Hank is a very fast and very compact distributed key-value NoSQL database that we built and use at LiveRamp. Read queries are guaranteed to execute fewer than 2 disk seeks at all times, and to perform 1 network call on average. All disk write operations are strictly sequential to achieve high throughput updates (millions per second per node). Block compression of values, and an on-disk flyweight pattern provide compactness. Hank is fully distributed and fault tolerant. Data is consistently hashed and re-allocated automatically. It horizontally scales to terabyte and petabyte-sized datasets with billions or trillions of records. Range queries and random writes are not supported by design, for simplicity and performance.

Hank provides linear scalability, a no single point of failure design, strives for compact on-disk and over-the-network representations, as well as for consistent performance in constrained environments such as very high data-to-RAM ratios (1000:1 and more) and low remaining disk space. Hank was inspired by Amazon’s DynamoDB and shares a few design characteristics with LinkedIn’s Voldemort.

Hank leverages ZooKeeper for coordination, metadata management, monitoring and notifications, Hadoop for external parallel indexing and intermediate data storage, Thrift for cross-language client-server services, and MapReduce/Cascading to interface with user code and load data.

When it comes to the CAP theorem, Hank provides A (Availability) and P (Partitioning) but only eventual Consistency.

Performance

Performance is very dependent on hardware, and I/O and CPU overheads are kept to a strict minimum. Hank performs either one or two disk seeks per request that does not hit the cache, no request will ever require three disk seeks. Therefore random read request latency will be bounded by the time it takes to perform two disk seeks on the drives, which is usually around a couple of milliseconds with an empty cache on modern spinning disks, sometimes much less. Random read throughput can easily hit tens of thousands of requests per second per node.

Incremental batch write throughput is also limited by hardware, more specifically by how much data the installation can stream over the network and write to disk (strictly sequentially, random writes are entirely avoided), which is probably around a couple hundreds of megabytes per second per node which, depending on the size of the values used, can translate to millions or hundreds of millions of key-values pairs written per second per node.

Additionally, Hank is not very chatty. Random read requests perform only one call over the network and communicate directly with a server that holds the requested key. There is no need for synchronization, no master node, no back-and-forth, and no agreement protocol at query time.

Why we built Hank

We started building Hank in 2010, taking inspiration from design decisions of projects such as Amazon’s DynamoDB and LinkedIn’s Voldemort. We felt that our use case was specific enough to start experimenting and optimizing for it. The Hank project is the result of those efforts and has been very successful internally, achieving high-performance random reads, massive batch writes, with more than 99.9% availability during its first year in our production environment. Hank is used for all of LiveRamp’s random access needs when it comes to large datasets.

Authors

The authors of Hank are Thomas Kielbus and Bryan Duxbury.

Distribution

Some tips helpful when configuring domains can be found here.

You can either build Hank from source as described below, or pull the latest snapshot from Sonatype Snapshots. Add the repo:

<repository>
  <id>sonatype-snapshots</id>
  <url>http://oss.sonatype.org/content/repositories/snapshots</url>
  <layout>default</layout>
  <releases>
    <enabled>false</enabled>
  </releases>
  <snapshots>
    <enabled>true</enabled>
    <updatePolicy>always</updatePolicy>
  </snapshots>
</repository>

Then, add the dependency:

<dependency>
    <groupId>com.liveramp</groupId>
    <artifactId>hank</artifactId>
    <version>1.0-SNAPSHOT</version>
</dependency>

NOTE: Delivery of releases to Maven Central is coming soon!

To build hank from source and generate the jar in target/:

> mvn package

To run the test suite locally:

> mvn test

License

Copyright 2014 LiveRamp

Licensed under the Apache License, Version 2.0

http://www.apache.org/licenses/LICENSE-2.0

Key characteristics

A distributed key-value NoSQL database

Hank is a schema-less key-value database. It is conceptually similar to a distributed hash map. Keys and values are simply unstructured byte arrays, and there is no query language. It is designed to run on clusters of commodity hardware. Key-value pairs are transparently partitioned across a configurable number of partitions and fully distributed and replicated across nodes for scalability and availability. Also, data is automatically redistributed upon detected node failure. Data distribution is based on rendezvous hashing, a technique similar to consistent hashing to minimize the cost of rebalancing data across the cluster.

As an API, Hank only supports random read requests (retrieving the value for a given key) and incremental batch writes updates (loading a large set of key-value pairs, overwriting previous values, and optionally clearing out old entries that have not been updated). Random writes of single key-value pairs are not supported by design, for performance and simplicity. If your use case requires performant random writes, Hank is not well suited to it.

The typical architecture layout involves dedicated Hank nodes which run a server process, maintain indexed key-value pairs on disk, and maintain a partial index and often-queried entries in main memory cache. Those Hank servers respond to read requests (from clients), and batch write update requests (from the system coordinator process).

Indexing is meant to be performed externally, in the sense that source data is maintained and indexed by other nodes (typically a Hadoop cluster) before being streamed to the actual Hank servers to be persisted. This setup provides good flexibility and great scalability. Also, separating the intensive indexing workload from servers that are answering time-sensitive random read requests results in more predictable performance from the point of view of clients.

Clients interact directly with Hank servers when performing read requests (there is no master node). All required metadata (such as location of key-value pairs, available nodes, etc) is stored in the ZooKeeper cluster, and the provided Hank smart client is able to perform load balancing across servers and replicas, query retries, record caching, strictly locally, without having to communicate with any other node besides the Hank node from which the key-value pair is retrieved and the client’s ZooKeeper touch-point. Hank servers are built as a Thrift service, which means that they can be accessed directly from a variety of languages.

Very low latency random read requests

As stated earlier, Hank is optimized for satisfying read requests (retrieving the value corresponding to a random key) with very low latency. Domains (tables) use configurable storage engines that specify the on-disk and in-memory representation of key-value pairs and strategies for reading and writing them.

Two storage engines are provided with Hank, one designed for variable-length values (which guarantees that read requests will perform only exactly two disk seeks on cache miss), and one designed for fixed-length values (which guarantees read requests in exactly one disk seek on cache miss). No request will ever require three disk seeks. This is achieved by proactively indexing data externally, maintaining a partial index in main memory, and (in the case of variable-length values), a full index on disk. Depending on your hardware, this results in random read request latency on the order of a few milliseconds to sub-millisecond.

Caching

Hank is meant to be fast regardless of cache state, but it employs a few caching mechanisms to further speed up random read requests, as well as a simple load balancing hint to improve cache performance. The performance improvement obviously depends on access patterns, but we have seen production applications with a 20% client-side cache hit rate and a 50% server-side cache hit rate, resulting in a large percentage of read queries being fulfilled in much less than 0.1 milliseconds.

Server-side OS-level cache

Hank servers benefit very heavily from OS-level disk cache and are an example of one of those applications where the OS-provided caching resources and algorithms will outperform most application-level approaches. Because indices and values are stored in flat files on disk at specific offsets, requesting the same key-value pair twice will hit your OS-level disk page cache and be retrieved instantly. (Because read and writes do not happen concurrently on any given Hank node, cached pages do not need to get invalidated.) For this reason, a server-side application cache is not necessary, as the OS-level cache can already transparently allocate all of the node’s remaining main memory to the Hank query cache, and is very performant.

Server-side application-level cache
