PSADT.WIMFile

Extension for PowerShell App Deployment Toolkit to create and handle .WIM files.

Features

• Creates WIM files from your Files directory by default.
• Maximum compression by default.
• Does not requires administrative rights to mount (extracts if can't mount).
• Does not requires administrative rights to create (requires wimlib).
• Can extract to UNC Path.
• Creates remediation scheduled tasks if mount/dismount fails
• Multilanguage support.
• ContinueOnError and ExitScriptOnError support.

Disclaimer

- Test the functions before production.
- Make a backup before applying.
- Check the config file options description.
- Run AppDeployToolkitHelp.ps1 for more help and parameter descriptions.

Functions

• New-WIMFile - Creates a WIM file with the content of CapturePath (Files directory by default) and saves it in the SavetoPath folder (Script directory by default).
• Mount-WIMFile - Mounts a WIM file in the MountDir folder (Files directory by default).
• Dismount-WIMFile - Dismounts a WIM file and deletes the path.

Usage

# Creates a new WIM File based on the content of the Files directory
New-WIMFile

# Comments or removes the function once it's been used
# New-WIMFile

# Mount any WIM file found in script directory (last modified one if multiple)
$MountedObject = Mount-WIMFile

# <Normal script commands go here>

# Dismount the previously mounted/extracted WIM file
$MountedObject | Dismount-WIMFile

Internal functions

This set of functions are internals and are not designed to be called directly

• Expand-WIMFile - Expands a WIM file using native method or wimlib executable if exists.
• New-RemediationDismountTask - Creates an scheduled task with remediation commands.
• Remove-RemediationDismountTask - Removes a previously created remediation scheduled task.

Extension Exit Codes

|Exit Code|Function|Exit Code Detail| |:----------:|:--------------------|:-| |70101|Mount-WIMFile|Unable to get full path from mount path.| |70102|Mount-WIMFile|The WIM file could not be found.| |70103|Mount-WIMFile|The WIM file contains an invalid path or file name.| |70104|Mount-WIMFile|No WIM file found in script directory.| |70111|Mount-WIMFile|Failed to mount or extract WIM file in path.| |70105|Expand-WIMFile|Failed to delete SymbolicLink extraction path.| |70107|Expand-WIMFile|Failed to extract WIM file in path.| |70108|Expand-WIMFile|Failed to extract WIM file in path using wimlib.exe.| |70109|Expand-WIMFile|This script support wimlib as alternative method to expand WIM files, (try downloading wimlib to [..\SupportFiles\PSADT.WIMFile] directory).| |70112|Dismount-WIMFile|Input object contains a null or empty path attribute.| |70113|Dismount-WIMFile|Input object not detected as a valid object, please use Mount-WIMFile function and use the object returned as -ImageObject parameter.| |70114|New-WIMFile|Failed to create WIM file using wimlib.exe.| |70115|New-WIMFile|Unable to find wimlib executable and libraries inside SupportFiles folder, (try downloading wimlib to [..\SupportFiles\PSADT.WIMFile] directory).| |70116|New-WIMFile|This script support wimlib as alternative method to create WIM files, (try downloading wimlib to [..\SupportFiles\PSADT.WIMFile] directory).| |70117|New-WIMFile|The capture path does not exist.| |70118|New-WIMFile|The capture path is empty, must contains at least one element.| |70119|New-WIMFile|Unable to get full path from capture path.| |70120|New-WIMFile|Unable to get full path from save to path.| |70121|New-WIMFile|Unable to delete existing file.| |70122|New-WIMFile|The file already exists, use -ReplaceExisting switch to overwrite it.| |70123|New-WIMFile|Failed to create WIM file. Exception ErrorCode...| |70125|New-WIMFile|The save to path does not exist.| |70127|New-WIMFile|Remove the 'New-WIMFile' function from the script to continue.| |70128|New-WIMFile|Provide an existing directory path for the -CapturePath parameter.| |70129|New-WIMFile|Provide an existing directory path for the -SavetoPath parameter.| |70126|New-RemediationDismountTask|Failed to register remediation scheduled task.|

How to Install

1. Download and copy into Toolkit folder.

2. Edit AppDeployToolkitExtensions.ps1 file and add the following lines.

3. Create an empty array (only once if multiple extensions):

## Variables: Extensions to load
$ExtensionToLoad = @()

4. Add Extension Path and Script filename (repeat for multiple extensions):

$ExtensionToLoad += [PSCustomObject]@{
	Path   = "PSADT.WIMFile"
	Script = "WIMFileExtension.ps1"
}

5. Complete with the remaining code to load the extension (only once if multiple extensions):

## Loading extensions
foreach ($Extension in $ExtensionToLoad) {
	$ExtensionPath = $null
	if ($Extension.Path) {
		[IO.FileInfo]$ExtensionPath = Join-Path -Path $scriptRoot -ChildPath $Extension.Path | Join-Path -ChildPath $Extension.Script
	}
	else {
		[IO.FileInfo]$ExtensionPath = Join-Path -Path $scriptRoot -ChildPath $Extension.Script
	}
	if ($ExtensionPath.Exists) {
		try {
			. $ExtensionPath
		}
		catch {
			Write-Log -Message "An error occurred while trying to load the extension file [$($ExtensionPath)].`r`n$(Resolve-Error)" -Severity 3 -Source $appDeployToolkitExtName
		}
	}
	else {
		Write-Log -Message "Unable to locate the extension file [$($ExtensionPath)]." -Severity 2 -Source $appDeployToolkitExtName
	}
}

Requirements

• Powershell 5.1+
• PSAppDeployToolkit 3.8.4+

Multilanguage support progress (feel free to upload translated strings):

• 🇺🇸 100%
• 🇩🇰 0%
• 🇫🇷 0%
• 🇩🇪 0%
• 🇮🇹 0%
• 🇯🇵 0%
• 🇳🇴 0%
• 🇳🇱 0%
• 🇵🇱 0%
• 🇵🇹 0%
• 🇧🇷 0%
• 🇪🇸 100%
• 🇸🇪 0%
• 🇸🇦 0%
• 🇮🇱 0%
• 🇰🇷 0%
• 🇷🇺 0%
• 🇨🇳 (Simplified) 0%
• 🇨🇳 (Traditional) 0%
• 🇸🇰 0%
• 🇨🇿 0%
• 🇭🇺 0%

External Links

• PowerShell App Deployment Toolkit
• wimlib: the open source Windows Imaging (WIM) library
