SegX: Improving Interpretability of Clinical Image Diagnosis with Segmentation-based Enhancement

Introduction

SegX Illustration

SegX [paper] is a plug-and-play approach designed to enhance the interpretability of deep learning-based medical image analysis by aligning explanation maps with clinically relevant regions using segmentation models.

The SegX begins with the classification and XAI pipeline (green), where a medical image is processed by a classification model to generate predictions and an XAI method produces the original explanation map. Afterwards, the segmentation-based enhancement (blue) starts with a segmentation model that generates a clinical interests mask to align the XAI outputs with clinically significant regions using the SegX module, producing a refined SegX map.

Here is an example demonstrating how SegX enhances the interpretability of GradCAM on the ChestX-Det10 dataset.

<table> <tr> <td style="text-align: center;"> <img src="img/chestx_36223.png" alt="raw" style="width: 90%;"> <p style="margin-top: 5px; font-size: 14px;">(a) Raw Image</p> </td> <td style="text-align: center;"> <img src="img/chestx_36223_gradcam.png" alt="GradCAM" style="width: 90%;"> <p style="margin-top: 5px; font-size: 14px;">(b) GradCAM</p> </td> <td style="text-align: center;"> <img src="img/chestx_36223_segx_gradcam.png" alt="SegX-GradCAM" style="width: 90%;"> <p style="margin-top: 5px; font-size: 14px;">(c) SegX-GradCAM</p> </td> </tr> </table>

Getting Started

Prerequisites

Python 3.10+
PyTorch
Optuna (for hyperparameter search)

Installation

Steps to install the project. This usually involves cloning the repository and installing dependencies.

git clone <https://github.com/JasonZuu/SegX.git>
cd SegX
pip install -r requirements.txt

Download the Data and Model Weights (Optional)

You can download the required data and model weights using the following Kaggle links:

After downloading, place the files in the SegX directory and unzip images.zip and masks.zip for each dataset.

Start with SegX-GradCAM (Optinal)

If you have downloaded the Data and Model weights and put them in the working directory, you should be able to interpret your model with the SegX using

python interpret.py --dataset ham --model resnet --algo segx_gradcam
python interpret.py --dataset chestx --model resnet --algo segx_gradcam

Usage

Grid Search for The Best Hyperparameters (Optional)

We provide the best hyperparameters and the grid search process in the optuna_db directory. However, you are free to modify the hyperparameter search space and rerun the grid search. To adjust the search space, edit configs/grid_search_configs.py and update the relevant settings. Then, run

python grid_search.py --dataset ham --task cls --model resnet --pretrained
python grid_search.py --dataset ham --task cls --model densenet --pretrained
python grid_search.py --dataset ham --task seg --model unet --pretrained

python grid_search.py --dataset chestx --task cls --model resnet --pretrained
python grid_search.py --dataset chestx --task cls --model densenet --pretrained
python grid_search.py --dataset chestx --task seg --model unet --pretrained

For time constraints, we have not explored the impact of the segmentation model's performance on SegX's interpretability effectiveness, though we believe there is a positive correlation. If you are interested in investigating this relationship, feel free to experiment with different segmentation techniques using our framework. We are proud to support your research and contribute to the community.

Train Your Model

After obtaining the best hyperparameters (or using our provided hyperparameters in optuna_db, you can train your classification model with ResNet and DenseNet backbones and your segmentation model with the U-Net backbone using:

python train.py --dataset ham --model resnet --task cls --pretrained --use_best_hparams
python train.py --dataset ham --model densenet --task cls --pretrained --use_best_hparams
python train.py --dataset ham --model unet --task seg --pretrained --use_best_hparams

python train.py --dataset chestx --model resnet --task cls --pretrained --use_best_hparams
python train.py --dataset chestx --model densenet --task cls --pretrained --use_best_hparams
python train.py --dataset chestx --model unet --task seg --pretrained --use_best_hparams

Please note that you should always use --use_best_hparams when training the model. The parameters in configs/train_configs.py are not our default settings and may lead to poor performance.

Interpret with SegX

After training your model (or using the downloaded model weights), you can interpret the model for your task using SegX using:

python interpret.py --dataset ham --model resnet --algo segx_gradcam
python interpret.py --dataset ham --model densenet --algo segx_gradcam
python interpret.py --dataset chestx --model resnet --algo segx_gradcam
python interpret.py --dataset chestx --model densenet --algo segx_gradcam

python interpret.py --dataset ham --model resnet --algo segx_gradient_shap
python interpret.py --dataset ham --model densenet --algo segx_gradient_shap
python interpret.py --dataset chestx --model resnet --algo segx_gradient_shap
python interpret.py --dataset chestx --model densenet --algo segx_gradient_shap

The code in interpret.py provides demos on the datasets used in our experiments. You can always modify it to suit your own tasks and models.

Contributing

Guidelines for contributing to the project.

Fork the repository
Create a new branch (git checkout -b feature-foo)
Commit your changes (git commit -am 'Add new feature')
Push to the branch (git push origin feature-foo)
Create a new Pull Request

Citation

If you use our work for you research, please cite it as follows:

@inproceedings{zhang2025segx,
  title={SegX: Improving Interpretability of Clinical Image Diagnosis with Segmentation-based Enhancement},
  author={Zhang, Yuhao and Zhu, Mingcheng and Luo, Zhiyao},
  booktitle={AAAI Bridge Program on AI for Medicine and Healthcare},
  pages={100--108},
  year={2025},
  organization={PMLR}
}

Contact

Email: yuhao_zhang@u.nus.edu
GitHub: Yuhao Zhang
