SolidGeo: Measuring Multimodal Spatial Math Reasoning in Solid Geometry

[🌐 Homepage] [💻 Github] [🤗 Huggingface Dataset]
[📊 Leaderboard ] [🔍 Visualization] [📖 Paper]

<div style="display: flex; justify-content: center;"> <img src="assets/LOGO.png" alt="LOGO" height="300"> </div>

Dataset Description

SolidGeo is the first large-scale benchmark specifically designed to evaluate the performance of MLLMs on mathematical reasoning tasks in solid geometry. SolidGeo consists of 3,113 real-world K–12 and competition-level problems, each paired with visual context and annotated with 3 difficulty levels and 8 fine-grained solid geometry categories. Our benchmark covers a wide range of 3D reasoning subjects such as projection, unfolding, spatial measurement, and spatial vector, offering a rigorous testbed for assessing solid geometry.Through extensive experiments, we observe that MLLMs encounter substantial challenges in solid geometry math tasks, with a considerable performance gap relative to human capabilities on SolidGeo .We hope SolidGeo serves as a catalyst for advancing MLLMs toward deeper geometric reasoning and spatial intelligence.

Performance of six MLLMs on SolidGeo benchmark across 8 solid geometry subjects (left), and trade-off between accuracy and average generated token length across 25 MLLMs (right).

Dataset Examples

Some examples of our datasets.

Click to expand/collapse more examples

<details> <summary>Measurement of Solid Geometric Forms</summary><p align="center"> <img src="assets/Measurement of Solid Geometric Forms.jpg" width="50%"> <br> </p></details> <details> <summary>Solid Shape Identification</summary><p align="center"> <img src="assets/Solid Shape Identification.jpg" width="50%"> <br> </p></details> <details> <summary>Spatial Metric Relations</summary><p align="center"> <img src="assets/Spatial Metric Relations.jpg" width="50%"> <br> </p></details> <details> <summary>Multi-view Projection</summary><p align="center"> <img src="assets/Multi-view Projection.jpg" width="50%"> <br> </p></details> <details> <summary>Planar Unfolding and Configuration</summary><p align="center"> <img src="assets/Planar Unfolding and Configuration.jpg" width="50%"> <br> </p></details> <details> <summary>Composite Solid Structures</summary><p align="center"> <img src="assets/Composite Solid Structures.jpg" width="50%"> <br> </p></details> <details> <summary>3D Coordinate and Vector Reasoning</summary><p align="center"> <img src="assets/3D Coordinate and Vector Reasoning.jpg" width="50%"> <br> </p></details> <details> <summary>Solid Geometry Modeling</summary><p align="center"> <img src="assets/Solid Geometry Modeling.jpg" width="50%"> <br> </p></details>

Data Format

{
  "question": [string] The question text.
  "choices": [list of string] Choice options for some questions.
  "image": [list of string] A list of image file paths used in the question text.
  "answer": [string] The final answer to the question, provided in LaTeX format for consistent mathematical formatting.
  "solution": [list of string] A Optional list of solution steps.
  "answer_type": [string] The format of the answer:"single_step", "multi_step", "choice"
  "problem_type": [list of strings] A classification of the type of math problem :"Measurement of Solid Geometric Forms","Solid Shape Identification","Spatial Metric Relations","Multi-view Projection","Planar Unfolding and Configuration","Composite Solid Structures","3D Coordinate and Vector Reasoning","Solid Geometry Modeling".
  "complexity_level": [string] An indicator of the difficulty level:"Level 1","Level 2","Level 3"
  "source": [string] The origin of the question.
  "qa_id": [integer] A unique identifier for the question-answer pair.
}

Citation

If you find this work useful, welcome to cite/star us.

@misc{wang2025solidgeomeasuringmultimodalspatial,
      title={SOLIDGEO: Measuring Multimodal Spatial Math Reasoning in Solid Geometry},
      author={Peijie Wang and Chao Yang and Zhong-Zhi Li and Fei Yin and Dekang Ran and Mi Tian and Zhilong Ji and Jinfeng Bai and Cheng-Lin Liu},
      year={2025},
      eprint={2505.21177},
      archivePrefix={arXiv},
      primaryClass={cs.CG},
      url={https://arxiv.org/abs/2505.21177},
}
