PyPathomics

<a href="https://github.com/HaoyuCui/PyPathomics?tab=GPL-3.0-1-ov-file"> <img align="right", src="https://img.shields.io/badge/License-GPL-blue.svg"> </a> <a href="https://imic.nuist.edu.cn/"> <img align="right", src="https://img.shields.io/static/v1?label=Org&message=iMIC&color=green"/> </a>

PyPathomics is an open-source software for gigapixel whole-slide image analysis. Off-the-shelf and easy-to-use.

<a href="https://zenodo.org/records/15164919"> <img align="right", src="https://zenodo.org/badge/DOI/10.5281/zenodo.15164919.svg"/> </a>

Currently under development. This is a simplified version of [sc_MTOP] [Paper]

Support for:

• [x] Hover-Net [Repo] [Paper] (Graham et al., 2019)

• [x] Cerberus (In Beta) [Repo] [Paper] (Graham et al., 2023)

Feature-sets

PyPthomics supports [a] Cell Ratio, [b] Morphological Features, [c] Texture Features, and [d] Spatial Features (Delaunay Triangle).

How it works?

<div align=center> <img width="960" alt="image" src="https://github.com/user-attachments/assets/11098570-4939-4bb9-9080-7e2dbe3bc68c"> </div>

Get all cell and slide-level features directly through the cell segmentation file like Hover-Net's .json file.

Installation

conda create -n pypathomics
conda activate pypathomics
pip install -r requirements.txt

Options and Usage

Options:

Options for config.yaml

   openslide-home: path\to\openslide-home # for Windows only
   feature-set: ['Morph', 'Texture', 'Triangle']
   cell_types: ['I', 'S', 'T']
   statistic-types: ['basic', 'distribution']

Where,

• openslide-home: Specifies the path to the OpenSlide library. (for Windows only, leave it empty for Linux)
• feature-set: A list of feature sets to extract. Options: Morph, Texture, Triangle.
• cell_types: Types of cells to analyze. Options: I (inflammatory), S, (stromal), T (tumor).
• statistic-types: Types of statistics to calculate. Options: basic, distribution.

| statistics-types | e.g. | |------------------|--------------------------------------------------| | basic | mean, std | | distribution | Q25, Q75, median, IQR, range, skewness, kurtosis |

Options for main.py

Required Arguments:

    --config     Specify the configuration file path
    --seg        Path to the segmentation directory or file from Hover-Net(.json) or Cerberus(.dat)
    --wsi        Path to the WSI directory or file
    --ext        WSI file extension (default: .svs or svs)
    --buffer     Specify the output buffer dir for preprocessing
    --output     Set the output directory for the analysis

Optional Arguments:

    -f           Run for a single file (default: run for directory)
    --auto_skip  Skip existing directories automatically (default: True)
    --level      Detail level of the WSI to analyze (default: 0)

Usage:

1. Make sure you run the Hover-Net's wsi seg or Cerberus' wsi seg and get the seg files.

2. Modify and check the config.yaml before running.

3. Analyze a Directory:

   python main.py --seg /path/to/seg_dir --wsi /path/to/wsi_dir --buffer /path/to/buffer --ext .svs --output /path/to/output.csv


4. Analyze a Single File

   python main.py -f --seg /path/to/seg_file --wsi /path/to/wsi_file --buffer /path/to/buffer --ext .svs --output /path/to/output.csv


All-cell Info, stored in /path/to/buffer

| Feature | Description | e.g. | |---------------|-----------------------------|---------------------------| | Name | Identifier of the cell | 7, 42, 113, ... | | Centroid | Position of the cell | [1676.85, 12851.68], ... | | Cell Type | Cell type in numeric coding | 0, 1, 0, ... |

Different cell types will be stored in different files. Each file could be hundreds or thousands MBs in size as they stored all cells' information.

Feature-sets Explanation

<details> <summary><strong>Slide Cell Ratio</strong></summary>

• Ratio: Reflects the proportion of cells of this type.

</details> <details> <summary><strong>Morphological Features</strong></summary>

• Area: Area of the cell, indicating cell size.
• AreaBbox: Area of the minimum bounding rectangle around the cell.
• CellEccentricities: Eccentricity of the cell.
• Circularity: Roundness of the cell.
• Elongation: Elongation rate of the cell.
• Extent: Proportion of the cell occupying its bounding rectangle.
• MajorAxisLength / Morph_MinorAxisLength: Lengths of the major and minor axes of the fitted ellipse for the cell.
• Perimeter: Perimeter of the cell boundary.
• Solidity: Ratio of the cell area to its convex hull area.
• CurvMean / Std / Max / Min: Mean, standard deviation, maximum, and minimum of the cell boundary curvature.

</details> <details> <summary><strong>Texture Features</strong></summary>

• ASM (Angular Second Moment): Texture consistency, measuring the similarity between a pixel and its neighbors.
• Contrast: Texture contrast, describing the intensity variation in the image.
• Correlation: Texture correlation, measuring the similarity between a pixel and its neighbors.
• Entropy: Texture entropy, representing the diversity of information in the image; higher values indicate more complex textures.
• Homogeneity: Texture homogeneity, assessing the consistency of the texture.
• IntensityMean / Std / Max / Min: Mean, standard deviation, maximum, and minimum of the texture intensity.

</details> <details> <summary><strong>Delaunay Triangle Spatial Features</strong></summary>

• Area: Area of the Delaunay triangle around the cell.
• Perimeter: Perimeter of the Delaunay triangle around the cell.
• Angle_Range: Difference between the maximum and minimum angles of the Delaunay triangle around the cell.

</details>

Citation

If you find our work useful in your research, please consider citing our Zenodo record:

@software{pypathomics,
  author       = {HY Cui and XX Wang and J Xu and DP Chen},
  title        = {PyPathomics},
  year         = 2024,
  publisher    = {GitHub},
  url          = {https://github.com/HaoyuCui/PyPathomics},
  version      = {1.0},
  doi          = {10.5281/zenodo.15164919},
  howpublished = {\url{https://zenodo.org/record/15164919}},
}
