CausalVerse: Benchmarking Causal Representation Learning with Configurable High-Fidelity Simulations

<p align="center"> <img src="./assets/causalverse_intro.png" alt="CausalVerse Overview Figure" width="85%"> <p align="center"> <a href="https://huggingface.co/CausalVerse"> <img alt="Hugging Face" src="https://img.shields.io/badge/HuggingFace-CausalVerse-ffad33?logo=huggingface&logoColor=white"> </a> <a href="https://huggingface.co/datasets/CausalVerse/CausalVerse_Image"> <img alt="Dataset" src="https://img.shields.io/badge/Dataset-CausalVerse_Image-ffad33?logo=huggingface&logoColor=white"> </a> <img alt="Python 3.9+" src="https://img.shields.io/badge/Python-3.9%2B-blue"> <img alt="NeurIPS 2025 Spotlight" src="https://img.shields.io/badge/NeurIPS-2025%20Spotlight-7b4ae2"> <img alt="Open Data" src="https://img.shields.io/badge/Data-Open-44cc11"> </p>

---

🔎 Overview

CausalVerse is a comprehensive benchmark for Causal Representation Learning (CRL) focused on recovering the data-generating process. It couples high-fidelity, controllable simulations with accessible and configurable ground-truth causal mechanisms (structure, variables, interventions, temporal dependencies), bridging the gap between realism and evaluation rigor.

The benchmark spans 24 sub-scenes across four domains:

• 🖼️ Static image generation
• 🧪 Dynamic physical simulation
• 🤖 Robotic manipulation
• 🚦 Traffic scene analysis

Scenarios range from static to temporal, single to multi-agent, and simple to complex structures, enabling principled stress-tests of CRL assumptions. We also include reproducible baselines to help practitioners align assumptions ↔ data ↔ methods and deploy CRL effectively.

👉 Project hub: https://huggingface.co/CausalVerse

---

🧭 Release

October 2025 — CausalVerse is now public (NeurIPS 2025 Spotlight)! 🎉

• ✅ Dataset usage scripts released
• ✅ Image-part evaluation code and baselines released

---

🗂️ Dataset at a Glance

<p align="center"> <img src="./assets/causalverse_overall.png" alt="CausalVerse Overview Figure" width="45%"> <img src="./assets/causalverse_pie.png" alt="CausalVerse data info Figure" width="49.4%"> </p>

• Scale & Coverage: ≈ 200k high-res images, ≈ 140k videos, >300M frames across 24 scenes in 4 domains
  • Image generation (4), Physical simulation (10; aggregated & dynamic), Robotic manipulation (5), Traffic (5)
• Resolution & Duration: typical 1024×1024 / 1920×1080; clips 3–32 s; diverse frame rates
• Causal Variables: 3–100+ per scene, including categorical (e.g., object/material types) and continuous (e.g., velocity, mass, positions). Temporal scenes combine global invariants (e.g., mass) with time-evolving variables (e.g., pose, momentum).

Hugging Face

• <a href="https://huggingface.co/CausalVerse"> <img src="https://huggingface.co/front/assets/huggingface_logo-noborder.svg" width="18" alt="🤗" /> Org: CausalVerse </a>
• <a href="https://huggingface.co/datasets/CausalVerse/CausalVerse_Image"> <img src="https://huggingface.co/front/assets/huggingface_logo-noborder.svg" width="18" alt="🤗" /> Dataset: CausalVerse_Image </a>

---

⚙️ Installation

# 1) Clone
git clone https://github.com/<your-org>/CausalVerse.git
cd CausalVerse

# 2) Core environment
python3 --version    # >= 3.9 recommended
pip install -U torch datasets huggingface_hub pillow tqdm

# 3) Optional: examples / loaders / transforms
pip install torchvision scikit-learn rich

---

⬇️ Download & Convert (Image subset)

Fetch the image portion from Hugging Face and export to a simple on-disk layout (PNG files + per-split CSVs).

Quick start (recommended)

chmod +x dataset/run_export.sh
./dataset/run_export.sh

This will:

• download parquet shards (skip if local),
• export images to image/<SPLIT>/*.png,
• write <SPLIT>.csv next to each split with metadata columns + a render_path column.

Output layout

image/
  FALL/
    FALL.csv
    ...
  SCENE1/
    SCENE1.csv
    ...

<details> <summary><b>Custom CLI usage</b></summary>

python dataset/export_causalverse_image.py \
  --repo-id CausalVerse/CausalVerse_Image \
  --hf-home ./.hf \
  --raw-repo-dir ./CausalVerse_Image \
  --image-root ./image \
  --folder-case upper \
  --no-overwrite \
  --include-render-path-column \
  --download-allow-patterns data/*.parquet \
  --skip-download-if-local

# Export specific splits (case-insensitive)
python dataset/export_causalverse_image.py --splits FALL SCENE1

</details>

---

🧩 Using the Image Dataset (PyTorch-ready)

We provide a reference PyTorch dataset/loader that works with exported splits.

• Core class: dataset/dataset_multisplit.py → MultiSplitImageCSVDataset
• Builder: build_dataloader(...)
• Minimal example: dataset/quickstart.py

Conventions

• Each split folder contains <SPLIT>.csv + .png files
• CSV must include render_path (relative to the repository root or chosen data root)
• All remaining CSV columns are treated as metadata and packed into a float tensor meta

Quick example

from dataset.dataset_multisplit import build_dataloader
# Optional torchvision transforms:
# import torchvision.transforms as T
# tfm = T.Compose([T.Resize((256, 256)), T.ToTensor()])

loader, ds = build_dataloader(
    root="/path/to/causalverse",
    split="SCENE1",
    batch_size=16,
    shuffle=True,
    num_workers=4,
    pad_images=True,  # zero-pads within a batch if resolutions differ
    # image_transform=tfm,
    # check_files=True,
)

for images, meta in loader:
    # images: FloatTensor [B, C, H, W] in [0, 1]
    # meta  : FloatTensor [B, D] with ordered metadata (including 'view' if present)
    ...

view column semantics: • Physical splits (e.g., FALL/REFRACTION/SLOPE/SPRING): camera viewpoint • Human rendering splits (SCENE1–SCENE4): indoor background type

---

📊 Evaluation (Image Part)

We release four reproducible baselines (shared backbone & similar training loop for fair comparison):

• CRL_SC — Sufficient Change
• CRL_SF — Mechanism Sparsity
• CRL_SP — Multi-view
• SUP — Supervised upper bound

How to run

# From repo root, run each baseline:
cd evaluation/image_part/CRL_SC && python main.py
cd ../CRL_SF && python main.py
cd ../CRL_SP && python main.py
cd ../SUP && python main.py

# Example: pass data root via env or args
# DATA_ROOT=/path/to/causalverse python main.py

Full comparison (MCC / R²)

| Algorithm | Ball on the Slope<br>_{MCC / R²} | Cylinder Spring<br>_{MCC / R²} | Light Refraction<br>_{MCC / R²} | Avg<br>_{MCC / R²} | |---|---:|---:|---:|---:| | Supervised | 0.9878 / 0.9962 | 0.9970 / 0.9910 | 0.9900 / 0.9800 | 0.9916 / 0.9891 | | Sufficient Change | 0.4434 / 0.9630 | 0.6092 / 0.9344 | 0.6778 / 0.8420 | 0.5768 / 0.9131 | | Mechanism Sparsity | 0.2491 / 0.3242 | 0.3353 / 0.2340 | 0.1836 / 0.4067 | 0.2560 / 0.3216 | | Multiview | 0.4109 / 0.9658 | 0.4523 / 0.7841 | 0.3363 / 0.7841 | 0.3998 / 0.8447 | | Contrastive Learning | 0.2853 / 0.9604 | 0.6342 / 0.9920 | 0.3773 / 0.9677 | 0.4323 / 0.9734 |

Ablations can be reproduced by editing each method’s main.py or adding configs (e.g., split selection, loss weights, target subsets).

---

🎬 Video Part

The video_part/ directory contains the video-based temporal CRL pipeline used in this repository. It includes data preprocessing to latent sequences, training code for temporal CRL methods, and evaluation code for representation-level metrics such as MCC and R² on video datasets including physical simulation and robotics settings.

For detailed usage and method-specific settings, refer to the corresponding paths inside video_part/.

---

🙌 Acknowledgements

We thank the open-source community and the simulation/rendering ecosystem. We also appreciate contributors who help improve CausalVerse through issues and pull requests.

---

📚 Citation

If CausalVerse helps your research, please cite:

@inproceedings{causalverse2025,
  title     = {CausalVerse: Benchmarking Causal Representation Learning with Configurable High-Fidelity Simulations},
  author    = {Guangyi Chen and Yunlong Deng and Peiyuan Zhu and Yan Li and Yifan Shen and Zijian Li and Kun Zhang},
  booktitle = {NeurIPS},
  year      = {2025},
  note      = {Spotlight},
  url       = {https://huggingface.co/CausalVerse}
}
