DEPRECATED - Use export endpoint instead

As of December 2021, Confluent recommends using the export endpoint of the Confluent Cloud Metrics API to extract metrics instead of running a separate service such as the ccloudexporter. This endpoint can be scraped directly with a Prometheus server or other Open Metrics compatible scrapers.

Prometheus exporter for Confluent Cloud Metrics API

A simple Prometheus exporter that can be used to extract metrics from Confluent Cloud Metric API. By default, the exporter will be exposing the metrics on port 2112. When launching with Docker Compose, metrics are displayed via a Grafana dashboard on http://localhost:3000 (admin/admin).

To use the exporter, the following environment variables need to be specified:

CCLOUD_API_KEY: The API Key created with ccloud api-key create --resource cloud
CCLOUD_API_SECRET: The API Key Secret created with ccloud api-key create --resource cloud

CCLOUD_API_KEY and CCLOUD_API_SECRET environment variables will be used to invoke the https://api.telemetry.confluent.cloud endpoint.

Usage

./ccloudexporter [-cluster <cluster_id>] [-connector <connector_id>] [-ksqlDB <app_id>] [-schemaRegistry <sr_id>]

Options

Usage of ./ccloudexporter:
  -cached-second int
    	Number of second that data will be cached in-memory and returned to Prometheus. This is a mechanism to protect the MetricsAPI from being flooded. (default 30)
  -cluster string
    	Comma separated list of cluster ID to fetch metric for. If not specified, the environment variable CCLOUD_CLUSTER will be used
  -config string
    	Path to configuration file used to override default behavior of ccloudexporter
  -connector string
    	Comma separated list of connector ID to fetch metric for. If not specified, the environment variable CCLOUD_CONNECTOR will be used
  -delay int
    	Delay, in seconds, to fetch the metrics. By default set to 120, this, in order to avoid temporary data points. (default 120)
  -endpoint string
    	Base URL for the Metric API (default "https://api.telemetry.confluent.cloud/")
  -granularity string
    	Granularity for the metrics query, by default set to 1 minutes (default "PT1M")
  -ksqlDB string
    	Comma separated list of ksqlDB application to fetch metric for. If not specified, the environment variable CCLOUD_KSQL will be used
  -schemaRegistry string
    	Comma separated list of Schema Registry ID to fetch metric for. If not specified, the environment variable CCLOUD_SCHEMA_REGISTRY will be used
  -listener string
    	Listener for the HTTP interface (default ":2112")
  -log-pretty-print
    	Pretty print the JSON log output (default true)
  -no-timestamp
    	Do not propagate the timestamp from the the metrics API to prometheus
  -timeout int
    	Timeout, in second, to use for all REST call with the Metric API (default 60)
  -verbose
    	Print trace level logs to stdout
  -version
    	Print the current version and exit

Examples

Building and executing

go get github.com/Dabz/ccloudexporter/cmd/ccloudexporter
go install github.com/Dabz/ccloudexporter/cmd/ccloudexporter
export CCLOUD_API_KEY=ABCDEFGHIKLMNOP
export CCLOUD_API_SECRET=XXXXXXXXXXXXXXXX
./ccloudexporter -cluster lkc-abc123

Using Docker

docker run \
  -e CCLOUD_API_KEY=$CCLOUD_API_KEY \
  -e CCLOUD_API_SECRET=$CCLOUD_API_SECRET \
  -e CCLOUD_CLUSTER=lkc-abc123 \
  -p 2112:2112 \
  dabz/ccloudexporter:latest

Using Docker Compose

export CCLOUD_API_KEY=ABCDEFGHIKLMNOP
export CCLOUD_API_SECRET=XXXXXXXXXXXXXXXX
export CCLOUD_CLUSTER=lkc-abc123
docker-compose up -d

In addition to the metrics exporter and Prometheus containers, the Docker Compose launch starts a Grafana on http://localhost:3000 (admin/admin). The launch pre-provisions a Prometheus datasource for the Confluent Cloud metrics and a default dashboard.

The Docker Compose service definitions include data volumes for both Prometheus and Grafana, so metrics data will be retained following docker-compose down and restored when containers are started again. To remove these volumes and start with empty Prometheus and Grafana databases, run docker-compose down --volumes.

Using Kubernetes

Kubernetes deployment with Prometheus Operator. These following lines assume there is Prometheus Operator already running in the cluster with label: release=monitoring. Add the list of cluster ids separated by spaces in ./kubernetes/ccloud_exporter.env, for example: CCLOUD_CLUSTERS=<cluster_id1> <cluster_id2> ....

cp ./ccloud_exporter.env-template ./kubernetes/ccloud_exporter.env
cd ./kubernetes
vim ./ccloud_exporter.env
make install

A Deployment and a Service object are deployed to a unique namespace. A ServiceMonitor CRD is deployed to the Prometheus Operator namespace.

To delete deployment: cd ./kubernetes && make remove

Configuration file

For more advanced deployment, you could specify a YAML configuration file with the -config flag. If you do not provide a configuration file, the exporter creates one from the provided flags.

Configuration

Global configuration

| Key | Description | Default value | |---------------------|---------------------------------------------------------------------------------------------------------------|----------------------------------------| | config.http.baseurl | Base URL for the Metric API | https://api.telemetry.confluent.cloud/ | | config.http.timeout | Timeout, in second, to use for all REST call with the Metric API | 60 | | config.listener | Listener for the HTTP interface | :2112 | | config.noTimestamp | Do not propagate the timestamp from the metrics API to prometheus | false | | config.delay | Delay, in seconds, to fetch the metrics. By default set to 120, this, in order to avoid temporary data points | 120 | | config.granularity | Granularity for the metrics query, by default set to 1 minute | PT1M | | config.cachedSecond | Number of second that data will be cached in-memory and returned to Prometheus. | 30 | | rules | List of rules that need to be executed to fetch metrics | |

Rule configuration

| Key | Description | |------------------------|---------------------------------------------------------------------------------------------------------------| | rules.clusters | List of Kafka clusters to fetch metrics for | | rules.connectors | List of connectors to fetch metrics for | | rules.ksqls | List of ksqlDB applications to fetch metrics for | | rules.schemaRegistries | List of Schema Registries id to fetch metrics for | | rules.labels | Labels to exposed to Prometheus and group by in the query | | rules.topics | Optional list of topics to filter the metrics | | rules.metrics | List of metrics to gather |

Examples of configuration files

A simple configuration to fetch metrics for a cluster: simple.yaml
A configuration to fetch metrics at the partition granularity for a few topics: partition.yaml

Default configuration

config:
  http:
    baseurl: https://api.telemetry.confluent.cloud/
    timeout: 60
  listener: 0.0.0.0:2112
  noTimestamp: false
  delay: 60
  granularity: PT1M
  cachedSecond: 30
rules:
  - clusters:
      - $CCLOUD_CLUSTER
    connectors:
      - $CCLOUD_CONNECTOR
    ksqls:
      - $CCLOUD_KSQL
    schemaRegistries:
      - $CCLOUD_SCHEMA_REGISTRY
    metrics:
      - io.confluent.kafka.server/received_bytes
      - io.confluent.kafka.server/sent_bytes
      - io.confluent.kafka.server/received_records
      - io.confluent.kafka.server/sent_records
      - io.confluent.kafka.server/retained_bytes
      - io.confluent.kafka.server/active_connection_count
      - io.confluent.kafka.server/request_count
      - io.confluent.kafka.server/partition_count
      - io.confluent.kafka.server/successful_authentication_count
      - io.confluent.kafka.connect/sent_bytes
      - io.confluent.kafka.connect/received_bytes
      - io.confluent.kafka.connect/received_records
      - io.confluent.kafka.connect/sent_records
      - io.confluent.kafka.connect/dead_letter_queue_records
      - io.confluent.kafka.ksql/streaming_unit_count
      - io.confluent.kafka.schema_registry/schema_co
