PreviewBuild - SwiftUI Preview Capture Toolkit

A CLI toolset for building and capturing SwiftUI previews programmatically. Designed to work with AI coding assistants (Claude Code and Cursor) for visual analysis of UI components.

Features

• Dynamic Preview Injection - Creates minimal PreviewHost targets instead of building full apps
• SPM Package Support - Works with standalone Swift packages
• Xcode Project Support - Works with xcodeproj files (including Tuist-generated projects)
• Fast Builds - Only builds required modules (~3-4 seconds for cached builds)
• Resource Bundle Detection - Automatically includes asset bundles for themes/colors

Requirements

• macOS with Xcode installed
• iOS Simulator
• Swift toolchain (preview-tool auto-builds on first run)

Installation

Claude Code: Plugin Marketplace (Recommended)

Install via the Claude Code plugin marketplace:

/plugin marketplace add Iron-Ham/XcodePreviews
/plugin install preview-build@XcodePreviews

Claude Code: Manual Install

1. Clone the repository

git clone https://github.com/Iron-Ham/XcodePreviews.git ~/XcodePreviews

2. Install the Claude Code skill

Copy the skill definition to your user-level commands directory:

mkdir -p ~/.claude/commands
cp ~/XcodePreviews/.claude/commands/preview.md ~/.claude/commands/

Note: The manual install expects scripts at ~/XcodePreviews. If you cloned to a different location, set PREVIEW_BUILD_PATH:

export PREVIEW_BUILD_PATH=/path/to/XcodePreviews

Upgrading from Claude-XcodePreviews? The old path ~/Claude-XcodePreviews still works — the skill files fall back to it automatically. You can rename your clone at any time, or just leave it.

Cursor: Install

1. Clone the repository

git clone https://github.com/Iron-Ham/XcodePreviews.git ~/XcodePreviews

2. Install the Cursor skill

Copy the skill to your user-level skills directory:

mkdir -p ~/.cursor/skills/preview
cp ~/XcodePreviews/.cursor/skills/preview/SKILL.md ~/.cursor/skills/preview/

3. (Optional) Install the workspace rule

If you want the preview toolkit context always available in a specific project, copy the rule to that project's .cursor/rules/ directory:

mkdir -p /path/to/your/project/.cursor/rules
cp ~/XcodePreviews/.cursor/rules/preview.mdc /path/to/your/project/.cursor/rules/

Note: Like the Claude Code install, this expects scripts at ~/XcodePreviews. Set PREVIEW_BUILD_PATH to override:

export PREVIEW_BUILD_PATH=/path/to/XcodePreviews

Usage

Unified Entry Point

The preview script auto-detects the best approach:

# Preview a file in an Xcode project
./scripts/preview path/to/MyView.swift

# Preview a file in an SPM package
./scripts/preview path/to/Package/Sources/Module/MyView.swift

# Specify output path
./scripts/preview MyView.swift --output ~/Desktop/preview.png

# Capture current simulator
./scripts/preview --capture-only

Direct Scripts

For standalone Swift files (system imports only):

./scripts/preview-minimal.sh MyView.swift

Options

| Option | Description | |--------|-------------| | --project <path> | Xcode project file | | --workspace <path> | Xcode workspace file | | --package <path> | SPM Package.swift path | | --module <name> | Target module (auto-detected) | | --simulator <name> | Simulator name (default: iPhone 17 Pro) | | --output <path> | Output screenshot path | | --verbose | Show detailed build output | | --keep | Keep temporary files after capture |

How It Works

For Xcode Projects

1. Parses the Swift file to extract #Preview { } content
2. Injects a temporary PreviewHost target into the project
3. Configures dependencies based on imports
4. Builds only the required modules
5. Launches in simulator and captures screenshot
6. Cleans up the injected target

For SPM Packages

1. Creates a temporary Xcode project
2. Adds the local SPM package as a dependency
3. Generates a PreviewHost app with the preview content
4. Builds and captures screenshot

AI Assistant Integration

Claude Code

After installation, use the /preview command:

/preview path/to/MyView.swift

Cursor

After installing the skill, ask the agent to preview a SwiftUI view:

Preview the file path/to/MyView.swift

In both cases, the assistant will:

1. Build the preview using the appropriate method
2. Capture a screenshot
3. Analyze and describe the visual output

Codex Integration

Codex can use the same scripts through a Codex skill.

Install Codex Skill

export PREVIEW_BUILD_PATH=/absolute/path/to/XcodePreviews
mkdir -p ~/.codex/skills/public/xcode-preview-capture
cp -R "$PREVIEW_BUILD_PATH"/.codex/skills/xcode-preview-capture/* \
  ~/.codex/skills/public/xcode-preview-capture/

Set PREVIEW_BUILD_PATH in your shell profile so Codex can invoke the scripts from any location.

Use with Codex

Ask Codex to preview a SwiftUI file. The skill instructs Codex to:

1. Run scripts/preview with your target file
2. Capture /tmp/preview*.png
3. Read the screenshot and provide UI analysis

Scripts & Tools

| Path | Purpose | |------|---------| | scripts/preview | Unified entry point (auto-detects best approach) | | scripts/preview-minimal.sh | Standalone files (system imports only) | | scripts/capture-simulator.sh | Screenshot capture | | scripts/sim-manager.sh | Simulator utilities | | tools/preview-tool | Swift CLI for dynamic preview injection + SPM preview |

License

MIT
