TianJi: Highly Parallelized Reinforcement Learning Training with Relaxed Assignment Dependencies

<img src="https://img.shields.io/badge/license-Apache_2.0-blue">

📄<a href="http://arxiv.org/abs/2502.20190">arXiv</a>

TianJi is an effective, scalable and highly parallel reinforcement learning training system. TianJi supports building distributed training tasks with simple configuration files, providing users with a universal API to define environments and algorithms, and even allowing users to freely use system components to design distributed training.

Installation

First, install Python packages using pip:

pip install -r requirements.txt

Second, install communication package which is in pkgs folder:

cd pkgs
pip install hiprlcomm-0.0.1-py3-none-any.whl

Finally, install the MPI library, one can choose to install OpenMPI or MPICH. For example, with the Ubuntu system install OpenMPI, one can use this command:

sudo apt update
sudo apt install openmpi-bin openmpi-common libopenmpi-dev

To install more training scenarios, see Env doc.

Get started

Reinforcement learing algorithms adapted in TianJi are located under scripts folder. Using a simple DQN training as an example to demonstrate how to use TianJi, one can use the command line:

python scripts/train.py --source config/dqn/cartpole_config.py --exp-name dqn_test

The training results are redirected and output under experiments folder when one successfully starts training.

Distributed training

TianJi decoupled computing components on hardware for how reinforcement learning algorithms are executed in a distributed way.

Take the simple dqn for example:

mpirun -np 6 python scripts/train.py --source config/dqn/cartpole_distribution.py --exp-name dqn_dist

The number after -np is the process number (N for short) related to the configuration parallel_parameters. This number involves a simple calculation: N = learner_num + actor_num + buffer_num.

In this mode, the learner_num and buffer_num are specified as 1.

If you want to do outward bound on a larger scale, e.g. to increase the number of learner, add the computational Group parameter to the configuration file.

    global_cfg = dict(
        use_group_parallel = True,
        group_num = N
    )

Training Command:

mpirun -np 21 python scripts/train.py --source config/dqn/cartpole_group_distribution.py --exp-name dqn_dist

The group number (group_num for short) represents scaling to N computing groups. In each group, it contains multiple roles. Therefore, the process number N is equal to group_num * (learner_num + actor_num + buffer_num) + 1.

Code Structure

• config: Configuration files for algorithms and environments.
• scripts: Main entry.
• drl: Model、algorithms and policy implemented using system API.
• env: An environment implemented with the system API.
• pkgs: System dependency packages.
• utils: The system function module provides some important components of the system.
• docs: Documentation.

For algorithm developers

• environment, If you want to add a customized environment, Inheritance uses the system BaseEnv API, see more Env doc.
• algorithm, If you want to add a customized algorithm, you need to know Agent、Embryo and Model three system API, see more algorithm doc.

Citation

If you find our work helpful, feel free to give us a cite.

@inproceedings{
  title={Highly Parallelized Reinforcement Learning Training with Relaxed Assignment Dependencies},
  author={Zhouyu He and Peng Qiao and Rongchun Li and Yong Dou and Yusong Tan},
  booktitle={Proceedings of the Thirty-Ninth AAAI Conference on Artificial Intelligence},
  year={2025}
}

License

Apache License 2.0
