ViTST

This is an official implementation of the NeurIPS2023 paper: "Time Series as Images: Vision Transformer for Irregularly Sampled Time Series".

Overview

We consider the irregularly sampled multivariate time series modeling from a whole new perspective: transforming irregularly sampled time series into line graph images and adapting powerful vision transformers to perform time series classification in the same way as image classification. With a few lines of code to transform the time series into line graph images, any vision model can be used to handle any type of time series.

<!-- ![Raindrop idea] --> <!-- (images/fig1.png "Idea of Raindrop.") --> <p align="center"> <img src="pics/illustration.png" width="720" align="center"> </p>

Results

With such a simple idea, our approach significantly outperforms highly specialized SoTA algorithms: | Methods | P19 | | P12 | | PAM | | | | |:----------:|:-----------:|:---------:|:-----------:|:---------:|:-----------:|:----------:|:-------:|:-------:| | | AUROC | AUPRC | AUROC | AUPRC | Accuracy | Precision | Recall | F1 score| | Transformer| 80.7±3.8 | 42.7±7.7 | 83.3±0.7 | 47.9±3.6 | 83.5±1.5 | 84.8±1.5 | 86.0±1.2| 85.0±1.3| | Trans-mean | 83.7±1.8 | 45.8±3.2 | 82.6±2.0 | 46.3±4.0 | 83.7±2.3 | 84.9±2.6 | 86.4±2.1| 85.1±2.4| | GRU-D | 83.9±1.7 | 46.9±2.1 | 81.9±2.1 | 46.1±4.7 | 83.3±1.6 | 84.6±1.2 | 85.2±1.6| 84.8±1.2| | SeFT | 81.2±2.3 | 41.9±3.1 | 73.9±2.5 | 31.1±4.1 | 67.1±2.2 | 70.0±2.4 | 68.2±1.5| 68.5±1.8| | mTAND | 84.4±1.3 | 50.6±2.0 | 84.2±0.8 | 48.2±3.4 | 74.6±4.3 | 74.3±4.0 | 79.5±2.8| 76.8±3.4| | IP-Net | 84.6±1.3 | 38.1±3.7 | 82.6±1.4 | 47.6±3.1 | 74.3±3.8 | 75.6±2.1 | 77.9±2.2| 76.6±2.8| | DGM^2-O | 86.7±3.4 | 44.7±11.7 | 84.4±1.6 | 47.3±3.6 | 82.4±2.3 | 85.2±1.2 | 83.9±2.3| 84.3±1.8| | MTGNN | 81.9±6.2 | 39.9±8.9 | 74.4±6.7 | 35.5±6.0 | 83.4±1.9 | 85.2±1.7 | 86.1±1.9| 85.9±2.4| | Raindrop | 87.0±2.3 | 51.8±5.5 | 82.8±1.7 | 44.0±3.0 | 88.5±1.5 | 89.9±1.5 | 89.9±0.6| 89.8±1.0| | ViTST | 89.2±2.0|53.1±3.4|85.1±0.8|51.1±4.1|95.8±1.3|96.2±1.3|96.1±1.1| 96.5±1.2|

In the rigorous leave-sensors-out setting where a portion of variables is omitted during testing, our method exhibits strong robustness against varying degrees of missing observations, achieving an impressive improvement over leading specialized baselines:

Figure: Performance in leave-fixed-sensors-out and leave-random-sensors-out settings on PAM dataset. The x-axis is the "missing ratio" which denotes the ratio of masked variables.

Getting Started

We conduct experiments on three irregular time series datasets P19, P12, and PAM, and several regular time series datasets from UEA & UCR Time Series Classification Repository.

Irregular Time Series Datasets

We use the data processed by Raindrop.

The raw data can be found at:

(1) P19: https://physionet.org/content/challenge-2019/1.0.0/

(2) P12: https://physionet.org/content/challenge-2012/1.0.0/

(3) PAM: http://archive.ics.uci.edu/ml/datasets/pamap2+physical+activity+monitoring

The processed datasets can be obtained at:

(1) P19 (PhysioNet Sepsis Early Prediction Challenge 2019) https://doi.org/10.6084/m9.figshare.19514338.v1

(2) P12 (PhysioNet Mortality Prediction Challenge 2012) https://doi.org/10.6084/m9.figshare.19514341.v1

(3) PAM (PAMAP2 Physical Activity Monitoring) https://doi.org/10.6084/m9.figshare.19514347.v1

Follow these two steps to create the images for each dataset:

1. Get the processed data, unzip them, and put the files in dataset folder.
2. Run the following commands in turn to create the images:
   1. cd dataset/P12data/, python ConstructImage.py
   2. cd dataset/P19data/, python ConstructImage.py
   3. cd dataset/PAMdata/, python ConstructImage.py

We have also provided the created images at https://drive.google.com/drive/folders/1tBkEcU9vqjbLvRqfevkbQOw4-7XcURXE?usp=drive_link

Download the data, unzip the data, and put them in the corresponding directory. For example, put all the directories obtained by unzipping the P12_images.zip under the ./datasets/P12data/processed_data/ directory.

Regular Time Series Datasets

You can download the datasets at http://www.timeseriesclassification.com/aeon-toolkit/Archives/Multivariate2018_ts.zip.

Create a folder Classification in the TSRAdara folder. Run ConstructDataset.py to create the images.

Training

Before started, remember to insert your project directory into the system path by replacing the PROJECT_PATH in sys.path.insert(0, 'PROJECT_PATH/code') with your own project path.

For the dataset containing static features, such as P19 and P12, go to the code/Vision-Text/ folder and run the script vtcls_script.sh to start training:

cd code/Vision-Text/
sh vtcls_script.sh

For the other datasets, go to the code/Vision/ folder and run the script imgcls_script.sh to start training:

cd code/Vision/
sh imgcls_script.sh

<!-- ### Self-supervised learning If you want to self-supervised learning pretrain the model, go to the ```code/Vision/``` folder and run the script ```imgmim_script.sh``` to start training: ``` cd code/Vision/ sh imgmim_script.sh ``` -->

Run baseline methods

We use the code provided by Raindrop. The code for the following baseline methods are placed in dataset/raindrop folder: Transformer, Trans-mean, GRU-D, SeFT and mTAND. See details of these baselines in our paper.

Starting from root directory dataset/raindrop, you can run models as follows:

• Raindrop

python Raindrop.py

• Transformer

cd baselines
python Transformer_baseline.py

• Trans-mean

cd baselines
python Transformer_baseline.py --imputation mean

• GRU-D

cd baselines
python GRU-D_baseline.py

• SeFT

cd baselines
python SEFT_baseline.py

• mTAND

cd baselines/mTAND
python mTAND_baseline.py

• IP-Net

cd baselines/IP_Net/src
python IP_Net_baseline.py

• MTGNN

cd baselines
python MTGNN_baseline.py

• DGM2-O

cd baselines
python DGM2_baseline.py

<!-- ## Acknowledgement We appreciate Huggingface and the following github repo very much for the valuable code base and datasets: https://github.com/mims-harvard/Raindrop https://github.com/gzerveas/mvts_transformer -->

Citations

if you found this repo useful, please consider citing our paper:

@article{li2023time,
  title={Time Series as Images: Vision Transformer for Irregularly Sampled Time Series},
  author={Li, Zekun and Li, Shiyang and Yan, Xifeng},
  journal={arXiv preprint arXiv:2303.12799},
  year={2023}
}
