CAPTRA: CAtegory-level Pose Tracking for Rigid and Articulated Objects from Point Clouds (ICCV 2021, Oral)

Introduction

This is the official PyTorch implementation of our paper CAPTRA: CAtegory-level Pose Tracking for Rigid and Articulated Objects from Point Clouds.

For more information, please visit our project page.

<span class="center"><img src="images/bmvc_ours.gif" width="45%"> <img src="images/real_drawers_ours.gif" width="45%"></span>

<p style="text-align: left; width: 90%; margin-left: 0%"><b>Result visualization on real data.</b> Our models, trained on synthetic data only, can directly generalize to real data, assuming the availability of object masks but not part masks. Left: results on a laptop trajectory from BMVC dataset. Right: results on a real drawers trajectory we captured, where a Kinova Jaco2 arm pulls out the top drawer.</p>

Citation

If you find our work useful in your research, please consider citing:

@inproceedings{weng2021captra,
	title={CAPTRA: CAtegory-level Pose Tracking for Rigid and Articulated Objects from Point Clouds},
	author={Weng, Yijia and Wang, He and Zhou, Qiang and Qin, Yuzhe and Duan, Yueqi and Fan, Qingnan and Chen, Baoquan and Su, Hao and Guibas, Leonidas J.},
	booktitle={Proceedings of the IEEE International Conference on Computer Vision (ICCV)},
    	month={October},
	year={2021},
    	pages={13209-13218}
}

Updates

• [2021/04/14] Released code, data, and pretrained models for testing & evaluation.
• [2021/04/22] Released code and data for training.
• [2021/07/22] Our paper has been accepted by ICCV 2021 as an oral presentation!
• [2021/10/24] Released code for visualization.

Installation

• Our code has been tested with

  • Ubuntu 16.04, 20.04, and macOS(CPU only)
  • CUDA 11.0
  • Python 3.7.7
  • PyTorch 1.6.0

• We recommend using Anaconda to create an environment named captra dedicated to this repository, by running the following:

  conda create -n captra python=3.7
  conda activate captra


• Create a directory for code, data, and experiment checkpoints.

  mkdir captra && cd captra


• Clone the repository

  git clone https://github.com/HalfSummer11/CAPTRA.git
  cd CAPTRA


• Install dependencies.

  pip install -r requirements.txt


• Compile the CUDA code for PointNet++ backbone.

  cd network/models/pointnet_lib
  python setup.py install


Datasets

• Create a directory for all datasets under captra

  mkdir data && cd data


  • Make sure to point basepath in CAPTRA/configs/obj_config/obj_info_*.yml to your dataset if you put it at a different location.

NOCS-REAL275

mkdir nocs_data && cd nocs_data

Test

• Download and unzip nocs_model_corners.tar, where the 3D bounding boxes of normalized object models are saved.

  wget http://download.cs.stanford.edu/orion/captra/nocs_model_corners.tar
  tar -xzvf nocs_real_corners.tar


• Create nocs_full to hold original NOCS data. Download and unzip "Real Dataset - Test" from the original NOCS dataset, which contains 6 real test trajectories.

  mkdir nocs_full && cd nocs_full
  wget http://download.cs.stanford.edu/orion/nocs/real_test.zip
  unzip real_test.zip


• Generate and run the pre-processing script

  cd CAPTRA/datasets/nocs_data/preproc_nocs
  # generate the script for data preprocessing
  # parallel & num_proc specifies the number of parallel processes in the following procedure
  python generate_all.py --data_path ../../../../data/nocs_data --data_type=test_only \
  			 --parallel --num_proc=10 > nocs_preproc.sh
  # the actual data preprocessing
  bash nocs_preproc.sh


• After the steps above, the folder should look like File Structure - Dataset Folder Structure.

Train

• Download and unzip "CAMERA Dataset - Training/Test" and "Real Dataset - Training" from the original NOCS dataset under nocs_data/nocs_full

  # current path relative to project root (captra): data/nocs_data/nocs_full
  wget http://download.cs.stanford.edu/orion/nocs/camera_train.zip
  unzip camera_train.zip
  wget http://download.cs.stanford.edu/orion/nocs/camera_val25K.zip
  unzip camera_val25K.zip
  wget http://download.cs.stanford.edu/orion/nocs/real_train.zip
  unzip real_train.zip


  • By now, nocs_full should be structured as follows. Note that the depth image (*_depth.png) only contains the synthetic foreground objects. For our purpose, we need a complete depth image composing both the synthetic foreground and the real background.

    nocs_full
    ├── real_test
    ├── real_train
    ├── train
    │   ├── 00000
    │   │   ├── 0000_color.png, 0000_coord.png, 0000_depth.png, 0000_mask.png, 0000_meta.txt
    │   │   ├── 0001_color.png, ...
    │   │   └── ...
    │   ├── 00001
    │   └── ...
    └── val				# same structure as train


• Download and unzip "CAMERA Dataset - Composed_depths" from the original NOCS dataset under nocs_data.

  cd ../ # current path relative to project root (captra): data/nocs_data
  wget http://download.cs.stanford.edu/orion/nocs/camera_composed_depth.zip
  unzip camera_composed_depth.zip


  This will result in a folder named camera_full_depths, structured as follows.

  camera_full_depths
  ├── train
  │   ├── 00000
  │   │   ├── 0000_composed.png # depth image containing both synthetic foreground objects
  │   │   │		        # and the real background
  │   │   ├── 0001_composed.png # rendered object normalized coordinates
  │   │   └── ...
  │   ├── 00001
  │   └── ...
  └── val				# same structure as train


  Then copy-merge camera_full_depths with nocs_full.

  # merge camera_full_depth/train/????? to nocs_full/train/?????
  rsync -arv camera_full_depths/ nocs_full/
  rm -r camera_full_depths


• Generate and run the pre-processing script

  cd CAPTRA/datasets/nocs_data/preproc_nocs
  python generate_all.py --data_path ../../../../data/nocs_data --data_type=all --parallel --num_proc=10 > nocs_preproc_all.sh # generate the script for data preprocessing
  # parallel & num_proc specifies the number of parallel processes in the following procedure
  bash nocs_preproc_all.sh # the actual data preprocessing


• After the steps above, the folder should look like [File Structure - Dataset Folder Structure](#File Structure).

SAPIEN Synthetic Articulated Object Dataset

mkdir sapien_data && cd sapien_data

Test

• Download and unzip object URDF models and testing trajectories

  wget http://download.cs.stanford.edu/orion/captra/sapien_urdf.tar
  wget http://download.cs.stanford.edu/orion/captra/sapien_test.tar
  tar -xzvf sapien_urdf.tar # urdf
  tar -xzvf sapien_test.tar # render_seq


Train

• Download and unzip training data.

  wget http://download.cs.stanford.edu/orion/captra/sapien_train.tar
  tar -xzvf sapien_train.tar # render


Testing & Evaluation

Download Pretrained Model Checkpoints

• Create a folder runs under captra for experiments

  mkdir runs && cd runs


• Download our pretrained model checkpoints for

  • NOCS-REAL275: nocs_ckpt.tar
  • SAPIEN synthetic articulated object dataset: sapien_ckpt.tar

• Unzip them in runs

  tar -xzvf nocs_ckpt.tar


  which should give

  runs
  ├── 1_bottle_rot 	# RotationNet for the bottle category
  ├── 1_bottle_coord 	# CoordinateNet for the bottle category
  ├── 2_bowl_rot
  └── ...


Testing

• To generate pose predictions for a certain category, run the corresponding script in CAPTRA/scripts/track (without further specification, all scripts are run from CAPTRA), e.g. for the bottle category from NOCS-REAL275,

  bash scripts/track/nocs/1_bottle.sh


• The predicted pose will be saved under the experiment folder 1_bottle_rot (see File Structure - Experiment Folder Structure).

• To test the tracking speed for articulated objects in SAPIEN, make sure to set --batch_size=1 in the script. You may use --dataset_length=500 to avoid running through the whole test set.

Evaluation

• To evaluate the pose predictions produced in the previous step, uncomment and run the corresponding line in CAPTRA/scripts/eval.sh, e.g. for the bottle category from NOCS-REAL275, the corresponding line is

  python misc/eval/eval.py --config config_track.yml --obj_config obj_info_nocs.yml --obj_category=1 --experiment_dir=../runs/1_bottle_rot


Visualization

• To visualize the pose predictions as 3D bounding boxes, run the corresponding line in CAPTRA/scripts/visualize.sh, e.g. for NOCS-REAL275, running the following will generate bounding boxes for all categories.

  python misc/visualize/visualize_tracking_nocs.py --img_path ../data/nocs_data/nocs_full/real_test --exp_path ../runs --output_path ../nocs_viz --save_fig


Training

• To train the CoordinateNet and RotationNet for a certain category, run the corresponding script in CAPTRA/scripts/train, e.g. for the bottle category from NOCS-REAL275, scripts
