MacroNASBenchmark

These NAS benchmarks for CIFAR10/100 are used in the paper:

Den Ottelander T., Dushatskiy A., Virgolin M., and Bosman P. A. N.: Local Search is a Remarkably Strong Baseline for Neural Architecture Search. arXiv:2004.08996 (2020) https://arxiv.org/abs/2004.08996

Features

These NAS benchmarks aim at providing the community with a new tool for evaluating the performance of search algorithms for NAS. Some features which make it different from existing alternative approaches:

• Search is performed at macro-level: cell types are the discrete variables, they are not repeated, the number of non-trivial cells is flexible (see example below)
• All solutions in the considered search space are feasible to make the usage easier with almost any search algorithm
• We believe it's better suited for benchmarking multi-objective optimization algorithms (see the paper)
• Quite a large search space: >200K unique architectures

Benchmarks description

• All considered architectures consist of 14 searchable and some fixed cells
• Each cell can have three options:
  1. Identity: a placeholder to allow nets of different depths (encoded as 'I')
  2. MBConv with expansion rate 3, kernel size 3x3 (encoded as '1')
  3. MBConv with expansion rate 6, kernel size 5x5 (encoded as '2')
• A net from the search space having the best validation accuracy on CIFAR10 (pic by @tdenottelander): <img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/net_example.png" width="800"/>

Benchmarks usage

To test your search algorithm on benchmarks:

• install git lfs and do git clone
• Data for CIFAR/CIFAR100 stored in benchmark_cifar10_dataset.json, benchmark_cifar100_dataset.json respectively
• In json files there are all (possibly including identity cells) models of the search space (>4M) as keys, solutions encoding is described above

Benchmarks creation & reproducibility

To reproduce benchmarks or change some hyperparameters and obtain your own version of them (an example for CIFAR10):

0. install git lfs and do git clone

1. pip3 install --user -r requirements.txt

2. Trained supernet models are provided in benchmark_cifar10/. If you want to re-train, delete existing models and run: ./scripts/train_supernet_cifar10.sh

   • By default, GPU #0 is used
   • When using for the first time, CIFAR dataset will be downloaded and placed to /datasets
   • Data split is fixed and stored in benchmark_cifar10/
   • The trained supernet (with and without SWA ensembling) will be placed in benchmark_cifar10/

3. To evaluate models: ./scripts/do_evaluations_cifar10.sh

   • By default, GPU #0 is used.
   • Parameters first_net_id, last_net_id determine which nets will be evaluated (only first 1000 nets by default).
   • All evaluated solutions data will be put in benchmark_cifar10/evaluations/. Data for each model is stored in a separate .json
   • You can run multiple copies of this script to do evaluations in parallel.

4. To build the final dataset:python3 src/build_dataset.py --dir benchmark_cifar10

   • Will assemble separate jsons into a single json (e.g., benchmark_cifar10_dataset.json) containing the data for all evaluated solutions

Benchmarks statistics

<img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR10_mmacs_val.png" width="300"/> <img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR10_mmacs_test.png" width="300"/>

<img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR100_mmacs_val.png" width="300"/> <img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR100_mmacs_test.png" width="300"/>

<img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR10_val_test.png" width="300"/> <img src="https://github.com/ArkadiyD/MacroNASBenchmark/blob/master/benchmarks_statistics_plots/CIFAR100_val_test.png" width="300"/>
