MLWG3

Kingston Mobilelite Wireless G3

Telnet

Create a file with the name 'mlwG3_v;telnetd; .x.x.bin' at the root level (USB-Stick or SD-Card) Plug it in and start the device.

Login as 'admin'

cat /proc/version

Linux version 2.6.36+ (terry_kuo@CVS2) (gcc version 4.6.3 (Buildroot 2012.11.1) ) #4 Fri Jan 8 09:03:01 CST 2016

cat /proc/cmdline

console=ttyS1,57600n8 root=/dev/ram0 console=

cat /proc/cpuinfo

system type             : MT7628
processor               : 0
cpu model               : MIPS 24Kc V5.5
BogoMIPS                : 386.04
wait instruction        : yes
microsecond timers      : yes
tlb_entries             : 32
extra interrupt vector  : yes
hardware watchpoint     : yes, count: 4, address/irw mask: [0x0000, 0x0778, 0x0c40, 0x0ee8]
ASEs implemented        : mips16 dsp
shadow register sets    : 1
core                    : 0
VCED exceptions         : not available
VCEI exceptions         : not available

cat /proc/filesystems

nodev   sysfs
nodev   rootfs
nodev   bdev
nodev   proc
nodev   tmpfs
nodev   sockfs
nodev   usbfs
nodev   pipefs
nodev   devpts
        ext2
        ext3
        ext4
nodev   ramfs
        vfat
        iso9660
nodev   jffs2
nodev   fuse
        fuseblk
nodev   fusectl
        udf
nodev   mtd_inodefs
        ufsd

cat /proc/mounts

rootfs / rootfs rw 0 0
proc /proc proc rw,relatime 0 0
none /var ramfs rw,relatime 0 0
none /dev ramfs rw,relatime 0 0
none /tmp ramfs rw,relatime 0 0
none /media ramfs rw,relatime 0 0
none /sys sysfs rw,relatime 0 0
none /proc/bus/usb usbfs rw,relatime 0 0
none /etc ramfs rw,relatime 0 0
mdev /dev ramfs rw,relatime 0 0
devpts /dev/pts devpts rw,relatime,mode=600 0 0
/dev/mtdblock5 /etc/config jffs2 rw,relatime 0 0
/dev/mmcblk0p1 /media/SD_Card1 vfat rw,relatime,fmask=0000,dmask=0000,allow_utime=0022,codepage=cp950,iocharset=utf8,shortname=mixed,errors=remount-ro 0 0

cat /proc/mtd

dev:    size   erasesize  name
mtd0: 00030000 00010000 "Bootloader"
mtd1: 00010000 00010000 "Config"
mtd2: 00010000 00010000 "Factory"
mtd3: 007b0000 00010000 "KernelA"
mtd4: 007b0000 00010000 "KernelB"
mtd5: 00050000 00010000 "User_CFG"

Serial port @ 57600

bootlog

�[05010C0B][05010C08]

DDR Calibration DQS reg = 0000888A



U-Boot 1.1.3 (Oct 22 2015 - 15:22:48)


Board: Ralink APSoC DRAM:  64 MB

relocate_code Pointer at: 83f68000

flash manufacture id: ef, device id 40 18

find flash: W25Q128BV

*** Check if data is correct or not...

*** Data is correct.

============================================

Ralink UBoot Version: 4.3.0.0

--------------------------------------------

ASIC 7628_MP (Port5<->None)

DRAM component: 512 Mbits DDR, width 16

DRAM bus: 16 bit

Total memory: 64 MBytes

Flash component: SPI Flash

Date:Oct 22 2015  Time:15:22:48

============================================

icache: sets:512, ways:4, linesz:32 ,total:65536

dcache: sets:256, ways:4, linesz:32 ,total:32768


 ##### The CPU freq = 575 MHZ ####

 estimate memory size =64 Mbytes

RESET MT7628 PHY!!!!!!

Please choose the operation:

   1: Load system code to SDRAM via TFTP.

   2: Load system code then write to Flash via TFTP.

   3: Boot system code via Flash (default).

   4: Entr boot command line interface.

   7: Load Boot Loader code then write to Flash via Serial.

   9: Load Boot Loader code then write to Flash via TFTP.



You choosed 3


 0



3: System Boot system code via Flash.

3: System Boot on bootstate=2.

## Booting image at bc800000 ...

   Image Name:   Linux Kernel Image

   Image Type:   MIPS Linux Kernel Image (lzma compressed)

   Data Size:    6161733 Bytes =  5.9 MB

   Load Address: 80000000

   Entry Point:  8000c150

   Verifying Checksum ... OK

   Uncompressing Kernel Image ... OK

No initrd

## Transferring control to Linux (at address 8000c150) ...

## Giving linux memsize in MB, 64


Starting kernel ...



LINUX started...

 THIS IS ASIC
Linux version 2.6.36+ (terry_kuo@CVS2) (gcc version 4.6.3 (Buildroot 2012.11.1) ) #4 Fri Jan 8 09:03:01 CST 2016

 The CPU feqenuce set to 575 MHz

 MIPS CPU sleep mode enabled.
CPU revision is: 00019655 (MIPS 24Kc)
Software DMA cache coherency
Determined physical RAM map:
 memory: 04000000 @ 00000000 (usable)
Initrd not found or empty - disabling initrd
Zone PFN ranges:
  Normal   0x00000000 -> 0x00004000
Movable zone start PFN for each node
early_node_map[1] active PFN ranges
    0: 0x00000000 -> 0x00004000
Built 1 zonelists in Zone order, mobility grouping on.  Total pages: 16256
Kernel command line: console=ttyS1,57600n8 root=/dev/ram0 console=
PID hash table entries: 256 (order: -2, 1024 bytes)
Dentry cache hash table entries: 8192 (order: 3, 32768 bytes)
Inode-cache hash table entries: 4096 (order: 2, 16384 bytes)
Primary instruction cache 64kB, VIPT, , 4-waylinesize 32 bytes.
Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes
Writing ErrCtl register=00051e2b
Readback ErrCtl register=00051e2b
Memory: 55104k/65536k available (4132k kernel code, 10388k reserved, 1136k data, 4296k init, 0k highmem)
NR_IRQS:128
console [ttyS1] enabled
Calibrating delay loop... 386.04 BogoMIPS (lpj=772096)
pid_max: default: 32768 minimum: 301
Mount-cache hash table entries: 512
NET: Registered protocol family 16
RALINK_GPIOMODE = 540d0404
RALINK_GPIOMODE = 540c0404
***** Xtal 40MHz *****
start PCIe register access
RALINK_RSTCTRL = 2400000
RALINK_CLKCFG1 = fdbfffc0

*************** MT7628 PCIe RC mode *************
PCIE0 enabled
Port 0 N_FTS = 1b105000
init_rt2880pci done
bio: create slab <bio-0> at 0
vgaarb: loaded
SCSI subsystem initialized
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
pci 0000:00:00.0: BAR 0: can't assign mem (size 0x80000000)
pci 0000:00:00.0: BAR 8: assigned [mem 0x20000000-0x201fffff]
pci 0000:00:00.0: BAR 1: assigned [mem 0x20200000-0x2020ffff]
pci 0000:00:00.0: BAR 1: set to [mem 0x20200000-0x2020ffff] (PCI address [0x20200000-0x2020ffff]
pci 0000:01:00.0: BAR 0: assigned [mem 0x20000000-0x200fffff]
pci 0000:01:00.0: BAR 0: set to [mem 0x20000000-0x200fffff] (PCI address [0x20000000-0x200fffff]
pci 0000:01:00.1: BAR 0: assigned [mem 0x20100000-0x201fffff]
pci 0000:01:00.1: BAR 0: set to [mem 0x20100000-0x201fffff] (PCI address [0x20100000-0x201fffff]
pci 0000:00:00.0: PCI bridge to [bus 01-01]
pci 0000:00:00.0:   bridge window [io  disabled]
pci 0000:00:00.0:   bridge window [mem 0x20000000-0x201fffff]
pci 0000:00:00.0:   bridge window [mem pref disabled]
BAR0 at slot 0 = 0
bus=0x0, slot = 0x0
res[0]->start = 0
res[0]->end = 0
res[1]->start = 20200000
res[1]->end = 2020ffff
res[2]->start = 0
res[2]->end = 0
res[3]->start = 0
res[3]->end = 0
res[4]->start = 0
res[4]->end = 0
res[5]->start = 0
res[5]->end = 0
bus=0x1, slot = 0x0
res[0]->start = 20000000
res[0]->end = 200fffff
res[1]->start = 0
res[1]->end = 0
res[2]->start = 0
res[2]->end = 0
res[3]->start = 0
res[3]->end = 0
res[4]->start = 0
res[4]->end = 0
res[5]->start = 0
res[5]->end = 0
bus=0x1, slot = 0x0
res[0]->start = 20100000
res[0]->end = 201fffff
res[1]->start = 0
res[1]->end = 0
res[2]->start = 0
res[2]->end = 0
res[3]->start = 0
res[3]->end = 0
res[4]->start = 0
res[4]->end = 0
res[5]->start = 0
res[5]->end = 0
Switching to clocksource Ralink Systick timer
NET: Registered protocol family 2
IP route cache hash table entries: 1024 (order: 0, 4096 bytes)
TCP established hash table entries: 2048 (order: 2, 16384 bytes)
TCP bind hash table entries: 2048 (order: 1, 8192 bytes)
TCP: Hash tables configured (established 2048 bind 2048)
TCP reno registered
UDP hash table entries: 256 (order: 0, 4096 bytes)
UDP-Lite hash table entries: 256 (order: 0, 4096 bytes)
NET: Registered protocol family 1
RT3xxx EHCI/OHCI init.
JFFS2 version 2.2 (NAND) (SUMMARY) (ZLIB) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
fuse init (API version 7.15)
msgmni has been set to 107
Block layer SCSI generic (bsg) driver version 0.4 loaded (major 254)
io scheduler noop registered (default)
Ralink gpio driver initialized
led=37, on=5, off=5, blinks,=4000, reset=1, time=4000
led=43, on=4000, off=1, blinks,=1, reset=1, time=4000
i2cdrv_major = 218
Serial: 8250/16550 driver, 2 ports, IRQ sharing enabled
serial8250: ttyS0 at MMIO 0x10000d00 (irq = 21) is a 16550A
serial8250: ttyS1 at MMIO 0x10000c00 (irq = 20) is a 16550A
brd: module loaded
flash0: started
flash manufacture id: ef, device id 40 18
W25Q128BV(ef 40180000) (16384 Kbytes)
mtd .name = raspi, .size = 0x01000000 (16M) .erasesize = 0x00010000 (64K) .numeraseregions = 0
Creating 6 MTD partitions on "raspi":
0x000000000000-0x000000030000 : "Bootloader"
0x000000030000-0x000000040000 : "Config"
0x000000040000-0x000000050000 : "Factory"
0x000000050000-0x000000800000 : "KernelA"
0x000000800000-0x000000fb0000 : "KernelB"
0x000000fb0000-0x000001000000 : "User_CFG"
rdm_major = 253
GMAC1_MAC_ADRH -- : 0x0000000c
GMAC1_MAC_ADRL -- : 0x43e17629
Ralink APSoC Ethernet Driver Initilization. v3.1  256 rx/tx descriptors allocated, mtu = 1500!
GMAC1_MAC_ADRH -- : 0x0000000c
GMAC1_MAC_ADRL -- : 0x43e17629
PROC INIT OK!
PPP generic driver version 2.4.2
PPP MPPE Compression module registered
NET: Registered protocol family 24
PPTP driver version 0.8.5


=== pAd = c01a5000, size = 1338600 ===

<-- RTMPAllocTxRxRingMemory, Status=0, ErrorValue=0x
<-- RTMPAllocAdapterBlock, Status=0
RtmpChipOpsHook(492): Not support for HIF_MT yet!
mt7628_init()-->
mt7628_init(FW(8a00), HW(8a01), CHIPID(7628))
e2.bin mt7628_init(1133)::(2), pChipCap->fw_len(63616)
mt_bcn_buf_init(218): Not support for HIF_MT yet!
<--mt7628_init()
ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver
FM_OUT value: u4FmOut = 0(0x00000000)
FM_OUT value: u4FmOut = 140(0x0000008C)
FM detection done! loop = 1
SR calibration value u1SrCalVal = 6
rt3xxx-ehci rt3xxx-ehci: Ralink EHCI Host Controller
rt3xxx-ehci rt3xxx-e
