Android Automate:

What Is It?

Android Automate is a root-less android automation tool.
Allows for multi-touch recording and playback with accurate time replication.
Provides an easy to use python object oriented API for injecting ADB commands to your android devices.
Can be used for automating Unit and Regression testing.
Because this utility uses ADB, it is possible to automate AVD, emulator, and real android devices.

Getting Started
Quick CLI Use Guide
Writing Scripts
Api Reference
Debugging FAQ

Getting Started

In order to use this tool you will need to:

Install python 3.7 (Need atleast Python 3.6 for f-strings).
Install ADB on your machine.
- You can do this by running sudo apt-get install adb on debian systems or sudo dnf install adb on an rpm system. Check if this worked by running: adb --version.
For using emulators, Android Studio must be installed. You must then create an avd from the tools/avdmanager drop-down. Further information on how to do this can be found here
Enable USB debugging on your android phone.
- This can be acheived on most models by opening the settings menu on your phone, navigating to "about phone" or "system information". Find "Build Number" and tap on it 7-10 times. This will enable developer options. Navigate back to the setting menu, and open the developer options. From here you may enable USB debugging.
- Verify this worked correctly by running adb devices. You should see your device listed as: <deviceId> device.
  - If it does not show anything then most likely have to install your device's USB drivers for linux.
  - If it shows <deviceId> unauthorized make sure to connect the phone and tap ok on the popup asking you for permission to allow usb debugging.
Only tested on linux systems. May not work on Windows as it uses UNIX style OS calls.
In order to test if your device is recognized, it is highly recommended that under developer options, the "show touches" and "show swipes" options are enabled.

Quick Use Guide

The idea is that you can use the CLI tool to explore what is possible, and then you can script things as can be seen in the example below.
Run androidAutomateCli with ./androidAutomateCli in the project root directory.
If this does not work you may have to add permissions with sudo cmod +x androidAutomateCli
Choose your device from the list.
From here record touch events, play touch events, explore and search installed apps, aswell as discovered the names of clickable nodes.

Emulator Managment

The CLI gives you the option of launching android emulators. These are only accessible if you have android studio installed and if you have already created some emulators using android studio's AVD manager.
For more information on using the in-built emulator managment, please refer to the wiki and to this for all possible emulator options.

How to Record Events:

Choose "Record Event" in the CLI menu.
Provide a name for the event i.e: "send_snapchat".
Perform the action on the device.
Press CTRL-C to stop recording.
The event is now stored in ./events and can be viewed and edited. The format of storing touch events is up for review and may change.

How to Playback Events:

Choose "Playback Event" in the CLI menu.
The available events will be listed with numbers.
Provide the number of the event.
Make sure the device is in the same state as when you recorded the event.
The event will now play.

Searching for an app:

Choose "Search Application".
Provide a search criteria term like you would with grep (Internaly it is just grep on the output of the list applications output).

List Clickable Nodes

Choose "List Clickable Nodes" in the CLI menu.
The info for all of the currently clickable nodes will be displayed.
The "content-desc" string will be used for matching nodes to click on in the tapNode() function.
If the node you would like to click is not listed, you can look in the generated screendump.xml file to look for issues.
NOTE: parseScreenXML() matches only nodes that have the atribute clickable="true".

Tap Clickable Node

Choose "Tap Clickable Node" in the CLI menu.
Provide a keyword of sub-string (case-insensitive) of "Text" or "Content-desc" from the output of the "List Clickable Nodes" output. This will tap the first node matching such criteria.

Writing Scripts

This module provides the option of importing the main androidAutomate.py file to programmatically control your automation task.

# SAMPLE AUTOMATION SCRIPT
from androidAutomate import Device
import time

# Argument is determined from `adb devices` command. In this case it is a Samsung s5
myDevice = Device("0283548d344b7a24")

# Use the CLI to determine package names for launching
myDevice.launchApp("com.android.settings")

# Wait for app to load / **REPLACE WITH FUNCTION TO DETECT WHEN APP LOADS** /
time.sleep(2)

# Tap on the searchbar (the possible tappable things are found in the CLI option "list Clickable Nodes")
myDevice.tapNode("Search")

# input text to the search bar:
myDevice.inputText("TEST")

# swipe up a couple times
for i in range(4):      #x1   y1    x2   y2
    myDevice.inputSwipe(500, 1300, 500, 400) #This represents a swipe up
    time.sleep(0.2)

# Demonstrate swipe options
myDevice.inputSwipe(500, 800, 500, 400, 1000) # This represents a swipe up but slow
myDevice.inputSwipe(50, 80, 50, 20, percent=True) # This represents a swipe up but with the x and y inputs being a percentage

This is an example script where the deviceId is passed during the instanciation of the device. The deviceId can be determined from the command adb devices. The eventId is a parameter that identifies the touchscreen hardware id. It is determined automatically by the funciton detEventId(). This function can fail under certain circumstances in which case you will need to run the command adb shell getevent -lp and find the eventId. This can then be used to overwrite the incorrect eventId determined in the instanciation of the device.

API Reference

The API reference and Source Code can be found on the GitHub Wiki!

The Emulator Options can be found and referenced HERE.

For info and examples on how to incorporate emulator managment into your script, click Here.

Debugging FAQ

1. A common issue is that the detEventId() method incorrectly identifies some other hardware device on your mobile device as being the touchscreen. If this is the case, you will have to manually check the eventId for touch getures. run: adb shell getevent -lp and find the touchscreen. ex output to adb shell getevent -lp:

add device 9: /dev/input/event2 <-- ###THIS IS THE NUMBER YOU WANT###
	name:     "sec_touchscreen"
	events:
		KEY (0001): KEY_HOMEPAGE          BTN_TOOL_FINGER       BTN_TOUCH       01c7		02be
		ABS (0003): ABS_X                 : value 0, min 0, max 4095, fuzz 0, flat 0, resolution 0
			ABS_Y                 : value 0, min 0, max 4095, fuzz 0, flat 0, resolution 0
			ABS_MT_SLOT           : value 0, min 0, max 9, fuzz 0, flat 0, resolution 0
			ABS_MT_TOUCH_MAJOR    : value 0, min 0, max 255, fuzz 0, flat 0, resolution 0
			ABS_MT_TOUCH_MINOR    : value 0, min 0, max 255, fuzz 0, flat 0, resolution 0
			ABS_MT_POSITION_X     : value 0, min 0, max 4095, fuzz 0, flat 0, resolution 0
			ABS_MT_POSITION_Y     : value 0, min 0, max 4095, fuzz 0, flat 0, resolution 0
			ABS_MT_TRACKING_ID    : value 0, min 0, max 65535, fuzz 0, flat 0, resolution 0
			003e                  : value 0, min 0, max -1, fuzz 0, flat 0, resolution 0
		SW  (0005): 0020*

Set device.eventId to the eventId in /dev/input/event<eventId>. In this case it is 2. This can be achieved with: myDevice.eventId = <deviceId>

2. If your device is not showing up in the adb devices command, look here for more info:

https://stackoverflow.com/questions/21170392/android-device-does-not-show-up-in-adb-list/21470729
https://forums.oneplus.com/threads/device-not-listing-using-adb-on-ubuntu-14-04-3.418957/
https://stackoverflow.com/questions/32151114/adb-is-not-detecting-my-android-device-on-ubuntu

3. If your device shows up as <deviceId> unauthorized there are a couple things to check: USB debugging in developer options is checked. Try running adb kill-server and then adb start-server after connecting your device. If you did not get a popup asking you if you trust usb debugging from this computer before, this should do it.

4. Currently replaying touchscreen touches is not supported on emulators. This is on the todo list. This issue arrizes from emulators not allowing executable files to be run over adb. Suggestions on workarounds appreciated.

TODO

[ ] add "waitOnApp()" functionality to wait for the activity to have the appname in it []
[ ] add touchscreen playback cababilities to x86 architecture emulator devides. This can be done by compiling the source to x86 32 bit elf executable and by adding a system architecture identification routine to the contructor of device classes.
[ ] add ability to click on specific id events []
[ ] record and replay input from all /dev/input/event# numbers and hardware devices [] $Might be impossible?$
[ ] add availability to go to s
