PyGpPhs Package

The PyGpPhs package is designed for utilizing Gaussian Process for port-Hamiltonian system.

The PyGpPhs toolbox is developed using Python and C++. The main structure of the toolbox is written in Python while a few computationally expensive functions, such as the kernel and Cholesky decomposition functions, are written in C++ . While two languages are used to develop the PyGpPhs toolbox, the important notions of encapsulation and abstraction are largely employed. Utilizing C++ data types and function calls are handled internally by the model class, thus leaving no explicit overheads for the users to consider the C++ internal workings or invoke function calls.

Installation

Requirements:

• Python>=3.8
• numpy>=1.18.0
• torch>=1.8.0
• scipy>=1.4.0
• gpytorch>=1.5.0

Installation Instruction: The heart of PyGpPhs is located in the folder "PyGpPhs". It is essential to clone the folder repository locally in order to utilize the functionality of the model.

1, Open the terminal and navigate to a desired directory

2, Type in the following git command to clone the repository

git clone https://github.com/PyGpPhs-Source/PyGpPhs.git

3, The repository should be seen at your desired directory. User can refer to the "example.py" for more information on how to use the package. The main.py file, or any file as the driver to the simulation, can be located either inside PyGpPhs folder or outside. "example.py" shows an demonstration of running the driver file outside the toolbox directory. Inside the PyGpPhs folder, user can see "main.py" as an example of running the driver file.

Important dependency: This package relies on the following packages in python:

• gpytorch (Gaussian Process regression to take gradients on)
• scipy.integrate (integration of state variable)
• numpy (generic mathematical programming)
• ctypes (handling communication and results between python and C\C++)
• glob (reading .so files, compiled from C\C++, from python)

Important libraries from C++ is:

• Eigen Dense (For fast matrix computations)
• stl vector class which should be already included.

Please note that we tested the toolbox can successfully run on machine that has Apple Silicon or Windows 64-bit machines

The .so and .dll files are pre-compiled for use. For Mac machines, .so files are provided and python script will directly handle the internal and external interactions with .so. Hence, everything should run on Mac. For Windows machines, the .dll extension files are offered and integrated. The python script will automatically handle internal and external interactions with .dll, leaving no user overheads.

However, for some users whose computer does not read .dll or .so files, it is sometimes necessary to recompile the .c and .cpp files used. The toolbox has not extended to Linux machines (thanks to a reviewer who report this issue), future releases will address this issue.

To do that:

• Navigate to the PyGpPhs folder
• Depending on the platform, the desired format should be compiled. The idea is to first compile into .o or .obj files, then make them into platform specific format (.so, or .dll, and so on). Instructions for .so and .dll is listed below:
• Select the platform oriented version (mac/windows) of Cholesky_decomp file
• follow the comment instruction at the top by typing into terminal(.so)
• Select platform oriented version of PHSkernel_se_CPP (whether windows or mac version)
• follow the comment instruction by typing into terminal (for .so or .dll)

Magnet Oscillator explaination:

Example.py explaination: The example simulation serves as a reference and instructor to use PyGpPhs toolbox. The example, or case-study, is a nonlinear magnet oscillator system shown below:

The parameters to the port-Hamiltonian system is given to be:

H(x) = \frac{x_1^2}{2}+2\cos(x_1)+\frac{x_2^2}{2}-1

G(x)=[0, 1]^T

u(t)=0.1\sin(t)

J-R=\begin{bmatrix}
        0&1\\\
        -1&-r
    \end{bmatrix}, \text{ where }r=0.1.

Please note that larger number of data is correlated with, in general, better and more accurate predictions. The example.py has set number of training data to be 101 for efficiency purposes. while more data points will benefit the prediction accuracy, the time to run the program will increase accordingly.

To have better results, user can set the variable "number_of_data" to be higher. In the paper, number has been set to 50: this means data from first 50 seconds of the magnet oscillator system were observed, translating to 501 data points.

Reference:

gpytorch

Theory and Paper
