Vip

#Introduction

VIP (VHDL Interface Plug-in) is a script for VIM text editor which provides some facilities to copy paste entities, components and instances of components.

For example you can copy the component :

component mux is   -- place the cursor on this line and enter the command :Viy (Vhdl Interface Yank)
   port (
     INPUT  : in  std_logic_vector (15 downto 0);
     SEL    : in  std_logic;
     OUTPUT : out std_logic
   );
end component mux;

and paste it as an instance :

mux_0 : mux   -- place the cursor here and enter the command :Vii (Vhdl Interface Instance)
   port map (
      INPUT   => s_INPUT,
      SEL     => s_SEL,
      OUTPUT  => s_OUTPUT
  );

VIP can :

    copy an entity and paste it as
        an entity
        a component
        an instance

    copy a component and paste it as
        an entity
        a component
        an instance

    copy a instance and paste it as
        an instance (with auto-incrementation of the suffix number)

VIP tries to respect your indentation as much as possible (spaces, tabs, spaces + tabs). It can work with many different styles of writing entities, components and instances but not all of them. See documentation.

#Download :

[VIM scripts / VIP] (http://www.vim.org/scripts/script.php?script_id=3335)
