EnhancedGridMap Plugin for Godot 4.4

Overview

EnhancedGridMap is a powerful plugin for Godot 4.4 that extends the functionality of the built-in GridMap node. It provides additional features for grid-based game development, including custom cell states, multi-floor support, and advanced grid manipulation tools.

Features

• Custom grid size (columns and rows)
• Multi-floor support with floor management
• Auto-generation of grid
• Custom cell states with visual representation
• A* pathfinding with diagonal movement option
• Randomization of grid cells
• Fill grid with specific cell types
• Item swapping functionality
• Editor dock for easy manipulation of grid properties
• Floor-specific operations for generating, clearing, and filling grids

Installation

1. Copy the enhanced_gridmap folder into your Godot project's addons directory.
2. Enable the plugin in Project Settings > Plugins.

EnhancedGridMap Dock

The EnhancedGridMap Dock provides a user-friendly interface to control and manipulate the EnhancedGridMap node. Here's a detailed explanation of all features available in the dock:

Grid Properties

1. Columns: Set the number of columns in the grid.
2. Rows: Set the number of rows in the grid.
3. Floors: Set the number of floors in your grid.
4. Current Floor: Select which floor to edit.
5. Auto Generate: Toggle automatic grid generation when properties change.

Grid Operations

1. Generate: Manually generate the grid based on current properties.
2. Clear: Remove all cells from the grid.
3. Randomize: Randomly assign cell types based on defined states.
4. Fill: Fill the entire grid with a specific cell type.
5. Swap Items: Replace all instances of one item type with another.

Cell States

The dock allows you to define and manage custom cell states:

1. Default States:

   • Normal
   • Hover
   • Start
   • End
   • Non-Walkable

2. Custom States:

   • Add new states with the "Add Item State" button.
   • For each state, you can set:
     • Name
     • ID (used in scripts to reference the state)
     • Include in Randomize (toggle)
     • Randomize Percentage (when included in randomization)

3. State Management:

   • Edit existing states
   • Remove custom states
   • Swap items between states

Floor Management

The new floor management system allows you to:

1. Add/Remove Floors: Dynamically adjust the number of floors in your grid.
2. Floor Navigation: Easily switch between different floors for editing.
3. Floor-Specific Operations:
   • Generate specific floors
   • Clear individual floors
   • Fill selected floors with specific items

Item Swapping

The new item swapping feature allows you to:

1. Select Source Item: Choose the item type to be replaced.
2. Select Target Item: Choose the new item type to replace with.
3. Swap Items: Replace all instances of the source item with the target item.
4. Floor-Specific Swapping: Option to swap items only on the current floor or across all floors.

A* Pathfinding

1. Start Position: Set the X and Z coordinates for the pathfinding start point.
2. End Position: Set the X and Z coordinates for the pathfinding end point.
3. Find Path: Calculate and visualize the path between start and end points.
4. Diagonal Movement: Toggle to allow diagonal movement in pathfinding.

Visual Grid Editor

The dock includes a visual representation of the grid:

1. Each cell displays its coordinates.
2. Drop-down menus in each cell allow you to change the cell's state directly.

In-Depth Feature Explanation

Custom Grid Generation

The EnhancedGridMap allows for flexible grid generation:

1. Auto-generation: The grid can automatically update when properties change.
2. Manual generation: Use the generate_grid() method for custom generation logic.
3. Clear and regenerate: Useful for level resets or procedural generation.

Cell States

Cell states are central to the EnhancedGridMap's functionality:

1. Default states: Predefined states for common use cases (normal, hover, start, end, non-walkable).
2. Custom states: Create states for specific game mechanics (e.g., water, lava, ice).
3. State properties:
   • ID: Used in scripts to set or check cell states.
   • Name: Human-readable label
   • Randomize inclusion: Determine if the state should be included in randomization.
   • Randomize percentage: Control the frequency of the state when randomizing.

A* Pathfinding

The integrated A* pathfinding system offers:

1. Efficient pathfinding: Quickly find optimal paths between two points.
2. Diagonal movement: Option to allow or disallow diagonal movement.
3. Custom cost functions: Override get_cell_cost() for complex movement rules.
4. Path visualization: Easily visualize calculated paths for debugging.

Grid Manipulation

Several methods for manipulating the grid:

1. set_cell_from_data(x, z, item_index): Set a specific cell's state.
2. fill_grid(item_index): Fill the entire grid with a specific state.
3. randomize_grid(): Randomly assign states based on defined probabilities.
4. randomize_grid_custom(randomize_states): Use custom randomization rules.

Extending Functionality

The EnhancedGridMap is designed to be easily extended:

1. Custom grid generation: Override generate_grid() for specialized layouts.
2. Custom pathfinding costs: Implement get_cell_cost() for complex movement rules.
3. Integration with game mechanics: Use signals like grid_updated to trigger game events.

Editor Integration

The plugin seamlessly integrates with the Godot editor:

1. Visual editing: Manipulate the grid directly in the editor viewport.
2. Real-time updates: Changes in the dock immediately reflect in the scene.
3. Custom inspector: The EnhancedGridMap node has a custom inspector for easy property editing.

Plugin Usage

Basic Setup

1. Add an EnhancedGridMap node to your scene.
2. Assign a MeshLibrary to the EnhancedGridMap.
3. Use the EnhancedGridMap dock in the editor to configure grid properties and cell states.

Scripting

You can also interact with the EnhancedGridMap through GDScript. Here's a basic example:

var enhanced_gridmap = $EnhancedGridMap

# Generate a 10x10 grid
enhanced_gridmap.columns = 10
enhanced_gridmap.rows = 10
enhanced_gridmap.generate_grid()

# Find a path from (0,0) to (5,5)
var path = enhanced_gridmap.find_path(Vector2(0, 0), Vector2(5, 5))

Sample Scene and Player Movement

The plugin includes a sample scene that demonstrates how to implement player movement using the EnhancedGridMap. This scene showcases pathfinding and grid-based movement.

Scene Setup

The sample scene (main.tscn) includes:

1. An EnhancedGridMap node with a pre-configured grid.
2. A player character CharacterBody3D with a custom script for grid-based movement.
3. A top-down camera for easy visualization.

Player Movement Script

The player.gd script provides a flexible implementation of grid-based movement using the EnhancedGridMap. Key features include:

• Click-to-move functionality
• Pathfinding using the EnhancedGridMap's A* algorithm
• Smooth movement along the calculated path
• Customizable cell size and offset
• Option for diagonal movement

Usage Example

To use the player movement script in your own scene:

1. Add an EnhancedGridMap to your scene.
2. Add a CharacterBody3D (or other suitable node) for your player.
3. Attach the player.gd script to your player node.
4. Set the enhanced_gridmap_path and player_path in the inspector.
5. Customize other properties like cell_size and use_diagonal_movement as needed.

Here's a minimal setup example:

extends Node3D

@onready var enhanced_gridmap = $EnhancedGridMap
@onready var player = $Player

func _ready():
    player.enhanced_gridmap_path = enhanced_gridmap.get_path()
    player.player_path = player.get_path()
    player.cell_size = Vector3(2, 2, 2)
    player.use_diagonal_movement = true

This setup allows for click-to-move functionality on your EnhancedGridMap, with the player finding and following optimal paths while avoiding non-walkable cells.

API Reference

Properties

• columns: int - Number of columns in the grid
• rows: int - Number of rows in the grid
• auto_generate: bool - Whether to automatically generate the grid when properties change
• normal_items: Array[int] - Array of item indices for normal cells (default: [0])
• non_walkable_items: Array[int] - Array of item indices for non-walkable cells (default: [4])
• hover_item: int - Item index for hover state cells
• start_item: int - Item index for pathfinding start cells
• end_item: int - Item index for pathfinding end cells
• non_walkable_item: int - Item index for non-walkable cells
• diagonal_movement: bool - Whether to allow diagonal movement in pathfinding

Methods

Grid Management

• generate_grid() - Generate the grid based on current properties
• clear_grid() - Clear all cells in the grid
• randomize_grid() - Randomize cell types in the grid
• randomize_grid_custom(randomize_states: Array) - Randomize cell types based on custom states
• fill_grid(item_index: int) - Fill the entire grid with a specific item type
• validate_item_indices() - Validate and ensure all item indices are within valid range

Property Setters

• set_columns(value: int) - Set the number of columns and update grid if auto-generate is enabled
• set_rows(value: int) - Set the number of rows and update grid if auto-generate is enabled
• `set_floor
