LoadingButton

A small and flexible button control with loading function,Extends from DrawableTextView，Loading animation comes from CircularProgressDrawable

Feature

• Support button shrink
• Support loading completion and failure icon
• Can custom loading drawable color, size, position and loading button shape
• Custom radius

How to install 中文说明

root directory build.gradle

	allprojects {

		  repositories {
		  	...
		  	maven { url 'https://jitpack.io' }

		  }
	}

App module build.gradle

 	dependencies {
		//Androidx
		implementation 'com.github.FlodCoding:LoadingButton:1.1.0-alpha01'

	}

Support-appcompat stop update
~~implementation 'com.github.FlodCoding:LoadingButton:1.0.5-support'~~

Demo Click me to download the apk

Demo screenshot

Basic usage

XML

 <com.flod.loadingbutton.LoadingButton
            android:id="@+id/loadingBtn"
            android:layout_width="match_parent"
            android:layout_height="50dp"
            android:layout_gravity="center_horizontal"
            android:background="@android:color/holo_red_light"
            android:drawablePadding="10dp"
            android:gravity="center"
            android:minHeight="45dp"
            android:padding="8dp"
            android:text="Submit"
            android:textColor="@android:color/white"
            android:textSize="14sp"
            app:endSuccessDrawable="@drawable/ic_successful"
            app:endFailDrawable="@drawable/ic_fail"
            app:radius="50dp"
            app:enableShrink="true"
	        app:enableRestore="true"
            app:shrinkShape="Oval"
            app:loadingDrawablePosition="Start" />

Code

loadingBtn.start();              //Start loading
loadingBtn.complete(true);       //Success
loadingBtn.complete(false);      //failed
loadingBtn.cancel();             //Cancel loading

loadingBtn.setEnableShrink(true)
	      .setEnableRestore(true)
          .setDisableClickOnLoading(true)
          .setShrinkDuration(450)
          .setLoadingPosition(DrawableTextView.POSITION.START)
          .setSuccessDrawable(R.drawable.ic_successful)
          .setFailDrawable(R.drawable.ic_fail)
          .setEndDrawableKeepDuration(900)
          .setLoadingEndDrawableSize((int) (loadingBtn.getTextSize() * 2));

loadingBtn.getLoadingDrawable().setStrokeWidth(loadingBtn.getTextSize() * 0.14f);
loadingBtn.getLoadingDrawable().setColorSchemeColors(loadingBtn.getTextColors().getDefaultColor());


State callback

start --> onShrinking --> onLoadingStart
complete --> onLoadingStop --> onEndDrawableAppear --> onCompleted --> onRestored

    public static class OnStatusChangedListener {

        public void onShrinking() {}

        public void onLoadingStart() {}

        public void onLoadingStop() {}

        public void onEndDrawableAppear(boolean isSuccess, EndDrawable endDrawable) {}

        public void onRestoring() {}

        public void onRestored() {}

        public void onCompleted(boolean isSuccess) { }

        public void onCanceled() {}
    }

Attribute

XML

Attribute name|type|Default value|Description ---|:--:|:---:|---: enableShrink |boolean |true |Shrink when begin loading disableClickOnLoading |boolean |true |Disable click on loading enableRestore |boolean |false |When finished, restore button(shape and text) radius |dimension |0dp |Set the rounded corners of the button,(need SDK>=21) <br>(from(DrawableTextView) shrinkDuration |integer |450ms |Shrink animation duration shrinkShape |enum<br>(Default,Oval) |Oval |Shape after shrinking (need SDK>=21) <br>(Default:Keep the original shape,Oval:Round shape) loadingEndDrawableSize |dimension |TextSize *2 |Set the size of LoadingDrawable and EndDrawable loadingDrawableColor |reference |TextColor |Set loading color loadingDrawablePosition |enum<br>(Start,Top,<br>End,Bottom) |Start |Set the loading drawable position endSuccessDrawable |reference | null |Successful drawable endFailDrawable |reference | null |failed drawable endDrawableAppearTime |integer | 300ms |Time for completion or failure icon to emerge from nothing endDrawableDuration |integer | 900ms |endDrawable keeping time

Public Func

Method name|Parameter description|default value|Description ---|:--:|:---:|---: start() |- |- |Start loading complete(boolean isSuccess) |whether succeed |- |Complete loading cancel()<br>cancel(boolean withRestoreAnim) |Whether to perform restore animation |true |Cancel loading setEnableShrink(boolean enable) |- |true |Shrink when begin loading setEnableRestore(boolean enable) |- |false |When finished, restore button(shape and text) setRadius(@Px int px)<br>setRadiusDP(int dp) |Px/Dp |0 |Set the rounded corners of the button,(need SDK>=21) <br>(from(DrawableTextView) setShrinkShape(@ShrinkShape int shrinkShape) |Default:Keep the original shape,Oval:Round shape |Oval |Shape after shrinking (need SDK>=21) setShrinkDuration(long time) |milliseconds |450ms |Shrink animation duration setLoadingEndDrawableSize(@Px int px) |Px |TextSize *2 |Set the size of LoadingDrawable and EndDrawable setLoadingPosition(@POSITION int position) |Start,Top,End,Bottom |Start |Set the loading drawable position setSuccessDrawable(@DrawableRes int drawableRes)<br>setSuccessDrawable(Drawable drawable) |- | null |Successful drawable setFailDrawable(@DrawableRes int drawableRes)<br>setFailDrawable(Drawable drawable) |- | null |failed drawable setEndDrawableAppearDuration(long time) |milliseconds | 300ms |Time for completion or failure icon to emerge from nothing setEndDrawableKeepDuration(long time) |milliseconds | 900ms |endDrawable keeping time setOnStatusChangedListener<br>(OnStatusChangedListener listener)|-|null|State callbacks of buttons

Third-party libraries used by Demo

Matisse

Glide
