Lux

A distributed multi-GPU system for fast graph processing.

Prerequisites

• CUDA is used to implemented Lux.

• CUB is used as an external submodule for Lux's tasks.

• Legion is the underlying runtime for launching tasks and managing data movement.

• (Optional) GASNet is used for multi-node executions. (see installation instructions)

After you have cloned Lux, use the following command lines to clone CUB and Legion.

git submodule init
git submodule update

Compilation

• Download Lux source code:

# Using git to download Lux
git clone --recursive https://github.com/LuxGraph/Lux

• Compile a Lux application (e.g., PageRank):

cd pagerank
make clean; make -j 4

• To build a distributed version of Lux, set USE_GASNET flag and rebuild:

make clean
USE_GASNET=1 make -j 4

Running code

The applications take an input graph as well as several runtime flags starting with -ll:. For example:

./pagerank -ll:gpu 4 -ll:fsize 12000 -ll:zsize 20000 -file twitter-2010.lux -ni 10
./components -ll:gpu 1 -ll:fsize 6000 -ll:zsize 6000 -file indochina.lux -verbose -check
./sssp -ll:gpu 2 -ll:fsize 12000 -ll:zsize 20000 -file twitter-2010.lux -start 0

• -ll:gpu: number of GPU processors to use in an execution
• -ll:fsize: size of framebuffer memory for each GPU (in MB)
• -ll:zsize: size of zero-copy memory (pinned DRAM with direct GPU access) on each node (in MB)
• -file: path to the input graph
• -ni: number of iterations to perform
• -start: root vertex for SSSP
• -verbose: show detailed task execution information
• -check: perform correctness check after computation

Graph Format

Lux uses compressed sparse column (CSC) graph in binary format. The specific format is as follows in binary:

<nv>
<ne>
<c0>
<c1>
...
<c(nv-1)>
<e0>
<e1>
...
<e(ne-1)>

<nv> and <ne> denote the number of vertices and direct edges in the graph. The CSC format starts with a sequence of offsets for the vertices in the CSC format, followed by a sequence of directed edges ordered by their target vertex. The offset <c(i-1) and <c(i)> refer to the start and end points of a contiguous block of in-edges for vertex i. More specifically, <e(c(i-1))>...<e(c(i)-1)> is the collection of all in-neighbors for vertex i. For weighted graphs, the weights are stored after the edge sources.

Some example graphs in Lux format are as follows.

| Graph | NV | NE | Weighted | |-----------------------------------------------------------------|-------------|---------------|--------------| | Hollywood | 1,139,905 | 57,515,616 | | | Indochina | 7,414,866 | 194,109,311 | | | Twitter-2010 | 41,652,230 | 1,468,365,182 | | | RMAT27 | 134,217,728 | 2,147,483,648 | | | Amazon | 3,376,972 | 11,676,082 | Yes | | NetFlix | 497,959 | 200,961,014 | Yes |

Publication

Zhihao Jia, Yongkee Kwon, Galen Shipman, Pat McCormick, Mattan Erez, and Alex Aiken. A Distributed Multi-GPU System for Fast Graph Processing. PVLDB 11(3), 2017.
