TextureChannelPacker

TextureChannelPacker is an Unreal Engine 5.7 plugin designed to efficiently pack separate grayscale textures into the Red, Green, Blue, and Alpha channels of a single output texture. This is commonly used for creating ORM (Occlusion, Roughness, Metallic) maps or other channel-packed textures.

First time? Check out the Quick Start Guide to get started in seconds!

Tool Overview

Features

4-Channel Packing (RGBA): Takes up to four input textures and packs their Red channels into the output's Red, Green, Blue, and Alpha channels respectively.
Auto-Resizing: Automatically resizes input textures to match the specified target resolution using High-Quality Bilinear Interpolation (FImageUtils).
Input Handling:
- Reads the Red channel from each source texture.
- If an input texture is missing, the corresponding channel is filled with Black (0).
- Optional Alpha Channel: If an Alpha texture is assigned, its Red channel is used. If left empty, the Alpha channel defaults to White (255) for full opacity.
Invert Toggle: Each channel slot includes an Invert checkbox. When enabled, the channel values are flipped (255 - Value), useful for conversions like Roughness to Smoothness without a separate texture.
Extended Format Support:
- Supports 16-bit Grayscale and 32-bit Float (SDF) source formats, ensuring high-precision data is processed correctly without "black texture" issues.
Output Configuration:
- Non-Square Output: Width and Height can be specified independently (up to 16384), enabling non-square packed textures for UI atlases and other use cases.
- Compression Settings: Select from Masks (Recommended), Grayscale, or Default via a dropdown menu.
- Customizes Output Path, File Name, and Resolution.
- Generates UTexture2D assets with sRGB = false (linear color).
High Performance:
- Utilizes Parallel Processing (multi-threading) to significantly speed up texture resizing and conversion.
User Interface:
- UI Localization: The interface automatically switches between English and Japanese based on the Editor's language preference.
- Cancellable Progress: A progress dialog with a cancel button appears during generation, allowing you to abort long operations.
- Overwrite Confirmation: A confirmation dialog appears when the output asset already exists, preventing accidental data loss.
- Path Picker: Easily select the output directory from the Content Browser using the folder icon button.
- Toast Notifications: Provides clear feedback (Success/Error) via non-intrusive notifications instead of just log messages.
- Integrated into the Unreal Engine Editor via the Tools menu.

Requirements

Unreal Engine 5.5+ (Developed and tested on 5.7)
C++ Project (to compile the plugin)

Why use this tool?

Texture Samplers Limit: Materials have a limit on how many textures they can read simultaneously (usually 16). Packing 3 textures (AO, Roughness, Metallic) into 1 saves sampler slots, avoiding material errors.
Memory Efficiency: Combining files reduces the memory overhead compared to loading multiple separate files.
File Management: It keeps the Content Browser organized by reducing the file count.

Supported Input Formats

The tool supports a variety of source texture formats, ensuring compatibility with different workflows:

8-bit: BGRA8, Gray8 (G8) - Standard texture formats.
16-bit: Gray16 (G16) - Useful for Heightmaps requiring higher precision.
Float: R16F, R32F, RGBA32F - Useful for SDFs (Signed Distance Fields) and LUTs.

Limitations

Floating Point Textures: Floating point textures (e.g., SDF, Heightmaps) are clamped to the 0.0 - 1.0 range during packing. Values outside this range will be clipped.

Installation

Option A: Install via Fab (Recommended)

The easiest way to install is via the Fab Store. This ensures you get the correct version for your engine. Get it on Fab

Option B: Manual Installation (GitHub)

If you want the latest development version or need to modify the source code:

Clone or Download: Download this repository and place the TextureChannelPacker folder into your project's Plugins directory.
- If the Plugins folder does not exist, create it in your project's root directory (next to .uproject).
Directory structure:
```
MyProject/
├── MyProject.uproject
├── Plugins/
│   └── TextureChannelPacker/
│       ├── TextureChannelPacker.uplugin
│       └── Source/
└── Source/
```
Generate Project Files: Right-click on your .uproject file and select Generate Visual Studio project files.
Build the Project: Open the generated .sln file in your IDE (e.g., Visual Studio or Rider) and build your project. This will compile the plugin.
Enable the Plugin: Launch the Unreal Engine Editor. If the plugin is not enabled automatically, go to Edit > Plugins, search for TextureChannelPacker, and enable it. Restart the editor if prompted.

Usage Guide

Open the Tool: In the Unreal Editor, navigate to the main menu bar and select Tools > Texture Packing. This will open the Texture Channel Packer tab. You can dock this tab anywhere in your editor layout.
Assign Inputs:
- Red Channel Input: Select a texture for the Red channel (e.g., Ambient Occlusion).
- Green Channel Input: Select a texture for the Green channel (e.g., Roughness).
- Blue Channel Input: Select a texture for the Blue channel (e.g., Metallic).
- Alpha Channel Input (Optional): Select a texture for the Alpha channel. If empty, it defaults to White (255).
Each channel slot also has an Invert checkbox. Enable it to flip the channel values (255 - Value), which is useful for converting between Roughness and Smoothness without needing a separate texture.

Note: You can Drag & Drop textures directly from the Content Browser into the slots. You can also leave any input empty; R/G/B channels will be filled with black if missing.
Configure Output:
- Resolution (Width × Height): Set the target width and height for the output texture independently (e.g., 2048 × 2048). Non-square resolutions are supported.
- Compression Settings: Choose the compression type (default is Masks).
- Output Path: Specify the game folder path. You can type it manually or click the Folder Icon to select a directory from the Content Browser.
- File Name: Enter the desired name for the new texture asset.
Generate: Click the Generate Texture button.
- The tool will process the textures and create a new asset in the Content Browser at the specified location.
- A Toast Notification will confirm if the operation was successful.

Compression Settings Explained

FAQ

Q: Can I use this plugin at runtime (in-game)? A: No, this is an Editor-only tool designed for asset creation during development. It does not run in packaged games.

Q: Do input textures need to be the same resolution? A: No. The tool automatically resizes all inputs (e.g., mixing 1024p and 2048p sources) to match your specified target resolution using high-quality sampling.

Q: What happens if I leave a slot empty? A:

Red, Green, Blue: Filled with Black (0).
Alpha: Filled with White (255 / Opaque) by default, so you don't need to create a dummy white texture for opacity.

Q: Why is 'sRGB' disabled on the output texture? A: Channel-packed textures (like ORM maps) contain data, not color, so they must be Linear (sRGB = false). This tool automatically applies the correct settings (Compression: Masks) for you.

Q: Does it support high-resolution textures like 8K? A: Yes, it now supports up to 16K resolution. The processing pipeline uses memory-optimized techniques to safely handle large assets. However, a memory consumption warning dialog will be displayed for resolutions exceeding 8K.

Q: What input formats are supported? A: It supports standard formats (PNG, TGA, PSD) as well as 16-bit Grayscale and 32-bit Float (e.g., EXR) formats, ensuring high precision for Heightmaps and SDFs.

Q: What does the Invert checkbox do? A: It flips the channel values (255 - Value). This is useful for converting between
