LiquidGlass

<p align="center"> <img src="Docs/Logo.png" width="380" alt="LiquidGlass logo" /> </p>

Metal-powered frosted glass effect with real-time background blur for SwiftUI and UIKit

A Swift library that creates liquid glass visual effects using custom Metal shaders. Automatically captures and blurs the view hierarchy behind UI elements without manual screenshot management.

<p align="center"> <a href="https://swiftpackageindex.com/BarredEwe/LiquidGlass"><img src="https://img.shields.io/badge/Swift_Package-Compatible-5E5E5E?style=for-the-badge&logo=swift"/></a> <img src="https://img.shields.io/badge/iOS‑14%2B-blue?style=for-the-badge&logo=apple"/> <img src="https://img.shields.io/badge/Swift‑5.9-orange?style=for-the-badge&logo=swift"/> <img src="https://img.shields.io/badge/License-MIT-green?style=for-the-badge"/> </p>

---

What is LiquidGlass?

LiquidGlass is an iOS library that creates a translucent frosted glass effect with blur and refraction. Unlike standard UIVisualEffectView, this implementation uses custom Metal shaders and view hierarchy capturing to achieve more advanced visual effects with fine-grained control over update frequency and appearance.

✨ Features

| | | | ---------------------------- | -------------------------------------------------------------------------------------------------- | | 🔍 Automatic capture | Background is captured automatically – just drop liquidGlassBackground on any view. | | ⚡ Real‑time rendering | Optimised MTLTexture snapshots + lazy redraw; redraws only when the background actually changes. | | 🛠 Flexible update modes | .continuous, .once, .manual via the updateMode parameter. | | 🧩 SwiftUI + UIKit | Works seamlessly in both frameworks with native APIs and shared Metal backend. | | 💤 Battery‑friendly | MTKView stays paused until the provider notifies it – no wasted frames. | | 🎨 Customizable shader | Modify Metal shader code to adjust blur, refraction, and visual effects. |

🛠 Installation

Add LiquidGlass through Swift Package Manager:

https://github.com/BarredEwe/LiquidGlass.git

Or via Xcode → File → Add Package Dependencies…
Select LiquidGlass and you're done.

🚀 Quick Start

SwiftUI

import SwiftUI
import LiquidGlass

Button("Glass Text") { }
    .liquidGlassBackground(cornerRadius: 60)

UIKit

import UIKit
import LiquidGlass

// Using extension (recommended)
button.addLiquidGlassBackground(cornerRadius: 25)

// Or using LiquidGlassUIView directly
let glassView = LiquidGlassUIView(cornerRadius: 30, blurScale: 0.8)
containerView.addSubview(glassView)

How It Works

LiquidGlass uses a four-stage pipeline to achieve the glass effect:

1. Hierarchy Capture — HierarchySnapshotCapturer renders the entire view hierarchy above the glass view into a CGImage
2. Texture Creation — BackgroundTextureProvider converts the image to MTLTexture and applies GPU-based blur
3. Metal Rendering — MetalShaderView.Coordinator renders the effect through MTKView with custom fragment shader
4. Update Management — Depending on updateMode, the background updates automatically or on-demand

🖼 Examples

SwiftUI Example

<table> <tr> <td width="50%">

import SwiftUI
import LiquidGlass

struct ContentView: View {
    var body: some View {
        ZStack {
            AnimatedColorsMeshGradientView()

            VStack(spacing: 20) {
                Text("Liquid Glass Button")
                    .font(.title.bold())
                    .foregroundColor(.white)

                Button("Click Me 🔥") {
                    print("Tapped")
                }
                .foregroundStyle(.white)
                .font(.headline)
                .padding()
                .liquidGlassBackground(cornerRadius: 60)
            }
        }
    }
}

</td> <td width="50%" align="center"> <img src="Docs/Example.gif" width="340" alt="LiquidGlass live example" /> </td> </tr> </table>

UIKit Example

import UIKit
import LiquidGlass

class ViewController: UIViewController {
    override func viewDidLoad() {
        super.viewDidLoad()

        let button = UIButton(type: .system)
        button.setTitle("Glass Button", for: .normal)
        button.setTitleColor(.white, for: .normal)

        // Add liquid glass background
        button.addLiquidGlassBackground(
            cornerRadius: 25,
            updateMode: .continuous(interval: 0.1),
            blurScale: 0.7,
            tintColor: .white.withAlphaComponent(0.1)
        )

        view.addSubview(button)
        // ... setup constraints
    }
}

⚙️ Update Modes

| Mode | What it does | Best for | | ------------------------ | ----------------------------------------- | ------------------------------------------- | | .continuous(interval:) | Captures every n seconds. | Animating backgrounds, parallax, fancy UIs. | | .once | Captures exactly one frame. | Static dialogs, settings sheets. | | .manual | Capture only when you call invalidate() | Power‑saving, custom triggers. |

SwiftUI

Button("Glass Button") { }
    .liquidGlassBackground(
        cornerRadius: 20,
        updateMode: .continuous(interval: 0.1),
        blurScale: 0.5
    )

UIKit

// Using extension
button.addLiquidGlassBackground(updateMode: .manual)

// Manual invalidation
button.liquidGlassBackground?.invalidateBackground()

// Using LiquidGlassUIView directly
let glassView = LiquidGlassUIView(updateMode: .once)
glassView.invalidateBackground() // for manual updates

🎛 API Reference

SwiftUI Modifier

.liquidGlassBackground(
    cornerRadius: CGFloat = 20,                          // Corner radius
    updateMode: SnapshotUpdateMode = .continuous(),      // Update frequency
    blurScale: CGFloat = 0.3,                            // Blur intensity (0.0-1.0)
    tintColor: UIColor = .white.withAlphaComponent(0.1) // Tint color overlay
)

LiquidGlassUIView

// Initialization
let glassView = LiquidGlassUIView(
    cornerRadius: 20,
    updateMode: .continuous(),
    blurScale: 0.5,
    tintColor: .gray.withAlphaComponent(0.2)
)

// Properties (all animatable with UIView.animate)
glassView.cornerRadius = 25
glassView.blurScale = 0.8
glassView.tintColor = .blue.withAlphaComponent(0.1)
glassView.updateMode = .manual

// Methods
glassView.invalidateBackground()  // Force update

UIView Extensions

// Add glass background (fills entire view)
view.addLiquidGlassBackground(cornerRadius: 20)

// Add glass background with custom frame
view.addLiquidGlassBackground(
    frame: CGRect(x: 0, y: 0, width: 200, height: 50),
    cornerRadius: 25
)

// Access glass backgrounds
let glassView = view.liquidGlassBackground        // First glass view
let allGlassViews = view.liquidGlassBackgrounds   // All glass views

// Remove glass backgrounds
view.removeLiquidGlassBackgrounds()

🎨 Shader Customization

Modify Sources/LiquidGlass/Shaders/LiquidGlassShader.metal to customize the visual effect:

• sampleBackground() — Distort UV coordinates, add wave/ripple effects
• postProcess() — Adjust saturation, add vignette, chromatic aberration, bloom

Example Modification

// In LiquidGlassShader.metal
float3 sampleBackground(float2 uv, texture2d<float> bgTexture, sampler bgSampler) {
    // Add wave distortion
    float wave = sin(uv.y * 10.0 + uniforms.time) * 0.01;
    uv.x += wave;

    return bgTexture.sample(bgSampler, uv).rgb;
}

📈 Performance

Optimizations:

• Snapshot covers only the area behind the glass – minimal memory footprint
• Layers above the glass are never hidden → no flicker
• Lazy redraw means nearly zero GPU usage when nothing changes
• Capture happens at reduced scale (0.8× screen scale) for memory savings
• UIKit and SwiftUI versions share the same optimized Metal backend

Recommendations:

• Use .once for static UI (dialogs, modals)
• Use .continuous(interval: 0.05) (≈20 FPS) for animated backgrounds
• Avoid many simultaneous glass views
• Test on real devices, not just simulator

📱 Requirements

• iOS 14.0+
• Swift 5.9+
• Xcode 15.0+
• Metal-capable device

⚠️ Known Limitations

• View hierarchy only — Cannot capture other windows
• Metal required — Won't work on very old devices without GPU support
• Performance — High update frequencies may impact older devices (A9 and below)
• SwiftUI layout — Background captures the underlying view hierarchy, not SwiftUI's logical structure

🙋‍♂️ FAQ

The glass doesn't update when I scroll.
Use .continuous(interval: 0.016) (≈60 fps) or trigger .manual's invalidate() in scrollViewDidScroll.

Can I animate the glass properties?
Yes! In UIKit, all properties (cornerRadius, blurScale, tintColor) are animatable with UIView.animate().

How do I use this in a table view cell?
Use .once or .manual update mode for better performance, and call invalidateBackground() when the cell is reused.

Can I mix SwiftUI and UIKit glass views?
Absolutely! They use the same Metal backend and work seamlessly together.

Why does this look different from Apple's Liquid Glass?
This is an independent implementation of a similar effect. Apple's official Liquid Glass is available only in iOS 26+ and uses private APIs.

What's the performance impact?
Minimal when using .once or .manual. With .continuous, e
