Rain

[!TIP] Example usage (hash everything):

 find . -type f -print0 | xargs -0 -I{} rainsum {}

This repository features the Rainbow and Rainstorm hash functions (collectively, Rain Hashes), created by Cris at DOSAYGO and licensed under Apache-2.0. All size variants of both hashes pass all tests in SMHasher3. Relevant results are available in the results/ directory, or at the SMHasher3 GitLab repository. The CLI tool API is similar to standard tools like sha256sum, but with more switches to select algorithm and digest length. The hashes produce digests ranging from 64 through to 512 bits wide. See the table below for details.

The codebase includes:

• A C++ reference implementation
• A WASM port (for Node.js and browser environments)
• A Makefile for building all targets
• An experimental cryptosystem based on plaintext mining ciphers

| Algorithm | Speed | Hash Size | Purpose | Core Mixing Function | Security | |-----------|--------------------|------------------|--------------------------------------|---------------------------------------------------|---------------------------------| | Rainbow | 3 - 6 GiB/s | 64, 128, 256 bits| General-purpose, non-crypto hash | Multiplication, addition/subtraction, rotation, XOR| Not designed as cryptographic | | Rainstorm | 2 - 3 GiB/s (4 rds)| 64, 128, 256, 512 bits | Proposed as a crypto-hash but requires analyses | Addition/subtraction, rotation, XOR | Unvetted, no formal analysis |

---

Table of Contents

• Usage Options
• Assets
• Building
• Benchmark
• Repository Structure
• Rainbow
• Rainstorm - Unvetted for Security
• Note on Cryptographic Intent
• Genesis
• License
• Rainsum Field Manual
  • 1. Introduction
  • 2. Basic Usage
    • 2.1 Command Structure
    • 2.2 Options
  • 3. Modes of Operation
    • 3.1 Digest Mode
    • 3.2 Stream Mode
  • 4. Hash Algorithms and Sizes
  • 5. Test Vectors
  • 6. Seed Values
  • 7. Help and Version Information
  • 8. Compilation
  • 9. Conclusion
• Developer Information
  • Stability
  • Test vectors
  • Building and Installing
  • Contributions
• Story
• Misue Disclaimer

---

Usage Options

JavaScript (WASM) Channel

1. Node.js Library Install:

   npm i @dosyago/rainsum@latest


   Usage:

   import { rainbowHash, rainstormHash } from '@dosyago/rainsum';

   const seed = 0x0;
   const hash = await rainbowHash(256, seed, 'Hello there!');
   const intendedCryptoHash = await rainstormHash(512, seed, Buffer.from('Hello there!'));


2. Global Binary via NPM

   npm i -g @dosyago/rainsum@latest
   jsrsum --help


Native Channel

1. Build everything (For WASM ensure Emscripten is installed):

   make clean && make
   sudo make install  # optional, installs 'rainsum' globally


   If you encounter troubles on macOS use the build script:

   ./scripts/build.sh


2. Use as a library or CLI:

   • Link rainstorm.o or rainbow.o into your project, or include tool.h and source files from ./src/.
   • Use the rainsum CLI directly:

     rainsum file.txt
     # By default: Rainbow, 256-bit hash
     rainsum --help


jsrsum (via NPM + WASM) mirrors the CLI/API of rainsum but runs slower.

---

Assets

• rainsum CLI tool and associated .o object files (C++)
• WASM binary
• JS CLI tool (jsrsum) with an ES Module API exporting rainbowHash and rainstormHash
• Scripts:
  • ./scripts/bench.mjs: Benchmark JS WASM vs C++
  • ./scripts/verify.mjs: Verify correctness
  • Other utility scripts

---

Building

make clean && make

Optional installation:

sudo make install

---

Benchmark

C++ vs WASM (Node.js)

These benchmarks highlight the performance gap between native C++ and the WASM-based implementation under Node.js:

Test Input & Size          Run   C++ Version        WASM Version       Speedup
10 bytes (input1)          1     6,964,250 ns     129,892,625 ns     18x (C++ wins!)
100 bytes (input2)         1     6,876,208 ns     127,928,542 ns     18x (C++ wins!)
1,000 bytes (input3)       1     6,583,125 ns     127,668,333 ns     19x (C++ wins!)
10,000 bytes (input4)      1     5,920,167 ns     127,438,666 ns     21x (C++ wins!)
100,000 bytes (input5)     1     6,214,916 ns     127,551,791 ns     20x (C++ wins!)
1,000,000 bytes (input6)   1     5,321,500 ns     126,986,167 ns     23x (C++ wins!)
10,000,000 bytes (input7)  1     9,879,042 ns     132,929,875 ns     13x (C++ wins!)
100,000,000 bytes (input8) 1    49,761,375 ns     207,500,917 ns      4x (C++ wins!)

Runs 2 and 3 show similar results, consistently demonstrating that the native C++ version outperforms the WASM variant by a factor of ~3x to ~25x, depending on input size.

---

Repository Structure

.
├─ LICENSE.txt
├─ Makefile
├─ README.md
├─ docs/
├─ js/
├─ rain/
│  ├─ bin/
│  └─ obj/
├─ results/
│  ├─ dieharder/
│  └─ smhasher3/
├─ scripts/
└─ src/
   ├─ common.h
   ├─ rainbow.cpp
   ├─ rainstorm.cpp
   ├─ rainsum.cpp
   ├─ tool.h
   └─ ...

---

Rainbow

Rainbow is a fast, general-purpose non-cryptographic hash that can produce 64-bit, 128-bit, or 256-bit hashes. It is simple, compact (~140 LOC), and passes all SMHasher3 tests for its 64-bit variant. Its prime-based mixing function yields strong avalanche properties.

---

Rainstorm - Unvetted for Security

Rainstorm is a slower, more complex hash function inspired by cryptographic designs. It supports output sizes of 64 to 512 bits and adjustable rounds. While it uses operations reminiscent of cryptographic hashes, it is not formally analyzed by any 3rd-party. Consider it experimental, but designed to be secure.

Documents

• Rainstorm Formal Spec (Draft): PDF
• Rainstorm Crypto Note: PDF

---

Note on Cryptographic Intent

Rainstorm's design includes concepts from cryptographic hashing, but without formal analysis, it should not be considered secure. Feedback and analysis are welcome.

---

Genesis

The mixing functions were inspired by Discohash and refined iteratively using SMHasher3 over a few weeks, guided by experience and intuition. Careful prime selection ensured broad avalanche properties.

---

License

Apache-2.0 © 2023 - 2024 Cris & DOSAYGO Corporation. With improvements © Frank J. T. Wojcik 2023

---

Rainsum Field Manual

1. Introduction

Rainsum is a CLI tool for hashing input data using Rainbow or Rainstorm. It supports two primary modes:

• Digest Mode: Produces a fixed-length hexadecimal output.
• Stream Mode: Iteratively feeds the hash back into itself to produce a variable-length stream of binary output.

A JavaScript WASM version (jsrsum) offers similar functionality at reduced speed.

2. Basic Usage

2.1 Command Structure

rainsum [OPTIONS] [INFILE]

If no INFILE is provided, input is read from standard input.

2.2 Options

• -m, --mode [digest|stream]: Default digest.
• -a, --algorithm [bow|storm]: Choose rainbow (bow) or rainstorm (storm). Default storm.
• -s, --size [64-256|64-512]: Hash size in bits. Default 256. Rainbow supports 64,128,256. Rainstorm supports 64,128,256,512.
• -o, --output-file FILE: Write output to FILE.
• -t, --test-vectors: Run test vectors.
• -l, --output-length HASHES: For stream mode, number of iterations.
• --seed VALUE: Sets the seed (64-bit number or string). A string seed is hashed by Rainstorm to produce a 64-bit seed.
• -h, --help: Show help.
• -v, --version: Print version.

3. Modes of Operation

3.1 Digest Mode

Produces a single, fixed-size hash in hex. For example:

rainsum -m digest -a storm -s 256 -o output.txt input.txt

3.2 Stream Mode

Generates a stream of hashes by repeatedly feeding the previous hash into the function. Specify iterations with -l. Example:

rainsum -m stream -a storm -s 512 -l 1000000 -o output.txt input.txt

4. Hash Algorithms and Sizes

• bow (Rainbow): 64, 128, 256 bits
• storm (Rainstorm): 64, 128, 256, 512 bits

5. Test Vectors

Use -t, --test-vectors to verify correctness against known inputs.

6. Seed Values

Use --seed to set a custom seed. String seeds are hashed to a 64-bit value.

7. Help and Version Information

• rainsum --help
• rainsum --version

8. Compilation

A modern C++17 compiler is required. Run make to build. Ensure necessary build tools (like xcode-select on macOS) are installed. On macOS you should use ./scripts/build.sh to ensure that path to the correct compiler and SDK is accurate, modify that script if needed for your system.

9. Conclusion

Rainsum provides flexible hashing through Rainbow or Rainstorm. Experiment freely and enjoy the convenience of multiple modes and sizes.

---
