Open Source: Geophysical 3D/2D Finite Difference Modeling and Marchenko Algorithms
This repository contains tools for geophysical modeling, including:
- 3D/2D Finite Difference (FD) modeling
- Marchenko algorithms
- 2D/3D x-w migration utilities
These tools are essential for seismic exploration, imaging, and multiple elimination tasks in inhomogeneous media. The code supports seismic interferometry and other advanced geophysical techniques.
Table of Contents
- Acknowledgments
- Features
- Installation
- Reproducing
- Demos:
- References
- License
- Additional Installations
- Updates and Latest Version
ACKNOWLEDGEMENT
This work received funding from the European Research Council (grant 742703) and the NWO Domain Applied and Engineering Sciences (grant 13939).
FEATURES
- Finite Difference (FD) Modeling: Includes 2D and 3D FD models for seismic interferometry, simulation, and analysis.
- Marchenko Method: Implements advanced algorithms for seismic wavefield extrapolation and multiple elimination.
- x-w Migration Utilities: Provides tools for x-w (space-frequency) migration in 2D/3D.
- Seismic Unix Compatibility: Integration with routines from Seismic Unix.
INSTALLATION
See the separate INSTALL file.
REPRODUCING
Almost all Figures in the papers mentioned above can be reproduced with the software in this repository. Please see the file REPRODUCE for further instructions
Finite Difference Modeling: FDELMODC
To run a demo for finite difference modeling, navigate to the fdelmodc/demo directory and execute the following script:
./fdelmodc_plane.scr
The demo directory contains many scripts which demonstrate the different possibilities of the modeling program.
To reproduce the Figures shown in the GEOPHYSICS manuscript "Finite-difference modeling experiments for seismic interferometry" the scripts in FiguresPaper directory can be used. Please read the README in the FiguresPaper directory for more instructions and guidelines.
An extensive manual of fdelmodc can be found in doc/fdelmodcManual.pdf
Marchenko method : MARCHENKO
To run the demos for the Marchenko method, navigate to the bin/marchenko directory and run the scripts found in:
marchenko/demo/oneD
marchenko/demo/twoD
To reproduce the Figures shown in the GEOPHYSICS paper "Implementation of the Marchenko method" the scripts in marchenko/demo/oneD directory can be used. The README in this directory gives more instructions and guidelines.
To reproduce the Figures shown in the Scientific Reports paper "Virtual acoustics in inhomogeneous media with single-sided access" the scripts in marchenko/demo/ScientificReports directory can be used. The README in this directory gives more instructions and guidelines.
To reproduce the Figures shown in the GEOPHYSICS paper "Implementation of the Marchenko Multiple Elimination algorithm" the scripts in marchenko/demo/mme directory can be used. The README_PRIMARIES in this directory gives more instructions and guidelines.
A brief manual about the MME program 'marchenko_primaries' can be found in doc/MMEmanual.pdf
A more extensive manual about Marchenko can be found in doc/marchenkoManual.pdf
MDD
Multidimensional deconvolution is a geophysical technique used for multidimensional wavefield reconstruction. The MDD kernels depend on BLAS and LAPACK calls. Free downloads of these libraries can be found on
https://www.netlib.org/blas/index.html https://www.netlib.org/lapack/index.html
MDD with LSQR uses the Fortran90 zLSQR code (for real or complex A) from the Systems Optimization Laboratory of Stanford University
https://stanford.edu/group/SOL/software/lsqr/
MKL libraries
The Math Kernel Library (MKL) is a set of mathematical routines designed to accelerate performance on Intel processors. It helps optimize performance for x84_64 architectures.
If you are running on x64_86 processors you can download (for free) Intel's highly optimised MKL package:
https://software.intel.com/en-us/mkl/choose-download
These Libraries include highly optimised libraries of BLAS, LAPACK, and FFT(W). Usually the MKL libraries are installed in $MKLROOT. If that variable is not set, you can try to find the correct path by searching for one of the libraries:
find /opt/intel -name libmkl_gf_lp64.so
and adjust MKLROOT in Make_include accordingly. You can also completely disable the use of MKL by commenting out the MKL parts in Make_include.
In case MKL is installed on your system there is no need to install the netlib packages mentioned for MDD.
SEISMIC UNIX
The output file format is based on Seismic Unix (SU) with a file extension '.su'. These files can be opened and processed with Seismic Unix Software. If you want to use the .su files with SU from CWP: git clone https://github.com/JohnWStockwellJr/SeisUnix
==> Please make sure that SU is compiled without XDR (in $CWPROOT/Makefile.config make sure that XDRFLAG is NOT enabled). The SU output files of fdelmodc are all based on local IEEE data. To exclude the XDRFLAG in SU you have to use the following line in $CWPROOT/src/Makefile.config around line 35:
XDRFLAG =
so the XDRFLAG is empty. If you have made that change you have to remake SU with the commands: make remake make xtremake
ZFP
The fdacrtmc and the 3D Marchenko code makes use of ZFP compression to store snapshots in CPU memory or do efficient IO. This package is included in this repository for your convenience. The latest package and detailed explanation can be found on:
https://github.com/LLNL/zfp
and written by Peter Lindstrom.
FDACRTMC
fdacrtmc uses FFTW and the wisdom computations are stored on disk for re-usage. This directory is defined in fdacrtmc.h
#ifndef WISDOMDIR #define WISDOMDIR "/tmp/fftw/" #endif
For the code to run properly the directory /tmp/fftw/ must exist. It is also possible to compile the fdacrtmc code that defines WISDOMDIR. In fdacrtmc/Makefile add:
CFLAGS += -DWISDOMDIR="/directory/that/exists"
or you can change the name of WISDOMDIR in fdacrtmc.h
The Finite Different based RTM code (FDACRTMC) will not be installed if MKL is not available. This code depends on FFTW and we do want to include the full FFTW source code package to this. Our aim is to keep the compilation of the code in the GitLab repository as simple as possible with the smallest number of external libraries.
LICENSE
THE ACCOMPANYING PROGRAM IS PROVIDED UNDER THE TERMS OF THIS COMMON PUBLIC LICENSE ("AGREEMENT"). ANY USE, REPRODUCTION OR DISTRIBUTION OF THE PROGRAM CONSTITUTES RECIPIENT'S ACCEPTANCE OF THIS AGREEMENT.
A copy of this license can be found in the file 'Common_Public_License.txt' in the directory where you have found this README.
http://www.opensource.org/licenses/cpl1.0.php
SU
Some routines are from Seismic Unix and include the SU LEGAL_STATEMENT in the source code.
Copyright (c) 2017 by the Society of Exploration Geophysicists. For more information, go to http://software.seg.org/2017/00XX . You must read and accept usage terms at: http://software.seg.org/disclaimer.txt before use.
REPRODUCING
Almost all Figures in the papers mentioned in the REFERENCES can be reproduced with the software in this repository. Please see the file REPRODUCE for further instructions
REFERENCES
-0- Reference of this software release
Thorbecke, J., and J. Brackenhoff, 2022, OpenSource code for Finite Difference, Marchenko algorithms and processing utilities: https://gitlab.com/geophysicsdelft/OpenSource.git, doi 10.5281/zenodo.3374728.
-1- If the Finite Difference code has helped you in your research please refer to the following paper in your publications:
Finite-difference modeling experiments for seismic interferometry Jan Thorbecke and Deyan Draganov 2011, Geophysics, Vol. 76, no. 6 (November-December); p H1--H18, doi: 10.1190/GEO2010-0039.1 Download: https://janth.home.xs4all.nl/Publications/Articles/ThorbeckeDraganov2012.pdf
-2- If the Marchenko code has helped you in your research please refer to this paper in your publications:
Implementation of the Marchenko method Jan Thorbecke, Evert Slob, Joeri Brackenhoff, Joost van der Neut, and Kees Wapenaar 2017, Geophysics, Vol. 82, no. 6 (November-December); p. WB29--WB45, doi: 10.1190/GEO2017-0108.1 Download: https://janth.home.xs4all.nl/Publications/Articles/ThorbeckeGPY2017.pdf
-3- If you used the code to construct homogeneous Green's functions, please refer to this paper in your related publications:
Virtual acoustics in inhomogeneous media with single-sided access: Wapenaar, K., Brackenhoff, J., Thorbecke, J., van der Neut, J., Slob, E., and Verschuur, E., 2018, Scientific Reports, Vol. 8, 2497. Download: https://www.keeswapenaar.nl/4_Journals/Nature/SR_18.pdf
-4- When you are using the marchenko_primaries algorithm developed by Lele Zhang please refer to the following papers
Free-surface and internal multiple elimination in one step without adaptive subtraction Lele Zhang and Evert Slob 2019, Geophysics, Vol. 84, no. 1 (January-February); p. A7-A11, doi: 10.1190/GEO2018-0548.1 Download: https://www.keeswapenaar.nl/BeyondInterferometry/geo_19h.pdf
and
Implementation of the Marchenko Multiple Elimination algorithm, Jan Thorbecke, Lele Zhang, Kees Wapenaar, Evert Slob, 2021, Geophysics, Vol. 86, no. 2 (March-April); p. 1-15, doi: 10.1190/GEO2020-0
