This is a script for relaying messages to a MCZ Maestro pellet stove. All of this software is provided AS-IS with no implied warranty or liability under sections 15, and 16 of the GPL V3. So if your stove burns down your house, it's not my fault.

MCZ Maestro Equipment Gateway with Mqtt / JSON

Python script for controlling Pellet Stoves using Maestro technology.

It is known to work with newer pellet stoves from MZC Personally I use it using a MCZ Musa Hydro stove.

About Maestro

Maestro technology uses a Websocket to communicatie with the pellet stove. It is used by the MZC Maestro App and also by external thermostats. https://www.mcz.it/en/maestro-technology/

Usage

This script returns the websocket data and will publish it on MQTT topics which you can use in your home automation software. You can use this information to display the state of all parameters from the stove. Also all basic commands that you can send using the official MZC app are available on another MQTT topic.

After version 1.03 it's also possible to send diagnostics commands. For these commands you first have to put the stove in diagnostics mode. You can only put the stove in diagnostic mode when the stove is powered off. Diagnostic mode enables you to control some stove parameters that are normally not available. A use case is to control the 3 walve valve / water pump to get heat from a boiler. See commands.py for command list.

It can be installed locally or using docker, get the latest build from https://hub.docker.com/r/chibald/maestrogateway

Configuration

Configure by setting varables in config.py when running in local python mode, or by setting environment variables in docker.

| Variable | Description | | ----------------------- | ----------- | | MQTT_ip| Mqtt broker address | MQTT_port| Mqtt broker port, default 1883 | MQTT_authentication| use authentication, True / False | MQTT_user| Mqtt User name | MQTT_pass| Mqtt password | MQTT_TOPIC_SUB| Mqtt topic for command messages here | MQTT_TOPIC_PUB| Information messages by daemon are published here | MQTT_PAYLOAD_TYPE| Payload as seperate subtopic (_MQTT_PAYLOAD_TYPE='TOPIC') or as JSON (_MQTT_PAYLOAD_TYPE='JSON') | WS_RECONNECTS_BEFORE_ALERT| Attempts to reconnect to webserver before publishing a alert on topic PUBmcz/Status | MCZip| Stove IP Address. Default is 192.168.120.1 | MCZport| Stove websocket port. Default is 81

Recieving information

Data is polled from the stove every 15 seconds.

Payload type Json

If you use the Json payload type all the parameters wille be published to one topic using a json object:

{"Stove_State": 11, "Power": 1, "Diagnostics": 0, "Fan_State": 1, "DuctedFan1": 0, "DuctedFan2": 0, "Fume_Temperature": 155, "Ambient_Temperature": 23.5, "Puffer_Temperature": 127.5, "Boiler_Temperature": 62.5, "NTC3_Temperature": 127.5, "Candle_Condition": 0, "ACTIVE_Set": 156, "RPM_Fam_Fume": 708, "RPM_WormWheel_Set": 150, "RPM_WormWheel_Live": 300, "3WayValve": "Risc", "Pump_PWM": 100, "Brazier": "OK", "Profile": 0, "Modbus_Address": 11, "Active_Mode": 1, "Active_Live": 157, "Control_Mode": 1, "Eco_Mode": 0, "Silent_Mode": 1, "Chronostat": 0, "Temperature_Setpoint": 23.5, "Boiler_Setpoint": 80.0, "Temperature_Motherboard": 37.5, "Power_Level": 11, "FirmwareVersion": 68107, "DatabaseID": 28, "Date_Time_Hours": 14, "Date_Time_Minutes": 39, "Date_Day_Of_Month": 31, "Date_Month": 10, "Date_Year": 2021, "Total_Operating_Hours": "307:00:03", "Hours_Of_Operation_In_Power1": "194:18:37", "Hours_Of_Operation_In_Power2": "0:32:50", "Hours_Of_Operation_In_Power3": "0:34:39", "Hours_Of_Operation_In_Power4": "0:34:45", "Hours_Of_Operation_In_Power5": "22:31:17", "Hours_To_Service": 1692, "Minutes_To_Switch_Off": 212, "Number_Of_Ignitions": 170, "Active_Temperature": 0, "Celcius_Or_Fahrenheit": 0, "Sound_Effects": 0, "Sound_Effects_State": 0, "Sleep": 0, "Mode": 0, "WifiSondeTemperature1": 255, "WifiSondeTemperature2": 255, "WifiSondeTemperature3": 255, "Unknown": 255, "SetPuffer": 130, "SetBoiler": 100, "SetHealth": 255, "Return_Temperature": 127.5, "AntiFreeze": 0}
.....

the script will check if value has changed to prevent message flooding, so next messages are filtered for changes values only

for example:

{"Ambient_Temperature": 19.0}

Payload type topic

If you use payload type Topic, all the parameters will be published to a separate topic under the MQTT_TOPIC_PUB topic for example

Maestro/Status/Ambient_Temperature, 19.0

| Topic | Description | | ----------------------- | ----------- | | Maestro/Power | Current power state (on / off) | Maestro/Command/Power | Turn stove on or off | Maestro/Diagnostics | Current diagnostics state | Maestro/Command/Diagnostics | Set stove in diagnostics mode. Can only be set to diagnostics mode when stove is powered off. | Maestro/Command/Refresh | Clear the maestrogateway's message cache | Maestro/Command/GetInfo | Get stove info immediately (instead of waiting till next cycle) | Maestro/state | | Maestro/Stove_State | | Maestro/Fan_State | | Maestro/Command/Fan_State | | Maestro/DuctedFan1 | | Maestro/Command/DuctedFan1 | | Maestro/DuctedFan2 | | Maestro/Command/DuctedFan2 | | Maestro/Fume_Temperature | | Maestro/Ambient_Temperature | | Maestro/Puffer_Temperature | | Maestro/Boiler_Temperature | | Maestro/NTC3_Temperature | | Maestro/Candle_Condition | | Maestro/ACTIVE_Set | | Maestro/RPM_Fam_Fume | | Maestro/RPM_WormWheel_Set | | Maestro/RPM_WormWheel_Live | | Maestro/3WayValve | | Maestro/Command/3WayValve | | Maestro/Pump_PWM | current pumping speed (percentage) | Maestro/Command/Pump_PWM | Turn on the water pump. This only works when stove is in diagnostics mode | Maestro/Brazier | | Maestro/Profile | | Maestro/Modbus_Address | | Maestro/Active_Mode | | Maestro/Command/Active_Mode | | Maestro/Active_Live | | Maestro/Control_Mode | | Maestro/Command/Control_Mode | | Maestro/Eco_Mode | | Maestro/Command/Eco_Mode | | Maestro/Silent_Mode | | Maestro/Command/Silent_Mode | | Maestro/Chronostat | | Maestro/Command/Chronostat | | Maestro/Temperature_Setpoint | | Maestro/Command/Temperature_Setpoint | | Maestro/Boiler_Setpoint | | Maestro/Command/Boiler_Setpoint | | Maestro/Temperature_Motherboard | | Maestro/Power_Level | | Maestro/Command/Power_Level | | Maestro/FirmwareVersion | | Maestro/DatabaseID | | Maestro/Date_Time_Hours | | Maestro/Date_Time_Minutes | | Maestro/Date_Day_Of_Month | | Maestro/Date_Month | | Maestro/Date_Year | | Maestro/Total_Operating_Hours | | Maestro/Hours_Of_Operation_In_Power1 | | Maestro/Hours_Of_Operation_In_Power2 | | Maestro/Hours_Of_Operation_In_Power3 | | Maestro/Hours_Of_Operation_In_Power4 | | Maestro/Hours_Of_Operation_In_Power5 | | Maestro/Hours_To_Service | | Maestro/Minutes_To_Switch_Off | | Maestro/Number_Of_Ignitions | | Maestro/Active_Temperature | | Maestro/Celcius_Or_Fahrenheit | | Maestro/Sound_Effects | | Maestro/Command/Sound_Effects | | Maestro/Sleep | | Maestro/Mode | | Maestro/WifiSondeTemperature1 | | Maestro/WifiSondeTemperature2 | | Maestro/WifiSondeTemperature3 | | Maestro/SetPuffer | | Maestro/SetBoiler | | Maestro/SetHealth | | Maestro/Return_Temperature | | Maestro/AntiFreeze | | Maestro/Command/Chronostat_T1 | | Maestro/Command/Chronostat_T2 | | Maestro/Command/Chronostat_T3 |

Sending commands

Publish Json command on the command Mqtt - topic to issue commands.

Payload type Json

Examples: to turn on the stove:

{ "Command": "Power", "Value": 1}

to turn off the stove:

{ "Command": "Power", "Value": 0}

to set temperature to 20.5 degrees:

{ "Command": "Temperature_Setpoint", "Value": "20.5"}

payload type Topic

to turn on the stove:

Maestro/Command/Power, 1

to turn off the stove:

Maestro/Command/Power, 0

to set temperature to 20.5 degrees:

Maestro/Command/Temperature_Setpoint, 20.5

Hardware Prerequisities

The MCZ pellet stove has its own Wifi SSID. The easiest way to bridge this connection is by using a Raspberry pi with a wired ethernet to your lan, and to configure the onboard Wifi to connect to the SSID of the pellet stove. But any with two interface and at least one wifi interface to connect to the stove will work.

Software Prerequisities

You will need a Home Automation software with MQTT broker.

Openhab https://www.openhab.org/

Home Assistant https://www.home-assistant.io/

But it'll work with any HA system that can process and send MQTT / Json messages.

Connecting to your stove

Connect to the Wifi of the stove The pellet stove willl typically run at a designated ip address 192.168.120.1 (this is hard coded in the official app). So a good place to start is setting up a device like a RPI connected to the Wifi of the stove. Make sure you can ping the device at 192.168.120.1 before proceeding.

Docker Installation

It is possible to run maestrogateway inside a docker container. It requires the installation of docker and docker-compose. https://hub.docker.com/r/chibald/maestrogateway

1. Update docker-compose.yml as needed. See example below: Docker-compose example:

version: '3.3'
services:

  maestrogateway:
    image: chibald/maestrogateway:latest
    network_mode: host
    environment:
      MQTT_ip: 'broker.hivemq.com'
      MQTT_port: 1883
      MQTT_authentication: '
