ACadSharp

ACadSharp

C# library to read/write cad files like dxf/dwg.

Features

ACadSharp allows to read or create CAD files using .Net and also extract or modify existing content in the files, the main features may be listed as:

• Read/Write Dxf binary files
• Read/Write Dxf ASCII files
• Read Dwg files
• Write Dwg files
• Extract/Modify the geometric information from the different entities in the model
• Control over the table elements like Blocks, Layers and Styles, allows you to read, create or modify the different tables

For pdf export check :construction: ACadSharp.Pdf :construction:.

Compatible Dwg/Dxf versions:

| | DxfReader | DxfWriter | DwgReader | DwgWriter | ------ | :-------: | :-------: | :-------: | :-------: | AC1009 | :heavy_check_mark: | :x: | :x: | :x: | AC1012 | :heavy_check_mark: | :heavy_check_mark: | :x: | :x: | AC1014 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | AC1015 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | AC1018 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | AC1021 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :x: | AC1024 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | AC1027 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | AC1032 | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: | :heavy_check_mark: |

Code Example

public static void Main()
{
	string path = "sample.dwg";
	CadDocument doc = DwgReader.Read(path, onNotification);
}

// Process a notification from the reader
private static void onNotification(object sender, NotificationEventArgs e)
{
	Console.WriteLine(e.Message);
}

For more code examples check.

Visit the :construction: wiki :construction: for the API specification of the library.

Check the documentation for specific information about some use cases.

Building

Before building run:

git submodule update --init --recursive

This command will clone the submodules necessary to build the project.
