pysrt3d

Python binding for SRT3D: Region-Based 6DoF Object Tracking

https://github.com/user-attachments/assets/bf9b0102-c6a2-4eba-bd31-6a6ffa3dec50

Modification

1. Automatical body-diameter calculation

You don't need to specify max_body_diameter manually, just as M3T.

2. Kullback-Leibler divergence based confidence assessment

If the predicted pose is good (close to the reality), the mean value of each correspondence line will be zero (at the center, without offset). We calculate KL divergence for each correspondence line and the optimal one: $\mathcal{N}(0, \sigma_{min}^2)$.

3. Thresholds for initialization and tracking

We define thresholds for initialization and tracking (you can manually set them), so that you can easily align the object to the virtual one before starting tracking.

4. Independent multi-model tracking

The confidences are calculated independently. You can easily add models and get their information (pose, conf., etc.).

Installation

Make sure that you have installed the following packages:

• GLEW
• glfw3
• Eigen3
• OpenCV 3/4
• OpenMP (may have already installed on your system)

Your compilation environment should support C++ 17.

Dependency Instruction

• [method 1] Through system path

  $ sudo apt install libglew-dev libglfw3-dev libeigen3-dev
  # BUILD opencv from source code: https://github.com/opencv/opencv


• [method 2] Under conda env

  $ conda activate ${YOUR_ENV_NAME}
  $ conda install glew glfw eigen libopencv


• Other dependencies for demo.py

  pip install numpy
  pip install opencv-python


Package Installation

cd ${repo_root}
pip install .

Demo

* The demo data is from DeepAC.

cd ${repo_root}/example
python demo.py

Interface

Just follow example/demo.py or source/pysrt3d/pysrt3d.cpp.

Note

This algorithm is for object tracking only, without global pose estimation. In consequence, an initial pose (4 by 4 matrix under opencv coordinate) must be provided before you start tracking.
