Beamforming Simulator

This project is a Beamforming Simulator that visualizes the beamforming process using a heatmap and beam profile. The simulator allows users to configure various parameters such as the number of antennas, distance between antennas, delay between antennas, and array geometry.

Features

• Heatmap Visualization: Displays the intensity of the beamforming pattern on a 2D grid.
• Beam Profile Visualization: Shows the beam pattern on a polar plot.
• Antenna Configuration:
  • Adjust the number of antennas.
  • Set the distance between antennas.
  • Configure the delay between antennas in degrees.
  • Select the array geometry (Linear or Curved).
  • Adjust the curvature for curved arrays.
• Frequency Configuration:
  • Set a global frequency for all antennas.
  • Adjust individual frequencies for each antenna.
• Position Configuration:
  • Manually adjust the x and y positions of each antenna.
• Predefined Scenarios: Load predefined scenarios from JSON files for 5G, Tumor Ablation, and Ultrasound applications.
• Dynamic Updates: Real-time updates of the heatmap and beam profile as parameters are adjusted.

<video src="https://github.com/user-attachments/assets/c76ef5bb-a84c-4eb0-b62f-c78e663dd723"></video>

Requirements

• Python
• PyQt5
• Matplotlib
• NumPy

Installation

1. Clone the repository:


   git clone https://github.com/HarmoniCode/BeamForming.git
   cd BeamForming/




2. Install the required packages:

   pip install -r requirements.txt


Usage

1. Run the main script:

   python main.py


2. Use the GUI to configure the beamforming parameters and visualize the results.

License

This project is licensed under the MIT License. See the LICENSE file for details.
