Http Multipart Parser

| Release Notes| NuGet (stable) | MyGet (prerelease) | |--------------|----------------|--------------------| | | | |

About

The Http Multipart Parser does it exactly what it claims on the tin: parses multipart/form-data. This particular parser is well suited to parsing large data from streams as it doesn't attempt to read the entire stream at once and procudes a set of streams for file data.

Installation

The easiest way to include HttpMultipartParser in your project is by adding the nuget package to your project:

PM> Install-Package HttpMultipartParser

.NET framework suport

• The parser currently targets .NET Standard 2.0 and .NET 8.0.
• Version 5.1.0 was the last version that supported .NET 4.6.1, NET 4.7.2 and .NET standard 2.0.
• Version 2.2.4 was the last version that supported older .NET platforms such as .NET 4.5 and .NET standard 1.3.

Usage

Non-Streaming (Simple, don't use on very large files)

1. Parse the stream containing the multipart/form-data by invoking MultipartFormDataParser.Parse (or it's asynchronous counterpart MultipartFormDataParser.ParseAsync).
2. Access the data through the parser.

Streaming (Handles large files)

1. Create a new StreamingMultipartFormDataParser with the stream containing the multipart/form-data
2. Set up the ParameterHandler and FileHandler delegates
3. Call parser.Run() (or it's asynchronous counterpart parser.RunAsync())
4. The delegates will be called as data streams in.

Examples

Single file

// stream:
-----------------------------41952539122868
Content-Disposition: form-data; name="username"

example
-----------------------------41952539122868
Content-Disposition: form-data; name="email"

example@data.com
-----------------------------41952539122868
Content-Disposition: form-data; name="files[]"; filename="photo1.jpg"
Content-Type: image/jpeg

ExampleBinaryData012031203
-----------------------------41952539122868--

// ===== Simple Parsing ====
// You can parse synchronously:
var parser = MultipartFormDataParser.Parse(stream);

// Or you can parse asynchronously:
var parser = await MultipartFormDataParser.ParseAsync(stream).ConfigureAwait(false);

// From this point the data is parsed, we can retrieve the
// form data using the GetParameterValue method.
var username = parser.GetParameterValue("username");
var email = parser.GetParameterValue("email");

// Files are stored in a list:
var file = parser.Files.First();
string filename = file.FileName;
Stream data = file.Data;

// ==== Advanced Parsing ====
var parser = new StreamingMultipartFormDataParser(stream);
parser.ParameterHandler += parameter => DoSomethingWithParameter(parameter);
parser.FileHandler += (name, fileName, type, disposition, buffer, bytes, partNumber, additionalProperties) =>
{
    // Write the part of the file we've received to a file stream. (Or do something else)
    filestream.Write(buffer, 0, bytes);
};

// You can parse synchronously:
parser.Run();

// Or you can parse asynchronously:
await parser.RunAsync().ConfigureAwait(false);

Multiple Parameters

// stream:
-----------------------------41952539122868
Content-Disposition: form-data; name="checkbox"

likes_cake
-----------------------------41952539122868
Content-Disposition: form-data; name="checkbox"

likes_cookies
-----------------------------41952539122868--

// ===== Simple Parsing ====
// You can parse synchronously:
var parser = MultipartFormDataParser.Parse(stream);

// Or you can parse asynchronously:
var parser = await MultipartFormDataParser.ParseAsync(stream).ConfigureAwait(false);

// From this point the data is parsed, we can retrieve the
// form data from the GetParameterValues method
var checkboxResponses = parser.GetParameterValues("checkbox");
foreach(var parameter in checkboxResponses)
{
    Console.WriteLine("Parameter {0} is {1}", parameter.Name, parameter.Data)
}

Multiple Files

// stream:
-----------------------------41111539122868
Content-Disposition: form-data; name="files[]"; filename="photo1.jpg"
Content-Type: image/jpeg

MoreBinaryData
-----------------------------41111539122868
Content-Disposition: form-data; name="files[]"; filename="photo2.jpg"
Content-Type: image/jpeg

ImagineLotsOfBinaryData
-----------------------------41111539122868--

// ===== Simple Parsing ====
// You can parse synchronously:
var parser = MultipartFormDataParser.Parse(stream);

// Or you can parse asynchronously:
var parser = await MultipartFormDataParser.ParseAsync(stream).ConfigureAwait(false);

// Loop through all the files
foreach(var file in parser.Files)
{
    Stream data = file.Data;

    // Do stuff with the data.
}

// ==== Advanced Parsing ====
var parser = new StreamingMultipartFormDataParser(stream);
parser.ParameterHandler += parameter => DoSomethingWithParameter(parameter);
parser.FileHandler += (name, fileName, type, disposition, buffer, bytes, partNumber, additionalProperties) =>
{
    // Write the part of the file we've received to a file stream. (Or do something else)
    // Assume that filesreamsByName is a Dictionary<string, FileStream> of all the files
    // we are writing.
    filestreamsByName[name].Write(buffer, 0, bytes);
};
parser.StreamClosedHandler += ()
{
    // Do things when my input stream is closed
};

// You can parse synchronously:
parser.Run();

// Or you can parse asynchronously:
await parser.RunAsync().ConfigureAwait(false);

Licensing

This project is licensed under MIT.
