Ballistic Penetration System

Advanced physics-based bullet penetration system for Godot 4 that simulates realistic projectile behavior through various materials. The system calculates damage reduction based on material thickness, hardness, and penetration depth. Uses raycasting, making it suitable for hitscan weapons.

https://github.com/user-attachments/assets/93f6dd95-38ff-462b-9120-626388da3e35

Key Features:

• Material-based Physics: Different penetration properties for wood, metal, concrete, etc.
• Thickness-aware Damage: Damage scales with material thickness and density
• Multi-layer Penetration: Bullets can penetrate multiple objects in sequence
• Performance Optimized: Efficient collision detection and raycasting
• Customizable: Easy to configure material properties and penetration rules, with code that can be easily modified to add additional features like ricochet

Performance

Performance-optimized for real-time use. Benchmark results (3 penetration levels):

• 1024 projectiles × 3 penetrations — ~45–49 ms/frame
• 512 projectiles × 3 penetrations — ~12.9–22 ms/frame
• 8 projectiles × 3 penetrations — ~0.37 ms/frame
• 1 projectile × 3 penetrations — ~0.070–0.130 ms/frame

Note: Higher penetration count require more calculations (for rays and other parameters). This dependency is non-linear, similar to the relationship with the number of shots per frame.

Note: Benchmarking was performed inside the editor

Usage

Basic Setup

1. Add the penetration system script or scene (more flexibility) as an autoload/singleton in your project
2. Configure material properties in the penetration_data dictionary
3. Assign materials to your objects. You can do this in two ways:
   • Via code: collider.set_meta(&"material", &"wood")
   • Via the Inspector: Add a meta property named "material" with StringName type to your scene objects

Basic Implementation

# Simple firing example
# G_PenetrationSystem - autoload/singleton
@onready var ray_cast_3d: RayCast3D = $path  # or unique name %name

func _shoot():
    var origin: Vector3 = self.global_position
    var direction: Vector3 = PenetrationSystem.get_raycast_global_direction(ray_cast_3d)

    var _damage : float = 20.0 # Base damage
    var _distance : float = 20.0 # Max distance
    var _bullet_power : float = 1.0
    var _max_penetrations_count : int = 3

    # Setup parametres
    G_PenetrationSystem.setup_bullet_params(_damage, _distance, _bullet_power, _max_penetrations_count)

    # Call the penetration system
    G_PenetrationSystem.fire_bullet(origin, direction, _max_penetrations_count, G_PenetrationSystem.penetration_data)

Advanced Usage

# Custom material configuration
# Materials can be configured directly in PenetrationSystem or passed as parameter
# G_PenetrationSystem - autoload/singleton
var custom_materials = {
    "glass": {
        &"max_thickness": 0.8, # Maximum penetration thickness of one object
        &"damage_multiplier": 0.9, # Base Penetration Damage Multiplier
        &"penetration_cost": 0.2 # Hardness of the material, how much the bullet's force and damage will decrease after penetration
    },
    "armor": {
        &"max_thickness": 0.05,
        &"damage_multiplier": 0.1,
        &"penetration_cost": 5.0
    }
}

# Option 1: Configure directly in the singleton
G_PenetrationSystem.penetration_data = custom_materials

# Option 2: Pass as parameter when firing
func _shoot_advanced():
    var origin : Vector3 = self.global_position
    var direction : Vector3 = PenetrationSystem.get_raycast_global_direction(ray_cast_3d)

    var _damage : float = 20.0 # Base damage
    var _distance : float = 20.0 # Max distance
    var _bullet_power : float = 1.0
    var _max_penetrations_count : int = 3

    # Setup parametres
    G_PenetrationSystem.setup_bullet_params(_damage, _distance, _bullet_power, _max_penetrations_count)

    # Call the penetration system
    G_PenetrationSystem.fire_bullet(origin, direction, _max_penetrations_count, custom_materials)

Damage Handling

Implement the take_damage method in your objects:

func take_damage(damage: float, hit_position: Vector3):
    health -= damage
    # Add visual effects, sound, etc.
    if health <= 0:
        destroy()

Realistic Simulation:

• Energy Loss Based on Material Hardness: Bullets lose energy proportionally to the hardness of penetrated materials
• Progressive Damage Reduction: Damage decreases with each successive penetration
• Smart Termination: Automatic stopping when damage becomes negligible to optimize performance
• Advanced Geometry Support: Works with complex collision shapes and CSG geometry

License

MIT License - see LICENSE file for details.
