4DFlowNet
Super Resolution 4D Flow MRI using Residual Neural Network
This is an implementation of the paper 4DFlowNet: Super-Resolution 4D Flow MRI using Tensorflow 2.2.0 with Keras.
Updates 4DFlowNet v2.0
- Loss function has been updated (MSE fluid + MSE non fluid)
- L2 regularization added
- Divergence loss turned off
- Evaluation metrics updated
- Final activation layer switch to linear to allow phase aliasing
These changes are implemented for Cerebrovascular super-resolution 4D Flow MRI
Manuscript version
Original network implementation from the manuscript can be found under the following branches:
- release/manuscript_version (for TF2.0)
- tf1.8 (for Tensorflow 1.8.0)
The pre-trained networks weights can be found here:
Training dataset is available for download from:
Example results
Below are the example prediction results from an actual 4D Flow MRI of a bifurcation phantom dataset.
LowRes input (voxel size 4mm)
<p align="left"> <img src="https://i.imgur.com/O48FbAh.gif" width="330"> </p>High Res Ground Truth vs noise-free Super Resolution (2mm)
<p align="left"> <img src="https://i.imgur.com/67CRdGn.gif" width="350"> </p>High Res Ground Truth vs noise-free Super Resolution (1mm)
<p align="left"> <img src="https://i.imgur.com/DMQa2Lr.gif" width="350"> </p>Training setup from CFD data
Prepare dataset
To prepare training or validation dataset, we assume a High resolution CFD dataset is available. As an example we have provided this under /data/example_data_HR.h5
How to prepare training/validation dataset.
1. Generate lowres dataset
>> Configure the datapath and filenames in prepare_lowres_dataset.py
>> Run prepare_lowres_dataset.py
>> This will generate a separate HDF5 file for the low resolution velocity data.
2. Generate random patches from the LR-HR dataset pairs.
>> Configure the datapath and filenames in prepare_patches.py
>> Configure patch_size, rotation option, and number of patches per frame
>> Run prepare_patches.py
>> This will generate a csv file that contains the patch information.
Training
The training accepts csv files for training and validation set. A benchmark set is used to keep prediction progress everytime a model is being saved as checkpoint. Example csv files are provided in the /data folder.
To run a training for 4DFlowNet:
1. Put all data files (HDF5) and CSV patch index files in the same directory (e.g. /data)
2. Open trainer.py and configure the data_dir and the csv filenames
3. Adjust hyperparameters. The default values from the paper are already provided in the code.
4. Run trainer.py
Adjustable parameters:
|Param | Description | Default| |------|--------------|--------:| | patch_size| The image will be split into isotropic patches. Adjust according to computation power and image size. | 24| | res_increase| Upsample ratio. Adjustable to any integer. More upsample ratio requires more computation power. Note: res_increase=1 will denoise the image at the current resolution |2| | batch_size| Batch size per prediction. Keep it low. |8| | initial_learning_rate| Initial learning rate |1e-4| | epochs | maximum number of epochs | 1000 | | mask_threshold| Mask threshold for non-binary mask. This is used to measure relative error (accuracy) | 0.6 | | network_name | The network name. The model will be saved in this name_timestamp format |4DFlowNet| |QUICKSAVE| Option to run a "bechmark" dataset everytime a model is saved | True | |benchmark_file| A patch index file (CSV) contains a list of patches. Only the first batch will be read and run into prediction. | None| | low_resblock | Number of residual blocks in low resolution space within 4DFlowNet. |8| | hi_resblock | Number of residual blocks in high resolution space within 4DFlowNet. |4|
Running prediction on MRI data
Prepare data from MRI (for prediction purpose)
To prepare 4D Flow MRI data to HDF5, go to the prepare_data/ directory and run the following script:
>> python prepare_data.py --input-dir [4DFlowMRI_CASE_DIRECTORY]
>> usage: prepare_mri_data.py [-h] --input-dir INPUT_DIR
[--output-dir OUTPUT_DIR]
[--output-filename OUTPUT_FILENAME]
[--phase-pattern PHASE_PATTERN]
[--mag-pattern MAG_PATTERN] [--fh-mul FH_MUL]
[--rl-mul RL_MUL] [--in-mul IN_MUL]
Notes:
- The directory must contains the following structure: [CASE_NAME]/[Magnitude_or_Phase]/[TriggerTime]
- There must be exactly 3 Phase and 3 Magnitude directories
- To get the required directory structure, DicomSort is recommended. Sort by SeriesDescription -> TriggerTime.
- In our case, VENC and velocity direction is read from the SequenceName DICOM HEADER. Code might need to be adjusted if the criteria is different.
Prediction
To run the prediction, download first the pre-trained weights. We have provided an example dataset under the data/ folder.
1. Create a directory named models/
2. Put the downloaded 4DFlowNet folder under models/
3. Put your dataset under the data/ folder
4. Go to src/ and open predictor.py and configure the input_filename and output_filename if necessary
5. Run predictor.py
Adjustable parameters:
|Param | Description | Default| |------|--------------|--------:| | patch_size| The image will be split into isotropic patches. Adjust according to computation power and image size. | 24| | res_increase| Upsample ratio. Adjustable to any integer. More upsample ratio requires more computation power. Note: res_increase=1 will denoise the image at the current resolution |2| | batch_size| Batch size per prediction. Keep it low. |8| | round_small_values|Small values are rounded down to zero. Small value is calculated based on venc, according to Velocity per 1 pixel value = venc/2048 |True| | low_resblock | Number of residual blocks in low resolution space within 4DFlowNet. |8| | hi_resblock | Number of residual blocks in high resolution space within 4DFlowNet. |4|
Contact Information
If you encounter any problems in using the code, please open an issue in this repository or feel free to contact me by email.
Author: Edward Ferdian (edwardferdian03@gmail.com).
