Proof Carrying Code Completions (PC3)

PC3: A Dafny framework for generating code together with a proof of a safety property.

[!WARNING] PC3 is under active development.

Introduction
Installation
Configuration
Usage
Repository Structure
Contributors
Contributing
License

Introduction

PC3 (proof carrying code completions) is a Dafny framework for generating code together with a proof of a safety property selected by the user. PC3 is a research prototype; it has the following current limitations:

Currently, PC3 supports code generation (i.e., full function bodies) and support for code completions is work-in-progress.
The safety properties are chosen and converted to verification conditions manually in the current version.

Installation

Clone PC3 Repository

Clone PC3 repository using this link https://github.com/DavisPL/PCCC.git

Dependencies

Install Dafny

Use Dafny official user installation instruction to install Dafny version 4.6.0 on a unix-based system.
Make sure that dafny is accessible from the command line and verify the version by trying dafny --version. The output should be =4.6.0

Install Python

Use python official documentation to install a python with version >=3.12.3.
Check python version python --version. The output should be >=3.12.3

Requirements

Use the package manager pip to install requiremetns.

Create a virtual environment using python -m venv /path/to/new/virtual/environment for instance: python3 -m venv pccc-venv Activate the virtual environment using source pccc-venv/bin/activate for a unix-based system and pccc-venv\Scripts\activate.bat for a windows-based system. In case of having any issue or requiring more details please refer to python documentation on the creation of virtual environments

To install required packages you can simply use the following command

pip install -r requirements.txt

Or install required packages separately using pip

pip install openai
pip install anthropic
pip install langchain
pip install langchain-anthropic
pip install langchain-community
pip install langchain-core
pip install langchain-openai
pip install langchain-text-splitters
pip install langsmith
pip install lunary

Configuration

Use the config.yaml file and modify it to add your desired configurations to work with PCCC. Config file includes four main parts that should be modified to set the requirements for the tool execution and the configurations required for the few-shot prompting.

API keys: the API keys for the required autoregressive transformer model and also Lunary API for logging the input to the model and the model's response. If you only would like to use openAI models you need to add openai_api_key and also set the model
```
    # OpenAI API KEY
    openai_api_key = your-api-key
    # LLM to be used 'gpt-4'
    model = gpt-4
```
If you would like to switch to another model, simply remove the openai_api_key and add the new_api_key for another model.

[!NOTE] Currently, our tool only supports openAI and Claude. Adding the lunary_api_key is optional. If you use Lunary for logging the prompt and the model's response you need to add it to as below:

    # Lunary API KEY
    lunary_api_key = YOUR_API_KEY

Model parameters: LLM parameters including the LLM model, coold down time, temperature (= 0.75), max number of tokens (= 4000). For this part you only need to modify the model name. However, you can also modify the temperature and other model parameters.

MODEL:
# LLM to be used 'gpt-4'
model: gpt-4
# Model temperature
temp: 0.75
# Number of attempts/samples
K_run: 5
# top_p (0,1) default: 1
top_p: 1
# Adjustable number of tokens to control response length
max_tokens: 4000
# Number of completions to generate
n: 1
# Stop completion tokens
stop: null
# Waiting time
cool_down_time: 3

Environment: Set the absolute path for the following files: - Set the absolute path for the input task task 6 json file - Set the absolute path for the output output - Set the absolute path for the effectful interface APIs to allow the tool to include it in the generated code effectful interface ``` # REQUIRED FILES [ENVIRONMENT] # Filesystems task JSON path (absolute path) task_path = path_to_task_6_json # Base output path (absolute path) base_output_path = path_to_output # Effectful interface API path (absolute path) interface_path = path_to_effectful_interface
```
 ```
```
Few-shot config: Set the absolute path to required files and number of few-shot examples
- Set RAG examples by adding the absolute path to the json file including RAG example
- Set the absolute path to the [json file that includes APIs of the effectful interface] (./benchmark/interface_api.json)
- Set the number of few shot examples in the Chain of Thought (CoT) Prompt template 5 in our exper
```
# Required for dynamic Few-Shot RAG Prompting
# example CWEs JSON path (absolute path)
RAG_json_path = path_to_RAG_samples_json
# Filesystem API reference path (absolute path)
api_reference_path = path_to_effectful_interface_api_json
# number of code examples in [Chain of Thought (CoT) Prompt]
code_shot_count = 5
```

Usage

Switch to the source folder and run the main.py file to run the tool

cd src
python3 main.py

The output files are available in output directory

files with verification_log suffix shows the status of the generated code at each try
- If the generated code is verified the output is
```
    Dafny program verifier finished with 1 verified, 0 errors
```
- If the generated code cannot be verified with Dafny compiler the output shows the line of code that caused the error:
```
        |
     10 |    requires has_valid_path_length(directory + filename);
        |    ^

        1 parse errors detected in task_id_6-gpt-4-temp_0.75-k_1.dfy
```
Generated dafny codes for each attempt are saved in the files with .dfy extension.
For each attempt a json file includes the config, total number of errors, the few shot example ids, the generated code, and the model response with a template like the following one:

{"id": "6", "K": 2, "temperature": 0.75, "task_id": "6", "task_description": "Your task is to implement a function which takes the filename as a parameter, which will then be used to create a full file path in a predetermined directory ( e.g.,'/home/user/documents').", "model": "gpt-4", "dafny_code": "method CreateFullPath(filename: seq<char>) returns (fullpath: seq<char>)\n requires is_valid_file_name(filename)\n requires !has_dangerous_pattern(filename)\n requires has_valid_file_length(filename)\n {\n   var directory: seq<char> := \"/home/user/documents\";\n   fullpath := Join(directory, filename);\n }", "isVerified": true, "code_example_shots": "5", "code_response": "Follow these steps to complete the task:\n\n\nStep 1: Analyze and select the required APIs and their preconditions from the list of API reference.\nFor this task:\n - method Join(p: path, f: file) returns(result: path)\n requires non_empty_string(f)\n requires non_empty_string(p)\n requires !has_dangerous_pattern(f)\n requires !has_dangerous_pattern(p)\n requires has_absolute_path(f)\n requires is_valid_file_name(f)\n requires is_valid_path_name(p)\n requires has_valid_file_length(f)\n requires has_valid_path_length(p)\n requires has_valid_path_length(p+f)\n\nStep 2:  Implement the Dafny code for the described task, adhering to the provided structure for each API. Utilize the provided API list and their specifications.\nProvide the implementation in Dafny syntax as follows:\n\n```dafny\ninclude \"/Users/pari/pcc-llms/filesystems-api/interface/effectful-interface.dfy\"\n\nmethod CreateFullPath(filename: seq<char>) returns (fullpath: seq<char>)\n requires is_valid_file_name(filename)\n requires !has_dangerous_pattern(filename)\n requires has_valid_file_length(filename)\n {\n   var directory: seq<char> := \"/home/user/documents\";\n   fullpath := Join(directory, filename);\n }\n```\nThe method `CreateFullPath` takes a filename as its parameter and appends it to the directory path \"/home/user/documents\" to create a full path. The filename must be a valid file name, have a valid file length and should not contain any dangerous pattern.", "code_examples_ids": ["4", "1", "3", "5", "2"], "total_no_errors": 0}

A json file includes the output of last attempt that is similar to the output described above.

Repository Structure

Most of the source code of PC3 can be found in src/. The prompt template can be found in src/prompts_template/ and the example in our paper is task-6 that can be found in src/tasks/task-6.json. The few-shot examples can be found in benchmark/RAG_samples.

Contributors

This repository is maintained actively by:

Parnian Kamran: [pk
