CockpitOS

<p align="center"> <img src="./CockpitOS_logo_small.png" alt="CockpitOS" width="400"> </p> <h3 align="center">Build real cockpit panels for DCS World</h3> <p align="center"> ESP32 firmware that connects physical switches, LEDs, displays, and gauges<br> to DCS World through the DCS-BIOS protocol. No programming required. </p> <p align="center"> <a href="https://github.com/BojoteX/CockpitOS/actions/workflows/ci-build.yml"><img src="https://github.com/BojoteX/CockpitOS/actions/workflows/ci-build.yml/badge.svg" alt="Build"></a> <a href="https://github.com/BojoteX/CockpitOS/releases/latest"><img src="https://img.shields.io/github/v/release/BojoteX/CockpitOS?label=latest" alt="Release"></a> <a href="https://github.com/BojoteX/CockpitOS/blob/main/LICENSE"><img src="https://img.shields.io/github/license/BojoteX/CockpitOS" alt="License"></a> <a href="https://github.com/BojoteX/CockpitOS/stargazers"><img src="https://img.shields.io/github/stars/BojoteX/CockpitOS?style=flat" alt="Stars"></a> </p>

---

Quick Start

Open a terminal (CMD or PowerShell) and paste:

powershell -c "irm https://bojotex.github.io/CockpitOS/install.ps1 | iex"

That's it. The installer handles Python, downloads the latest release, and launches the Setup tool.

Prefer a manual install? Install Python 3.10+, download CockpitOS, unzip, and double-click START.py.

---

What is CockpitOS?

CockpitOS is ESP32 firmware that turns off-the-shelf dev boards into fully functional DCS World cockpit controllers. It runs natively across the entire ESP32 family -- Classic, C3, C5, C6, P4, S2, and S3 -- and supports buttons, switches, encoders, LEDs, segment displays, TFT gauges, and stepper motors out of the box.

Three bundled Python tools handle the entire workflow -- setup, compilation, and panel configuration -- so you never touch the Arduino IDE or edit source files by hand.

Think of it as the DCS-BIOS Arduino Library reimagined for performance and scale on ESP32.

---

Features

<table> <tr> <td width="50%" valign="top">

Inputs

• Buttons, toggles, rotary encoders, multi-position selectors
• Analog axes with self-calibration
• I2C expanders (PCA9555), shift registers (74HC165)
• Matrix scanning for rotary switches
• Built-in debouncing and edge detection

</td> <td width="50%" valign="top">

Outputs

• GPIO LEDs with PWM dimming
• WS2812 addressable RGB LEDs
• TM1637 and GN1640T LED segment drivers
• HT1622 segment LCD displays (IFEI, UFC, etc.)
• SPI/RGB TFT gauges via LovyanGFX
• Stepper motors (28BYJ-48, X27.168)

</td> </tr> <tr> <td width="50%" valign="top">

Connectivity

• USB HID (recommended) -- no drivers needed
• WiFi UDP -- for wireless panels
• BLE -- Bluetooth Low Energy
• Serial -- legacy support (socat)
• RS485 -- multi-device bus networking

</td> <td width="50%" valign="top">

Architecture

• Static memory allocation -- zero heap fragmentation
• Non-blocking I/O throughout -- no watchdog resets
• O(1) label lookups via perfect hashing
• 250 Hz input polling, 30-60 Hz display refresh
• Per-aircraft configuration via Label Sets

</td> </tr> </table>

---

Supported Hardware

| MCU | USB | WiFi / BLE | Status | |-----|-----|------------|--------| | ESP32-S2 | Native USB | WiFi only | Recommended | | ESP32-S3 | Native USB | WiFi + BLE | Recommended | | ESP32 (Classic) | -- | WiFi + BLE | Serial/WiFi only | | ESP32-C3 / C6 | -- | WiFi + BLE | Serial/WiFi only | | ESP32-P4 | Native USB | -- | USB/Serial only |

Popular boards: LOLIN S2 Mini, LOLIN S3 Mini, or any S2/S3 dev board.

---

How It Works

 DCS World  ──>  DCS-BIOS (Lua)  ──>  CockpitOS (ESP32)  ──>  Your Panel
     ^                                        |
     └────────────────────────────────────────┘
                    Commands flow back

DCS-BIOS exports cockpit state from the simulator as a binary stream. CockpitOS receives this data and drives your physical hardware -- LEDs light up, displays update, gauges move. When you flip a switch, CockpitOS sends the command back through DCS-BIOS to the sim.

---

Bundled Tools

| Tool | What it does | |------|-------------| | Setup Tool (Setup-START.py) | Installs ESP32 board support and libraries via bundled arduino-cli | | Compiler (CockpitOS-START.py) | Compiles and uploads firmware -- select board, transport, label set | | Label Creator (LabelCreator-START.py) | Visual editors for inputs, LEDs, displays, segments, and pins |

All tools are Windows-native TUI applications. They switch between each other seamlessly.

---

Label Sets

Label Sets define your panel's configuration. Each one lives in src/LABELS/LABEL_SET_<name>/ and contains:

| File | Purpose | |------|---------| | InputMapping.h | Buttons, switches, encoders -- their pins and DCS-BIOS commands | | LEDMapping.h | LEDs and indicators -- hardware type and DCS-BIOS bindings | | DisplayMapping.cpp/h | Display field definitions for segment LCDs and TFTs | | CustomPins.h | Pin assignments and feature enables | | LabelSetConfig.h | Device name, USB PID, panel metadata |

Label sets are created and edited using the Label Creator tool. Hash tables and runtime data are auto-generated.

---

Documentation

| Guide | Description | |-------|-------------| | Getting Started | Environment setup guide | | Quick Start Guide | Build your first panel in 30 minutes | | Tools Overview | Setup Tool, Compiler, Label Creator | | Hardware Guides | Wiring for all input/output types | | How-To Guides | Step-by-step tutorials | | Config Reference | Complete Config.h flag reference | | Transport Modes | USB, WiFi, Serial, BLE configuration | | DCS-BIOS Integration | Protocol details and debug tools | | Advanced Topics | Custom panels, CoverGate, display pipeline | | FAQ & Troubleshooting | Common questions and solutions |

---

Need Help?

| Resource | Link | |----------|------| | AI Assistant | Chat with CockpitOS Assistant -- knows the entire codebase | | Web Uploader | Flash firmware from the browser |

---

Project Structure

CockpitOS/
+-- CockpitOS.ino          # Entry point
+-- Config.h               # Master config (transport, debug, timing)
+-- Mappings.cpp/h         # Panel init/loop orchestration
+-- src/
|   +-- Core/              # DCSBIOSBridge, HIDManager, LEDControl, InputControl
|   +-- Panels/            # Panel implementations (IFEI, TFT gauges, etc.)
|   +-- Generated/         # Auto-generated PanelKind.h
|   +-- LABELS/            # Aircraft/panel configurations (one folder per label set)
|       +-- _core/         # Generator modules and aircraft JSON data
+-- compiler/              # Compiler tool (cockpitos.py)
+-- label_creator/         # Label Creator tool (label_creator.py)
+-- lib/CUtils/            # Hardware drivers (GPIO, I2C, displays, steppers)
+-- HID Manager/           # PC-side USB HID bridge
+-- Debug Tools/           # UDP console, stream recorder/player
+-- Docs/                  # Full documentation

---

Requirements

• Windows 10/11
• Python 3.12+ (or from the Microsoft Store)
• DCS World with DCS-BIOS installed

Everything else is installed automatically by the Setup Tool.

---

Design Principles

• No dynamic memory -- All buffers statically allocated, no heap fragmentation over long sessions
• No blocking calls -- State machines and interrupts, never delay()
• Bounded execution -- All loops have iteration limits, watchdog-safe
• Fail-safe defaults -- Graceful handling of disconnections, transport loss, and protocol errors

---

<details> <summary><strong>For Developers</strong> -- Internal architecture details</summary>

Protocol Implementation

CockpitOS adapts to DCS-BIOS, it doesn't reinvent it. We kept the original protocol.cpp state machine intact -- the same sync-frame detection, address parsing, and delta-compressed 16-bit word handling. The wire format is efficient; we saw no reason to change it.

Transport Abstraction

Panel logic (inputs, LEDs, displays) is fully decoupled from the data transport:

+------------------------------------------------------------------+
|                         PANEL LOGIC                               |
|          (subscriptions, callbacks, hardware drivers)             |
+------+-------+--------+--------+--------+-----------+
       |       |        |        |        |
   USB HID    BLE   WiFi UDP   Serial   RS485

Swapping transports requires no panel code changes. This also means the architecture could theoretically adapt to different protocols -- if another sim exposed a binary stream with address/value pairs, you'd swap the transport layer, not rewrite panels.

Selective Subscriptions (Label Sets)

Traditional DCS-BIOS clients receive the entire aircraft state -- every address, every update, whether you need it or not. CockpitOS inverts this:

• Each Label Set defines which DCS-BIOS addresses the panel cares about
• At compile time, hash tables are generated for O(1) address lookup
• At runtime, irrelevant addresses are skipped in microseconds
• Result: A panel with 50 controls doesn't process 2,000+ addresses per frame

This
