SmoothPathPlanner

After the Cheesy Poofs (FRC 254) put on an amazing display of robot path following during the 2014 FRC championship finals, a lot of buzz has been generated by other teams wishing to implement a similar feature on their robot. The poofs released their code and the community learned they used 5th order polynomial splines in order to find the best fit smooth curve from POint A to Point B.

Path planning has been the primary focus in many other fields outside of FRC. For example in Game AI, generating smooths paths for the main character to follow when going around obstacles needs to be calculated in real-time. In other robotics fields such as autonomous car navigation, many smooth paths need to be generated simultaneously, and the "best" path choosen.

These fields have spent many years adopting and optimizing the field of motion planning for their specific application. However, what they have in common is that the calculations for generating the path needs to be performed in real-time, and typically are performed on inexpensive embedded devices, such as gaming consoles or car computers. As part of my PhD thesis (developing a controller for an Autonomous Car) I had the opportunity to create a simplified path planner for real-time mobile robot applications.

This class is a port of the code I developed for my PhD thesis, to perform the function of path calculation on a mobile, skid-steer robot very quickly. The algorithms provided here rely on algorithms used in optimal control theory to converge to a solution very quickly. The code here uses the "gradient descent" optimization technique to coerce a simple waypoint path, into a smooth trajectory.

Once the smooth trajectory is determined, parallel paths for the left and right wheels are calculated based on the robots trackwidth distance, and corresponding velocities for each of the wheels are determined. As long as the robot has independant speed controllers for the left and right side of the drivetrain, the user can "play" through the velocity profile as if they are setpoints and the robot should drive the corresponding path.

The function takes in just 3 paramters to get started and boost a very simple user interface.

1. TotalTime - is the time you wish the robot to complete the path, this is used to calculate the velocity
2. Time Step - this is the rate at which the controller on your robot runs. Typically for FRC we run our controllers at a 100ms rate in a separate thread from the main Robot.
3. TrackWidth - the distance between the left and right wheels of the robot. This is used to calculate the left and right wheel paths.

The waypoints are simply global positions you would like your robot to drive, specified as a 2D array. The order of the points specify the path which the user wishes to drive, and the smooth path is generated accordingly. The smooth path generated also uses the Max Time, and controller periodic rate to automatically create the proper length velocity array so the user simply steps through each element once every time step. The end result is that the robot drives along the path, depending how well your speed controllers are tuned. So for example, if you have a controller running at 100ms, and you want a path that will take no more than 5 seconds to travsers, the algorithm will provide the left and right velocities as arrays with no more than 5/0.1 = 50 points. Each point will contain the velocity the robot should be at the time to make the end position by the end of travel.

Here is an an example to generate a path using the default paramters.

//create waypoint path
double[][] waypoints = new double[][]{
	{1, 1},
	{5, 1},
	{9, 12},
	{12, 9},
	{15, 6},
	{19, 12}
};

double totalTime = 8; //max seconds we want to drive the path
double timeStep = 0.1; //period of control loop on Rio, seconds
double robotTrackWidth = 2; //distance between left and right wheels, feet

FalconPathPlanner path = new FalconPathPlanner(waypoints);
path.calculate(totalTime, timeStep, robotTrackWidth);

After the calculate method is called, the smooth path and left and right velocities are all calculated and stored into the class data members. Below is the list of each class path variable. Note, all of the data members of this class are public. While this is usually not a good idea, I think for this case, and how we use these classes in FRC, it makes sense to leave these as public so the user can access them and modify them as needed. Note path is the class instantiated from the example above.

path.origPath; // 2D array of doubles which contains the original waypoint path provided
path.nodeOnlyPath; // 2D array of doubles which filters the original path and only keeps points which
		   //cause the path to change direction (i.e. all intermediate points on a straight line
		   //are removed)
path.smoothPath; //2D array of doubles represents the smooth path for the center of the robot.
path.leftPath; //2D array of doubles represents the left wheel path (based on track width of robot)
path.rightPath; //2D array of doubles represents the right wheel path (based on track width of robot)

path.smoothCenterVelocity; //2D array of doubles which contains a smooth velocity profile of the smoothPath above
path.smoothRightVelocity; //2D array of doubles which contains a smooth velocity profile of the rightPath above
path.smoothLeftVelocity; //2D array of doubles which contains a smooth velocity profile of the leftPath above

At this point all you need to do is pass path.smoothRightVelocity and path.smoothLeftVelocity to the Robots left and right wheel speed controllers. "Play" through the array updating the setpoint of the controller with the next element of the array each time step.

Note: ALL PATH 2 DIMENSIONAL ARRAYS CONTAIN THE X-COORDINATE IN THE FIRST DIMENSION, AND THE Y COODINATE IN THE SECOND DIMENSION. SO path.rightPath[i][0] would be the ith X- coodinate, and path.rightPath[i][1] would be the ith Y- coordinate of the right wheel path for example. THE UNITS OF THESE ARE THE GLOBAL UNITS ASSUMED BY THE USER.

Note: ALL VELOCITY 2 DIMENSIONAL ARRAYS CONTAIN THE TIME VECOTOR IN THE FIRST DIMENSION, AND THE VELOCITY MAGNITUDE IN THE SECOND DIMENSION. So path.smoothLeftVelocity[i][0] would be the ith time step value in seconds, and path.smoothLeftVelocity[i][1] would be the ith velocity magnitude in units per second. When attemping to command the speed controller, the user only needs to pass the `path.smoothLeftVelocity[i][1] array, which is a single dimension array of doubles to the speed controller.

Furthermore, the algorithm also implements a smooth start/stop routine and automatically ramps up and down to a zero velocity so at the end of travel the robot slows down to zero. The coerceion to zero velocity takes in to account the total distance needed to travel and modifies the velocity accordingly.

Typically when I write complex algorithms, I tend to put the Big O notation in the JavaDoc comments of each method and I also write down a pseudocode to help guide me as I program the algorithm. Typically I remove these comments in the final product, but I decided to leave them in to help people follow my logic, and see which Algorithms I have optimized, and which algorithms could use more optimization. Most algorithms have been optimized to linear Big O notation.

I have tested this algorithm on a 2015 RoboRio and for a path containing

<Include timing assessment>

Using the Included Grapher

I have also included a very crude graphing class to help visualize the output. The graphing class is also written using native Java SE classes and will run on any desktop.

Note: Because the RoboRio is headless (meaning no display), the Graph functions can not run on the RoboRio. Check if(!GraphicsEnvironment.isHeadless()) before graphing this way the code is completely portable and will run on both desktop and RoboRio.

So let’s work through an example of how to use this class:

If we want to graph the output of the path above we can do the following and produce the following plot:

FalconLinePlot fig1 = new FalconLinePlot(path.nodeOnlyPath,Color.blue,Color.green);

The plot above isn’t that helpful. However we can configure it to be more useful to us. Since this is the plot of the global path of the robot. Let’s change the X- and Y- axis to reflect the dimensions of half of the FRC field (24 x 27ft) and lets add some labels and grid lines.

fig1.yGridOn();
fig1.xGridOn();
fig1.setYLabel("Y (feet)");
fig1.setXLabel("X (feet)");
fig1.setTitle("Top Down View of FRC Field (24ft x 27ft) \n shows global position of robot path, along with left and right wheel trajectories");

//force graph to show 1/2 field dimensions of 24ft x 27 feet
fig1.setXTic(0, 27, 1);
fig1.setYTic(0, 24, 1);

The above figure is more useful. It shows the general path we wish the robot to take. Starting at our waypoint {1,1} and ending at {19,12}. This plot is in feet. The real usefulness of the plotter function is the ability to add additional plots to one figure. You can add an unlimited amount of charts using the addData method. There are also options to specify line color, and marker color. If you do not wish to have lines or markers, set them to null.

Lets add the smooth center path the algorithm calculated to this plot. Which gives the following:

fig1.addData(path.smoothPath, Color.red, Color.blue);

We can see the smooth path algorithm does two things. It creates many more data points and provides smooth transitions around the corners. The number of data points created is based on the max Time you wish the robot to complete the path, and the time step of the controller.

We can also add the left and right path trajectories to the plot to provide all the useful information we need in o
