GeoGrids.jl

This is a package containing functions for Geographical Grids generation, for example for terminals distribution for System Level Simulations.

v0.5.0 - Updates

Support for different type of regions.
Tessellation for creating cell grid layouts is supported on this version.
Faster computation of filtering and grouping of points in different regions.
Offsetting of regions is supported on this version.

Basic Types

AbstractRegion: Abstract type representing a geographical region.
- GlobalRegion: Represents the entire globe.
- LatBeltRegion: Represents a latitude belt defined by minimum and maximum latitudes.
- GeoRegion: Represents a geographical region defined by a country or a list of countries.
- PolyRegion: Represents a region defined by a polygon of latitude-longitude coordinates.
AbstractTiling: Abstract type for different tessellation methods.
- HEX: Hexagonal tessellation with specified direction (:pointy or :flat).
- ICO: Icosahedral grid tessellation with specified correction factor and pattern (:hex or :circle).
- H3: Uber's H3 hexagonal hierarchical geospatial indexing system (not implemented in current version).

Enlarged Regions

GeoRegionOffset: Represents a geographical region defined by a country or a list of countries, with an additional field :enlarged that can be set to true to indicate that the region is enlarged.
PolyRegionOffset: Represents a region defined by a polygon of latitude-longitude coordinates, with an additional field :enlarged that can be set to true to indicate that the region is enlarged.

These types provide a flexible framework for defining geographical regions and tessellation methods for creating grid layouts in GeoGrids.jl. They allow users to specify different types of regions (global, latitude belts, country-based, or custom polygons) and choose appropriate tessellation methods for their specific needs.

Icosahedral Grid

icogrid(; N::Union{Int,Nothing}=nothing, sepAng::Union{ValidAngle,Nothing}=nothing) -> Vector{Point{🌐,<:LatLon{WGS84Latest}}}

At least one of N, the number of points to generate, or sepAng, the separation angle between points, must be provided.

This function returns a Vector of Point{🌐,<:LatLon{WGS84Latest}} elements, representing a global grid built with an icosahedral-based method.

The grid is generated based on the specified radius and type parameters. The type parameter is an ICO struct that defines the correction factor and pattern (hexagonal or circular) for the grid.

The problem of how to evenly distribute points on a sphere has a very long history. Unfortunately, except for a small handful of cases, it still has not been exactly solved. Therefore, in nearly all situations, we can merely hope to find near-optimal solutions to this problem.

Of these near-optimal solutions, the icosahedral grid is one approach that provides a more uniform distribution of points on a sphere compared to simple latitude-longitude grids. It starts with a regular icosahedron inscribed in a sphere and then subdivides its faces to create a finer mesh.

This method of point distribution aims to provide a more uniform coverage of the Earth's surface, which can be particularly useful for global-scale simulations or analyses.

The function returns points in the WGS84 coordinate system, represented as latitude-longitude pairs.

Example:

	plot_geo_points(icogrid(sepAng=5); title="Ico Grid")

Rectangular Grid

rectgrid(xRes::ValidAngle; yRes::ValidAngle=xRes) -> Array{Point{🌐,<:LatLon{WGS84Latest}}, 2}

This function generates a rectangular grid of points on the Earth's surface. It returns a Matrix of Point{🌐,<:LatLon{WGS84Latest}} elements, representing a global grid with the specified parameters.

At least xRes must be provided, which is the resolution for the latitude grid spacing.

The function generates a grid of regularly spaced points on the Earth's surface. The grid points are returned as Point{🌐,<:LatLon{WGS84Latest}} objects, representing latitude-longitude coordinates in the WGS84 coordinate system.

This rectangular grid can be useful for various geospatial applications, such as creating evenly spaced sampling points across the globe or defining a regular grid for data analysis and visualization.

Example:

	plot_geo_points(rectgrid(5)[:]; title="Rect Grid")

Vector Grid

vecgrid(gridRes::ValidAngle) -> Vector{Point{🌐,<:LatLon{WGS84Latest}}}

This function generates a vector of latitude points from the equator to the North Pole with a specified resolution. It returns a Vector of Point{🌐,<:LatLon{WGS84Latest}} elements, representing a grid of latitudes with the specified resolution.

The gridRes parameter must be provided, which is the resolution for the latitude grid spacing. This can be a real number (interpreted as degrees) or a ValidAngle.

The function generates a vector of latitude points ranging from 0° (the equator) to 90° (the North Pole). Each point is represented as a Point{🌐,<:LatLon{WGS84Latest}} object with a fixed longitude of 0°.

This vector grid can be useful for various applications that require sampling or analysis along a meridian, such as studying latitudinal variations in climate data, or creating a basis for more complex grid structures.

Filtering

in(p::Union{LatLon, Point{🌐,<:LatLon{WGS84Latest}}}, domain::AbstractRegion) -> Bool
in(points::AbstractVector{<:Union{LatLon, Point{🌐,<:LatLon{WGS84Latest}}}}, domain::AbstractRegion) -> Vector{Bool}

This function determines if a given point or vector of points belongs to an AbstractRegion. The AbstractRegion can be a GlobalRegion, GeoRegion, GeoRegionOffset, PolyRegion, or LatBeltRegion.

For a single point, the function returns a boolean indicating whether the point is inside the region. For a vector of points, it returns a vector of booleans, each indicating whether the corresponding point is inside the region.

The function checks if each point falls inside the given region using the appropriate method for that region type.

filter_points(points::AbstractVector{<:Union{LatLon, Point{🌐,<:LatLon{WGS84Latest}}}}, domain::AbstractRegion) -> Vector{eltype(points)}

This function filters a vector of points based on whether they fall within a specified region. It returns a new vector containing only the points that are inside the region.

group_by_domain(points::AbstractVector{<:Union{LatLon, Point{🌐,<:LatLon{WGS84Latest}}}}, domains::AbstractVector{<:AbstractRegion}) -> Dictionary{String, Vector{eltype(points)}}

This function groups points based on which region they belong to. It returns a dictionary where the keys are names of the domains, and the values are vectors of points that fall within each domain.

Examples:

  p = icogrid(;sepAng=1)
  r = GeoRegion(;admin="Italy;Spain")
  f = filter_points(p,r)
  plot_geo_points(f; title="Geo Region Filtering")

  p = icogrid(;sepAng=4)
  r = LatBeltRegion(;lim=(-10,10))
  f = filter_points(p,r)
  plot_geo_points(f; title="Lat Belt Region Filtering")

  p = rectgrid(2)
  r = PolyRegion(domain=[LatLon(10°, -5°), LatLon(10°, 15°), LatLon(27°, 15°), LatLon(27°, -5°)])
  f = filter_points(p[:],r)
  plot_geo_points(f; title="Poly Region Filtering")

<img src="./docs/img/poly_filtering.png" alt="Poly Filtering"/>$s$

Tessellation

generate_tesselation(region::Union{GeoRegion, PolyRegion}, radius::Number, type::HEX; refRadius::Number=constants.Re_mean, kwargs_lattice...) -> AbstractVector{<:Point{🌐,<:LatLon{WGS84Latest}}}
generate_tesselation(region::Union{GeoRegion, PolyRegion}, radius::Number, type::HEX, ::EO; refRadius::Number=constants.Re_mean, kwargs_lattice...) -> AbstractVector{<:Point{🌐,<:LatLon{WGS84Latest}}}, AbstractVector{<:AbstractVector{<:Point{🌐,<:LatLon{WGS84Latest}}}}
generate_tesselation(region::GlobalRegion, radius::Number, type::ICO; refRadius::Number=constants.Re_mean) -> AbstractVector{<:LatLon}
generate_tesselation(region::GlobalRegion, radius::Number, type::ICO, ::EO; refRadius::Number=constants.Re_mean) -> AbstractVector{<:LatLon}, AbstractVector{<:AbstractVector{<:LatLon}}
generate_tesselation(region::Union{LatBeltRegion, GeoRegion, PolyRegion}, radius::Number, type::ICO; refRadius::Number=constants.Re_mean) -> AbstractVector{<:LatLon}
generate_tesselation(region::Union{LatBeltRegion, GeoRegion, PolyRegion}, radius::Number, type::ICO, ::EO; refRadius::Number=constants.Re_mean) -> AbstractVector{<:LatLon}, AbstractVector{<:AbstractVector{<:LatLon}}

This function generates a tessellation pattern around a given center poi
