?
Physics
- 1-3D
- Compressible
- Low Mach number treatment available
- Multi- and single-component
- 4, 5, and 6 equation models for multi-component/phase features
- Kapila and Allaire models 5-equation models
- Multi- and single-phase
- Phase change via p, pT, and pTg schemes
- Grids
- 1-3D Cartesian, cylindrical, axisymmetric.
- Arbitrary grid stretching for multiple domain regions.
- Complex/arbitrary geometries via immersed boundary method
- STL geometry files supported
- Surface tension for multiphase cases
- Sub-grid bubble dynamics
- Euler-Euler volume-averaged bubble models
- Euler-Lagrange particle tracking
- Quadrature-based moment methods (QBMM)
- Viscous effects (high-order accurate representations)
- Hypoelastic and hyperelastic material models
- Ideal and stiffened gas equations of state
- Body forces
- Acoustic wave generation (one- and two-way sound sources)
- Chemistry and multi-species transport via Pyrometheus
- Magnetohydrodynamics (MHD)
- Relativistic Magnetohydrodynamics (RMHD)
Numerics
- Shock and interface capturing schemes
- First-order upwinding
- MUSCL (order 2)
- Slope limiters: minmod, monotonized central, Van Albada, Van Leer, superbee
- WENO reconstructions (orders 3, 5, and 7)
- WENO variants: WENO-JS, WENO-M, WENO-Z, TENO
- Monotonicity-preserving reconstructions
- Reliable handling of large density ratios
- Exact and approximate (e.g., HLL, HLLC, HLLD) Riemann solvers
- Boundary conditions
- Periodic, reflective, extrapolation/Neumann
- Slip and no-slip
- Thompson-based characteristic BCs: non-reflecting sub/supersonic buffers, inflows, outflows
- Generalized characteristic relaxation boundary conditions
- Runge-Kutta orders 1-3 (SSP TVD), adaptive time stepping
- RK4-5 operator splitting for Euler-Lagrange modeling
- Interface sharpening (THINC-like)
- Information geometric regularization (IGR)
- Shock capturing without WENO and Riemann solvers
Large-scale and accelerated simulation
- GPU compatible on NVIDIA ([P/V/A/H]100, GH200, etc.) and AMD (MI[1/2/3]00+) GPU and APU hardware
- Ideal weak scaling to 100% of the largest GPU and superchip su
