Gridfinity Label Generator

Web generator: https://cnckitchen.github.io/gridfinityLabelGenerator/

A browser-based tool that generates custom STL labels for Gridfinity bins. Everything runs entirely in the browser — no server or install required for the deployed version.

What it does

The generator composites a base label STL with embossed text and clipart icons, then exports the result as a ready-to-slice .stl file. Labels are designed for a single 1× Gridfinity tile but can be scaled to 2× or 3× width.

Each label consists of:

Icon (left side): one of 10 clipart symbols (hex, nut, nylock, washer, large washer, lock washer, insert, torx, phillips, slot)
Line 1 (top right): text, auto-sized to fill the available box
Line 2 (bottom right): text, or one of 10 technical screw-profile images (button head, countersunk, cylinder head, grub screw, hex head, low head, pan head, and self-tapping variants)
Emboss depth: 0.4 mm — matches a single layer at 0.4 mm layer height, ideal for colour-change printing

Modes

Custom label

Enter your own text and pick an icon. Exports a single .stl.

Predefined labels

Select from a curated catalogue of CNC Kitchen fasteners and inserts. Exporting one label gives an .stl; exporting multiple gives a .zip with one file per label.

Categories:

Heat inserts — metric (M2–M10) and imperial (#2-56–3/8″-16), various lengths
Socket head cap screws — M1.6–M5, lengths from 3–45 mm, each labelled with its Torx drive size (TX5–TX25)
Hex nuts — M2–M8
Nylock nuts — M2–M8
Standard washers — M2–M8
Large washers — M2–M8

Printing tips

Layer height: 0.2 mm
Colour change: in layer 3 (so the embossed text prints in a contrasting colour)
Wall generator: Arachne recommended for sharper detail on thin strokes

How it works

STL generation runs entirely in the browser using Three.js:

Loads GridfinityBinLabel.stl as the base geometry
Parses SVG clipart with SVGLoader, extrudes to 3D and scales it into the icon box
Generates font glyphs from helvetiker_bold.typeface.json using a custom tracking function (tighter letter spacing so the auto-sizer chooses a larger font size, keeping strokes thicker and more slicer-friendly)
Extrudes all text and icon shapes to 0.4 mm depth and positions them on the label surface
For 2× or 3× wide labels, widens the base geometry and centres the content accordingly
Exports the combined mesh as a binary STL via STLExporter

Project structure

web/      React + Vite front-end — this is what gets deployed
server/   Express API with equivalent server-side STL generation (not used by the deployed site)

Run locally

cd web
npm install
npm run dev

Opens at http://localhost:5173. No backend needed — all generation happens in-browser.

Build

cd web
npm run build

Output goes to web/dist/. The base: "./" setting in vite.config.ts ensures assets use relative paths, so the build works on GitHub Pages and any subdirectory host.
