ZMap SDK

A Python SDK for the ZMap network scanner that provides an easy-to-use interface for network scanning operations with REST API support.

Installation

Prerequisites

• Python 3.6 or higher
• ZMap installed on your system - ZMap Installation Guide

Installing the SDK

pip install zmapsdk

Or install from source:

git clone https://github.com/HappyHackingSpace/ZmapSDK
cd zmapsdk
pip install .

Quick Start

from zmapsdk import ZMap

# Initialize the ZMap SDK
zmap = ZMap()  # Uses 'zmap' from PATH by default

# Run a basic scan on port 80
results = zmap.scan(
    target_port=80,
    subnets=["192.168.1.0/24"],  # Scan your local network
    bandwidth="1M"  # Limit bandwidth to 1 Mbps
)

# Print the results
print(f"Found {len(results)} open ports")
for ip in results:
    print(f"Open port at: {ip}")

# Create a blocklist
zmap.create_blocklist_file(["192.168.0.0/16", "10.0.0.0/8"], "private_ranges.txt")

# Generate a standard blocklist
zmap.generate_standard_blocklist("standard_blocklist.txt")

Core Components

The ZMap SDK consists of several core components:

• ZMap: The main class that provides the interface to ZMap
• ZMapScanConfig: Handles scan configuration parameters
• ZMapInput: Manages input sources (subnets, allowlists, blocklists)
• ZMapOutput: Controls output formatting and destinations
• ZMapRunner: Executes ZMap commands and captures results
• ZMapParser: Parses ZMap output into structured data

Basic Usage

Specifying a Custom ZMap Path

from zmapsdk import ZMap

# Initialize with custom path to the ZMap executable
zmap = ZMap(zmap_path="/usr/local/bin/zmap")

# Run scan as usual
results = zmap.scan(target_port=80, subnets=["192.168.0.0/24"])

Scanning a Specific Port

from zmapsdk import ZMap

zmap = ZMap()
results = zmap.scan(target_port=443, subnets=["10.0.0.0/8"])

Configuring Bandwidth and Rate

from zmapsdk import ZMap, ZMapScanConfig

# Option 1: Configure via parameters
results = zmap.scan(
    target_port=22,
    bandwidth="10M",  # 10 Mbps
    subnets=["192.168.0.0/16"]
)

# Option 2: Configure via config object
config = ZMapScanConfig(
    target_port=22,
    bandwidth="10M"
)
zmap = ZMap()
zmap.config = config
results = zmap.scan(subnets=["192.168.0.0/16"])

Specifying Output File

from zmapsdk import ZMap

zmap = ZMap()
results = zmap.scan(
    target_port=80,
    subnets=["172.16.0.0/12"],
    output_file="scan_results.csv"
)

Using Blocklists and Allowlists

from zmapsdk import ZMap

zmap = ZMap()

# Using a blocklist file
zmap.blocklist_from_file("/path/to/blocklist.txt")

# Creating a blocklist file
zmap.create_blocklist_file(
    subnets=["10.0.0.0/8", "192.168.0.0/16"],
    output_file="private_ranges.conf"
)

# Using a allowlist file
zmap.allowlist_from_file("/path/to/allowlist.txt")

# Run scan with blocklist
results = zmap.scan(
    target_port=443,
    blocklist_file="private_ranges.conf"
)

Controlling Scan Behavior

from zmapsdk import ZMap

zmap = ZMap()
results = zmap.scan(
    target_port=80,
    max_targets=1000,      # Limit to 1000 targets
    max_runtime=60,        # Run for max 60 seconds
    cooldown_time=5,       # Wait 5 seconds after sending last probe
    probes=3,              # Send 3 probes to each IP
    dryrun=True            # Don't actually send packets (test mode)
)

Advanced Configuration

from zmapsdk import ZMap, ZMapScanConfig

# Create configuration
config = ZMapScanConfig(
    target_port=443,
    bandwidth="100M",
    interface="eth0",
    source_ip="192.168.1.5",
    source_port="40000-50000",  # Random source port in range
    max_targets="10%",          # Scan 10% of address space
    sender_threads=4,           # Use 4 threads for sending
    notes="HTTPS scanner for internal audit",
    seed=123456                 # Set random seed for reproducibility
)

# Initialize ZMap with configuration
zmap = ZMap()
zmap.config = config

# Run scan
results = zmap.scan(subnets=["10.0.0.0/16"])

Processing Results

Parsing Results

from zmapsdk import ZMap

zmap = ZMap()

# Run scan and save results
zmap.scan(
    target_port=22,
    subnets=["192.168.1.0/24"],
    output_file="scan_results.csv",
    output_fields=["saddr", "daddr", "sport", "dport", "classification"]
)

# Parse the results file
parsed_results = zmap.parse_results("scan_results.csv")

# Process the structured data
for result in parsed_results:
    print(f"Source IP: {result['saddr']}, Classification: {result['classification']}")

# Extract just the IPs
ip_list = zmap.extract_ips(parsed_results)

Working with Large Result Sets

from zmapsdk import ZMap

zmap = ZMap()

# For large scans, stream the results instead of loading all at once
for result in zmap.stream_results("large_scan_results.csv"):
    process_result(result)  # Your processing function

# Count results without loading everything
count = zmap.count_results("large_scan_results.csv")
print(f"Found {count} results")

REST API

ZMap SDK includes a REST API that allows you to control ZMap operations remotely.

Starting the API Server

You can start the API server in two ways:

From Command Line

# Start API server on default host (127.0.0.1) and port (8000)
zmapsdk api

# Start API server with custom host and port
zmapsdk api --host 0.0.0.0 --port 9000

# Start API server with verbose logging
zmapsdk api -v

From Python

from zmapsdk import APIServer

# Create and start the API server
server = APIServer(host="0.0.0.0", port=8000)
server.run()

API Endpoints

The REST API provides the following endpoints:

| Endpoint | Method | Description | |----------|--------|-------------| | / | GET | Basic information about the API | | /probe-modules | GET | List available probe modules | | /output-modules | GET | List available output modules | | /output-fields | GET | List available output fields for a probe module | | /interfaces | GET | List available network interfaces | | /scan-sync | POST | Run a scan synchronously and return results | | /blocklist | POST | Create a blocklist file from a list of subnets | | /standard-blocklist | POST | Generate a standard blocklist file | | /allowlist | POST | Create an allowlist file from a list of subnets |

API Documentation

The API includes automatic documentation using Swagger UI and ReDoc:

• Swagger UI: http://localhost:8000/docs
• ReDoc: http://localhost:8000/redoc

Example API Requests

Basic Information

curl -X GET "http://localhost:8000/"

Response:

{
  "name": "ZMap SDK API",
  "version": "2.1.1",
  "description": "REST API for ZMap network scanner"
}

List Available Probe Modules

curl -X GET "http://localhost:8000/probe-modules"

Response:

["tcp_synscan", "icmp_echoscan", "udp", "module_ntp", "module_dns"]

List Available Output Modules

curl -X GET "http://localhost:8000/output-modules"

Response:

["csv", "json", "extended_file", "redis"]

List Available Network Interfaces

curl -X GET "http://localhost:8000/interfaces"

Response:

["eth0", "lo", "wlan0"]

Run a Scan

curl -X POST "http://localhost:8000/scan-sync" \
  -H "Content-Type: application/json" \
  -d '{
    "target_port": 80,
    "bandwidth": "10M",
    "probe_module": "tcp_synscan",
    "return_results": true
  }'

Response:

{
  "scan_id": "direct_scan",
  "status": "completed",
  "ips_found": ["192.168.1.1", "192.168.1.2", "10.0.0.1"]
}

Create a Blocklist

curl -X POST "http://localhost:8000/blocklist" \
  -H "Content-Type: application/json" \
  -d '{
    "subnets": ["192.168.0.0/16", "10.0.0.0/8"]
  }'

Response:

{
  "file_path": "/tmp/zmap_blocklist_a1b2c3.txt",
  "message": "Blocklist file created with 2 subnets"
}

Generate a Standard Blocklist

curl -X POST "http://localhost:8000/standard-blocklist" \
  -H "Content-Type: application/json" \
  -d '{}'

Response:

{
  "file_path": "/tmp/zmap_std_blocklist_x1y2z3.txt",
  "message": "Standard blocklist file created"
}

Create an Allowlist

curl -X POST "http://localhost:8000/allowlist" \
  -H "Content-Type: application/json" \
  -d '{
    "subnets": ["1.2.3.0/24", "5.6.7.0/24"],
    "output_file": "my_allowlist.txt"
  }'

Response:

{
  "file_path": "my_allowlist.txt",
  "message": "Allowlist file created with 2 subnets"
}

API Reference

ZMap Class

The main interface for the ZMap SDK.

Methods

• scan(target_port, subnets, output_file, **kwargs): Perform a scan and return the results
• run(**kwargs): Run ZMap with specified parameters
• get_probe_modules(): Get list of available probe modules
• get_output_modules(): Get list of available output modules
• get_output_fields(probe_module): Get list of available output fields
• get_interfaces(): Get list of available network interfaces
• get_version(): Get ZMap version
• blocklist_from_file(blocklist_file): Validate and use a blocklist file
• allowlist_from_file(allowlist_file): Validate and use a allowlist file
• create_blocklist_file(subnets, output_file): Create a blocklist file
• create_allowlist_file(subnets, output_file): Create a allowlist file
• `create_target_f
