DiveFuzz

DiveFuzz is a diversified instruction generation approach designed specifically for RISC-V CPUs. Its core idea is to drive testing through dynamically diversified instruction write-back values, enabling effective exploration of CPU states. More details can be found in the paper. In addition, the project is under active development and will continue to incorporate new extensions and features.

Get Start

Clone the main repository

git clone https://github.com/In2Sec/DiveFuzz
cd DiveFuzz

Clone the runtime-diversified version of riscv-isa-sim adapted for DiveFuzz as a git submodule

git submodule init ref/riscv-isa-sim-adapter
git submodule update ref/riscv-isa-sim-adapter

Navigate to the dut directory and select your target RISC-V CPU for testing. If you already have the target existing, you can skip this step.

cd dut

# Example: XiangShan
git submodule init XiangShan

Requirements

RISC-V toolchain

DiveFuzz using RISC-V toolchain to generate test cases. For base usage, the following dependencies are required: riscv64-unknown-elf-*

You can obtain the toolchain by following the instructions here. We need the newlib version of the toolchain, which prefixes with riscv64-unknown-elf-, designed for embedded applications and bare metal development.

We recommend version 2025.11.27; Older versions may have issues with certain extensions not being supported.

Spike RISC-V ISA simulator

DiveFuzz's diverse test generation capability relies on the Spike RISC-V ISA simulator.

The following dependencies are required to install Spike on Debian-based systems:

apt-get install device-tree-compiler libboost-regex-dev libboost-system-dev

Enter the submodule directory (ref/riscv-isa-sim-adapter and ref/riscv-isa-sim) to compile and install Spike.

cd riscv-isa-sim-adapter # or cd riscv-isa-sim
mkdir build
cd build
../configure
make

Python libraries

DiveFuzz requires the installation of Python, pip, and the necessary Python libraries.

Assumes you have Python and pip installed, with a Python version of 3.10 or newer.Then install the necessary Python packages using pip:

cd DiveFuzz
pip install -r requirements.txt

Then, build the Spike C/C++ and python wrapper

cd ref/riscv-isa-sim-adapter/spike_engine
make

Environment Setup

REF Configuration

To ensure that the system can locate the spike executable you just built, you need to add its path to your shell's PATH variable.

# make sure you are in the DiveFuzz root directory, then run:
export PATH="$(pwd)/riscv-isa-sim-adapter/build:${PATH}"

Important: You need to re-run this command every time you open a new terminal session.

DUT Configuration

Enter your DUT directory and build the emulator with:

export NOOP_HOME="$(pwd)"
make emu

Usage Example

This project is adapted for the XiangShan processor developed by the Beijing Institute of Open Source Chip (BOSC). The following examples are based on XiangShan; usage on other CPUs is similar.

fuzzer/demo.yaml.dev is the configuration file for DiveFuzz. You can modify it to fit your needs. Then rename it to your_test.yaml and place it in the fuzzer directory.

# Device under test target config
dut_target:
# The name of the DUT target
- name: "XiangShan KMH DiveFuzz Inst 100"
  # How many threads to use
  threads: 16
  # The version of the DUT target
  version: commit:718a93f
  # Spike or NEMU or None
  diff_ref: Spike
  # The path of the DUT
  emu_path: /path/many_version/718a93f/XiangShan
  # Tell DiveFuzz how to run the DUT
  # notice: $1 is the input file
  cmd: ./build/emu -i $1  --diff /path/dut_fuzz/dut_instance/xs-env/XiangShan/ready-to-run/riscv64-spike-so

seeds:
- name: divefuzz_ins_10
  # Type of input for the seed. Allowed values: dir (directory input), divefuzz (DiveFuzz-formatted input), or leave unset for a single test case.
  input: divefuzz
  divefuzz:
    # TODO: Only generate seeds, do not deliver to DUT
    # gen_only: false
    # parallelism
    threads: 128
    # Whether to enable error elimination
    dive_enable: true
    # Generate or mutate
    mode: generate
    # Path to store seeds after generation/mutation
    seeds_output: /path/seeds_output_inst_100

    # The following features are only effective when the mode is set to generate
    # Number of seeds to generate
    seeds_num: 4
    # Number of instructions for each seed
    ins_num: 100
    # Special instruction generation for cva6
    is_cva6: false
    # Special instruction generation for rv32
    is_rv32: false
    template_type: 'xiangshan'
    # # The following features are only effective when the mode is set to mutate
    # # In mutation mode, the path to the initial corpus
    # mutate_input: /path/seeds_output_inst_100
    # # Enable instruction expansion mutation
    # enable_extension: true
    # # Excluded instruction extensions
    # exclude_extension: ['zicsr']
- name: dir_seeds
  # directory input
  input: dir
  # filter seeds by file suffix
  suffix: elf
  # the path of the directory
  path: /path/riscv_a

- name: seed_0
  # the path of the single test case
  path: /path/riscv_b/seed_0.elf

When you are ready to run DiveFuzz, run the following command:

cd fuzzer/
python run_dut.py --config your_test.yaml

After the execution is complete, you can find the results in the outputs directory.

DiveFuzz implements a three-tier logging system

1. DiveFuzz runtime logs
   Directly output during execution of run_dut.py

2. Seed configuration logs
   Stored at: outputs/{configuration_file}-{seed_profile_name}.log, like outputs/your_test_divefuzz_ins_10.log

3. Per-seed execution logs
   Stored at: outputs/{configuration_file}-{seed_profile_name}_{seed_basename}.log, like outputs/your_test-divefuzz_ins_10_seed_0_.elf.log

Affiliation

This project is developed by the Institute of Information Engineering, Chinese Academy of Sciences (CAS).

Citation

@inproceedings{guo2025divefuzz,
  title={DiveFuzz: Enhancing CPU Fuzzing via Diverse Instruction Construction},
  author={Guo, Zihui and Yuan, Miaomiao and Yang, Yanqi and Chen, Liwei and Shi, Gang and Meng, Dan},
  booktitle={Proceedings of the 2025 ACM SIGSAC Conference on Computer and Communications Security},
  pages={1964--1978},
  year={2025}
}
