ioc2rpz™ makes your threat intelligence actionable

Short summary

ioc2rpz™: The DNS Security Solution - ioc2rpz™ is a powerful DNS server that transforms threat indicators into actionable Response Policy Zone (RPZ) feeds. It automates the update process, ensuring your network is protected against the latest threats, including malicious domains and IP addresses. By converting IOC feeds into RPZs, ioc2rpz™ acts as a crucial link between threat intelligence and DNS security, compatible with RPZ-supporting DNS servers like ISC Bind or PowerDNS. Learn more about how ioc2rpz™ can secure your network at ioc2rpz™ official website.

Overview

DNS is the control plane of the Internet. Usually DNS is used for good but:

• It can be used to track users locations and their behaviour;
• Malware uses DNS to command and control, exfiltrate data or redirect traffic;
• According with 2016 Cisco annual security report, 91.3% of malware use DNS;
• Advertisements companies usually use separate and obscure domains to show ads;
• Free DNS services (e.g. 1.1.1.1, 8.8.8.8, 9.9.9.9 etc) can help you to address some concerns but you can not define your own protection settings or ad filters.

<p align="center"><img src="https://github.com/Homas/ioc2rpz/blob/master/DNS_Malware.png"></p>

ISC Bind is a de facto a standard of a nameserver. With introduction of Response Policy Zones in the ISC BIND 9.8 it is became a simple task to monitor and contain malware on DNS layer. RPZ is supported on PowerDNS recursor 4.0.0 and later releases. Knot DNS is also partially supports RPZ.

In comparing with traditional network protection solutions a DNS server can handle millions of indicators without performance impact but there were no automated and efficient way to maintain response policy zones on primary DNS servers.

Usually indicators of compromise are distributed in plain text but in different formats and only a few providers of IOCs make them available via RPZ.

ioc2rpz™ is a custom DNS server which automatically converts indicators (e.g. malicious FQDNs, IPs) from various sources into RPZ feeds and automatically maintains/updates them. The feeds can be distributed to any open source and/or commercial DNS servers which support RPZ, e.g. ISC Bind, PowerDNS. You can run your own DNS server with RPZ filtering on a router, desktop, server and even Raspberry Pi. System memory is the only limitation.

With ioc2rpz™ you can define your own feeds, actions and prevent undesired communications.

ioc2rpz™ is a place where threat intelligence meets DNS

ioc2rpz™ transforms IOC feeds into response policy zones (RPZ). You can mix feeds to generate a single RPZ or multiple RPZs. Trusted domains and IPs can be whitelisted. ioc2rpz™ supports expiration of indicators and accordingly rebuilds zones.
The current release supports: local files, files/requests via http/https/ftp and shell scripts to access other resource types. You can use any file format if you can write a REGEX to extract indicators and indicators are separated by newline or/and return carriage chars (/n, /r, /r/n).

How to use ioc2rpz™

You can use ioc2rpz™ with any DNS server which supports Response Policy Zones e.g. recent versions of ISC BIND, PowerDNS and any commertial DNS server based on these products (e.g. Infoblox, Blue Cat, Efficient IP). A sample bind's configuration file (named.conf) is provided in the cfg folder.

<p align="center"><a href="http://www.youtube.com/watch?feature=player_embedded&v=bvhyMFa_mBM" target="_blank"><img src="https://github.com/Homas/ioc2rpz/blob/master/ioc2rpz_demo.png"></a></p>

ioc2rpz™ web interface

ioc2rpz.gui is a Management Web interface which is developed as a separate project. It is not required to run ioc2rpz™.

DNS over TLS (DoT)

ioc2rpz™ supports RPZ distribution over DoT. The SSL listener service is automatically started on port 853 (PortTLS) if a certificate is provided in the configuration (cert). Current implementation has following limitations:

• TLS 1.2 only;
• single request per session;
• TLS PIN is not supported;
• DNS Notify messages are unencrypted. When a certificate is expired or is going to expire soon there is no need to restart service if new certificates were saved in the same file. Erlang automatically updates certificates if files were replaced. The delay may be up to 2 minutes because of caching. It is recommended do not let the certificate to expire for service continuity.

ioc2rpz™ vs ISC BIND vs other DNS:

• ioc2rpz™ was built to handle RPZ distribution only;
• ioc2rpz™ supports DoT (DNS over TLS) so nobody can easily eavesdrop on your RPZs/indicators;
• ioc2rpz™ supports as many RPZs as you need;
• ioc2rpz™ supports live/non cached zones. It creates zones by an incoming request;
• indicators can be pulled from different sources and via different protocols (e.g. via REST API calls);
• RPZs are automatically updated;
• IOC expiration time is used to remove expired indicators in a timely manner;
• Performance and zone transfer time/size/packets optimizations.

Installation

The easiest way to deploy the service is using docker containers on the docker hub. Deployment on Docker How-To you can find in ioc2rpz™ wiki.

Docker container

ioc2rpz™ is available on the Docker Hub. Just look for ioc2rpz™. Prerequisites:

• ioc2rpz™ doesn't contain a configuration file, you need to mount /opt/ioc2rpz/cfg to a directory on a host system with the configuration file (ioc2rpz.conf);
• ioc2rpz™ uses 53/udp (SOA requests only), 53/tcp (AXFRP, IXFR, SOA, MGMT), 853/tcp (AXFRP, IXFR, SOA, MGMT) and 8443/tcp (REST API) ports. The ports should be exposed to a host system;
• ioc2rpz™ saves ETS database into files for faster boot. You may mount /opt/ioc2rpz/db to a directory on a host system to preserve DB over restarts; You can start ioc2rpz™ with the following command:

sudo docker run -d --name ioc2rpz --log-driver=syslog --restart always --mount type=bind,source=/home/ioc2rpz/cfg,target=/opt/ioc2rpz/cfg --mount type=bind,source=/home/ioc2rpz/db,target=/opt/ioc2rpz/db -p53:53 -p53:53/udp -p853:853 -p8443:8443 pvmdel/ioc2rpz

where /home/ioc2rpz/cfg, /home/ioc2rpz/db directories on a host system.
You can pass a custom configuration file name via-e parameter. E.g. ./cfg/ioc2rpz2.conf

Docker Compose

You can deploy ioc2rpz™ and ioc2rpz.gui using docker compose. The docker-compose.yml file can be found in ioc2rpz.dc repository.

ioc2rpz™ on AWS

You can run ioc2rpz™ and ioc2rpz.gui on AWS. For relatively small deployments (several hundreds thousands indicators) even free tier is enough. The video below shows how to setup ioc2rpz™ and ioc2rpz.gui on AWS using ECS.

<p align="center"><a href="http://www.youtube.com/watch?feature=player_embedded&v=C-y4p5TXt8s" target="_blank"><img src="https://github.com/Homas/ioc2rpz/blob/master/ioc2rpz_aws_setup.png"></a></p>

How to start ioc2rpz™ service (w/o docker)

ioc2rpz™ by default reads configuration from ./cfg/ioc2rpz.conf, listens on all network interfaces and saves DB backup in ./db directory. You can change the default values in include/ioc2rpz.hrl.
If you downloaded sources, before running ioc2rpz™ you have to compile the code with the following command: rebar3 release.
You can start the application by evoking _build/default/rel/ioc2rpz/bin/ioc2rpz start.

ioc2rpz™ management

via DNS

ioc2rpz™ supports management over DNS/TCP or DoT. It is recommended to use DoT or REST API over DNS/TCP. The current version of ioc2rpz™ does not support a separate management IP/interface. In any case it is highly recommended to create a designated TSIG key (or keys) which will be used for management only. You can turn off management over DNS.
Supported actions:

• ioc2rpz™ current status. Request ioc2rpz-status, class CHAOS, record TXT. e.g.:

dig +tcp -y dnsmkey_1:ayVnL+h2QKMszRVohrngagcEuIpN3RkecXKdwSa5WsHD5N4Y5R3NUMGM W8sIGv36gPkAtWtgarqKzN9tmHqEnA== @127.0.0.1 ioc2rpz-status TXT -c CHAOS

• Reload configuration file. RR Name ioc2rpz-reload-cfg, RR Class CHAOS, RR Type TXT
• Update TSIG keys. RR Name ioc2rpz-update-tkeys, RR Class CHAOS, RR Type TXT
• Full refresh of all zones. RR Name ioc2rpz-update-all-rpz, RR Class CHAOS, RR Type TXT
• Full refresh a zone. RR Name zone_name, RR Class CHAOS, RR Type TXT. E.g. full refresh of dga.ioc2rpz can be invoked by:

dig +tcp -y dnsmkey_1:ayVnL+h2QKMszRVohrngagcEuIpN3RkecXKdwSa5WsHD5N4Y5R3NUMGM W8sIGv36gPkAtWtgarqKzN9tmHqEnA== @127.0.0.1 dga.ioc2rpz TXT -c CHAOS

• Stop ioc2rpz™. RR Name ioc2rpz-terminate, RR Class CHAOS, RR Type TXT
• Request a sample zone. RR Name sample-zone.ioc2rpz, RR Class IN, RR Type AXFR

via REST

REST API (port 8443/tcp) is the preffered management interface. For serurity reasons all management traffic must be encrypted and REST API interface is not started if there is no SSL certificate. Basic HTTP authentication is used to authenticate requests. ManagementTSIG keys are used for request authentication. A TSIG key name is used as the HTTP username and TSIG key as the password. Access to the REST API is restricted with the ACL.
The REST API supports json (default) and text as an output format based on the "Accept" header. E.g.:

curl -i -u "dnsmkey_1:ayVnL+h2QKMszRVohrngagcEuIpN3RkecXKdwSa5WsHD5N4Y5R3NUMGM W8sIGv36gPkAtWtgarqKzN9tmHqEnA==" --insecure -H "Accept: text/plain" https://127.0.0.1:8443/api/mgmt/update_tkeys

API requests:

• GET /api/v1.0/update/all_rpz - full refresh of all zones.
• GET /api/v1.0/update/:rpz - full refre
